OXeN is a ductless heat recovery unit. Two stage heat recovery in cross flow
exchangers ensure high efficiency. OXeN units are dedicated for use in medium
and large size areas where mechanical air exchange is a must. There are two
types available
X2-N-1.2-V –w/o additional heater, wall montage
X2-W-1.2-V –with additional heater (water supplied) to warm up fresh air, wall
montage
X2-E-1.2-V –with additional electric heater to warm up fresh air, wall montage
X2-N-1.2-H –w/o additional heater, ceiling montage
X2-W-1.2-H –with additional heater (water supplied) to warm up fresh air, ceiling
montage
OXeN is dedicated to operate indoor, ambient temperature in range +5ºC ÷
35ºC, maximal solid pollution 0,3 g/m3. Materials which were used: EPP,
aluminium, brass, copper, galvanized steel: substances which can cause
corrosion/damage of listed cannot be present in the room.
Water heat exchanger could be supply by water or glycol solution up to 60%.
The heat exchanger tubes are made of copper. The feed medium should not
cause corrosion of this material. In particular, the parameters as below should be
provided:
