Fisher & Paykel 9 Series User manual

QUICK REFERENCE GUIDE > CG301DLPGB4 Date: 11.05.2023 > 1

Gas on Glass Cooktop, 30cm,

LPG

Series 9 | Minimal

Black Glass | LPG

Powerful single wok burner. Pair with any other appliance in our

Minimal range.

Perfect for a compact cooking area with one dual flame wok

burner

A timeless, minimal look to fit any kitchen style, with black

ceramic glass cooking zones and a black trim.

A flame-failure safety device; if the flame goes out, the gas

turns off

Removable cast iron trivets and ceramic glass that can be

wiped down for easy cleaning

DIMENSIONS

Height 59mm

Width 300mm

Depth 530mm

FEATURES & BENEFITS

COMPLEMENTARY DESIGN

The subtle black glass, anodised trim, and black dials blend

elegance with durability and are designed to match the Minimal

style Series 9 ovens. With premium styling and detailing, these

cooktops seamlessly blend with other appliances for a cohesive,

considered kitchen design.

PRECISE CONTROL

The consistent flame and heat distribution of the dual flame wok

burner combined with the highly responsive dials offer precise

heat adjustment that can perfect a slow simmer for sauces or an

intense heat for searing steaks.

EASY CLEANING

Cleaning and care of these cooktops is easy with sealed burners

and a single sheet cooking surface. After each use, simply

remove the trivets and wipe down the glass.

QUALITY MATERIALS

With cast iron trivets, anodized metal dials and tough ceramic

glass that can withstand high temperatures, we use only the

highest quality materials for optimal performance.

SAFE & SOUND

The flame failure safety device automatically turns off the gas if

the flame is accidentally extinguished.

QUALITY MATERIALS

Our cooktops are built from recyclable, eco-friendly ceramic

glass – without using arsenic or heavy metals in the

manufacturing process. The glass edges are chip-tested for

resistance to damage from pots and pans, ensuring lasting

quality.

SPECIFICATIONS

Accessories

Small pan support •

Wok stand •

Accessories (sold separately)

Joiner kit Part 534731 (required to join

Stainless steel dial kit 82225

Burner ratings

Dual wok burner (inner only) 2.4MJ/h

Dual wok burner power 21.5MJ/h

Wok burner (natural gas) 21.5MJ/h

Burners

Wok burner 1 (Dual)

Cleaning

Easy clean cooktop design •

Quick component removal •

Controls

Dual wok control •

Ergonomic control dials •

Toughened fused glass •

QUICK REFERENCE GUIDE > CG301DLPGB4 Date: 11.05.2023 > 2

Performance

Blue flame burner •

Both LPG & NG models •

Cast iron trivets •

Electronic ignition •

Quick connect gas valves •

Power requirements

Supply voltage 230 - 240V

Product dimensions

Depth 530mm

Height 59mm

Width 300mm

Safety

Flame failure system •

Warranty

Parts and labour 2 years

Zones

Number of elements 1

SKU 81993

The product dimensions and specifications in this page apply to the specific product

and model. Under our policy of continuous improvement, these dimensions and

specifications may change at any time. You should therefore check with Fisher &

Paykel's Customer Care Centre to ensure this page correctly describes the model

currently available. ? Fisher & Paykel Appliances Ltd 2020 Other product downloads available at fisherpaykel.com

Service & Warranty

User Guide Gas on Glass Cooktop

Installation Guide Black Gas Cooktop

A PEACE OF MIND SALE

24 Hours 7 Days a Week Customer Support

T 0800 372 273 Wwww.fisherpaykel.com
