FilterStream DirtTamer Supreme V2400 User manual
DirtTamer SUPREME® V2400
INSTRUCTION MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
ISTRUZIONI PER L’USO
ENGLISH 4 13
IMPORTANT SAFEGUARDS 4
ABOUT YOUR DIRTTAMER SUPREME® 5
CHARGING BASE / CHARGING PROCEDURE 6
BATTERY INDICATORS 7
3STAGE FILTRATION SYSTEM 7
CLEANING TOOLS 8
DIRT FINDING HEADLIGHT 8
HOW TO USE 9
MAINTENANCE 10 11
CLEANING TIPS / ACCESSORIES 12 13
WARRANTY Back Cover
FRANCAIS 14 23
CONSEILS DE SÉCURITÉ 14
À PROPOS DE VOTRE DIRTTAMER SUPREME® 15
STATION DE CHARGEMENT / PROCESSUS DE CHARGEMENT 16
INDICATEUR DE LA BATTERIE 17
SYSTÈME DE FILTRATION 17
ACCESSOIRES DE NETTOYAGE 18
LUMIÈRE 18
UTILISATION 19
ENTRETIEN 20 21
CONSEILS DE NETTOYAGE / ACCESSOIRES DE RECHANGE 22 23
GARANTIE Couverture Arrière
DEUTSCH 24 33
WICHTIGE VORSICHTSMASSNAHMEN 24
DIRTTAMER SUPREME® KURZBESCHREIBUNG 25
LADESTATION / LADEVORGANG 26
BATTERIEANZEIGE 27
3STUFENFILTRIERUNGSSYSTEM 27
ZUBEHÖR 28
LAMPE 28
ANWENDUNG 29
WARTUNG 30 31
REINIGUNGSTIPPS / ERSATZTEILEBESTELLUNG 32 33
GARANTIE Rückseite
ITALIANO 34 43
MISURE PRECAUZIONALI IMPORTANTI 34
DIRTTAMER SUPREME® BREVE DESCRIZIONE 35
STAZIONE DI CARICAMENTO / PROCEDIMENTO DI CARICO 36
INDICATORE DELL’ACCUMULATORE 37
SISTEMA DI FILTRAZIONE A 3SCALE 37
ACCESSORI 38
LAMPADA 38
UTILIZZAZIONE 39
MANUTENZIONE 40 41
CONSIGLI PER LA PULIZIA / ACCESSORI & FILTRI DI RICAMBIO 42 43
GARANZIA pagina posteriore
INDEX
2
3
Congratulations! You now own a top quality
FilterStream® product. To ensure maximum satisfaction,
please take a few moments to review the following important
information before using this item.
Thank you!
Félicitations! Vous venez d’acquérir un produit de
haute qualité de FilterStream® . Pour profiter pleinement
de votre appareil, veuillez prendre connaissance des
informations suivants avant de l’utiliser.
Merci!
Gratulation! Sie besitzen jetzt ein hochwertiges
FilterStream® Produkt. Damit wir für beste Zufriedenheit
garantieren können, bitten wir Sie, vor der Inbetriebnahme
diese Anleitung sorgfältig durchzulesen.
Danke!
Congratulazione! Siete in possesso di un prodotto
FilterStream® di prima qualità. Prima di mettere in servizio
quest‘apparecchio, vogliate leggere attentamente le
istruzioni per l‘uso.
Grazie!
IMPORTANT SAFEGUARDS
4
maintenance.
• Do not put any object into
openings. Do not use with any
opening blocked; keep free of dust,
lint, hair, or anything that may
reduce airflow.
• Do not use on or near hot surfaces.
• Use extra care when cleaning on
stairs.
• This vacuum is intended for
household use.
• Use only as described in this manual.
Use only original FilterStream®
DirtTamer® accessories and filters.
• This product contains a sealed lead
acid battery. Do not incinerate the
batteries as they will explode at
high temperatures. Always dispose
of the batteries in accordance with
your country’s laws.
• Leaks from a battery cell can occur
under extreme conditions. If the
battery liquid gets on skin: (i) wash
immediately with water. (ii) If it gets
in your eyes, immediately flush your
eyes with water and seek medical
attention.
DIESE I
SAVE THESE
INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS
CAREFULLY BEFORE USING THIS
APPLIANCE.
WARNING!
To reduce the risk of fire, electrical
shock or injury:
• Close supervision is necessary when
any appliance is used by children.
Do not allow this appliance to be
used as a toy.
• Do not use without bowl and filters
in place. Replace a damaged filter
promptly.
• To protect against risk of electrical
shock do not put unit or charging
base in water or other liquid.
Although this vacuum is designed to
pick up liquids, only the nozzle end
of the bowl should be placed in a
liquid.
• Do not pick up anything that is
burning or smoking.
• Avoid picking up hard, sharp objects
with the vacuum as they may
damage the vacuum and the filters.
• Do not operate in the presence of
explosives and/or flammable fumes
or liquids.
• Do not unplug the charger by
pulling on the cord. Do not pull cord
around sharp edges or corners.
• Never handle the plug or vacuum
with wet hands.
• Use only the charger supplied with
this unit to recharge the vacuum.
• Do not operate with a damaged
cord or charger.
• Unplug the charger from outlet
before any routine cleaning or
Your DirtTamer Supreme® V2400 Cordless Wet/Dry Vacuum is the most advanced
handheld vacuum of its kind. It stands out for superior suction, extra long
runtime, patented 3stage filtration, and the unique ability to trap 99.97% of
allergy causing particles down to 0.3 microns with the included HEPA filter.
5
ABOUT YOUR DIRTTAMER SUPREME®
1
2
3
4
5
6
7
8
9
10
13
14
15
16
17
4
5
3
2
1
19
17
15
14
13
11 10
9
8
7
6
18
17
20
12
Charging Base
Bowl
Bowl Nozzle
Bowl Latch
Charge and Low
Battery Indicators
On/Off Switch
Handle/Housing
Battery Compartment
Charger and Cord
Squeegee
Upholstery Brush
Extendible Wand/
Crevice Tool
Plastic Wall Anchors
Screws
Filter Cover
PreFilter
Foam Filter
HEPA Filter
Exhaust Port
Dirt Finding Headlight
18
19
20
16
11
12
CHARGING BASE | CHARGING PROCEDURE
6
WALL MOUNTABLE
The Charging Base can be mounted
vertically (see Figure A) or placed on
a horizontal surface such as a counter,
shelf, etc.
If you choose to wall mount the
Charging Base, please use the
enclosed anchors and screws. Drill
5 mm diameter holes into the wall.
CHARGING PROCEDURE
1.Plug the Charging Base into a
230 volt electrical outlet.
2.IMPORTANT: Make sure that the
On/Off switch is turned to the
„Off“ position before charging.
Otherwise, your vacuum will not
charge.
3.Slide the vacuum downward onto
the charging base making sure that
the vacuum firmly hooks onto the
Charging Base (see Figure B). The
Green Light indicates that charging
is taking place. If your DirtTamer
is completely out of power, a full
recharge will take approx. 10 h.
Note: before first use, charge your
vacuum for at least 24 hours.
4.To maintain a
charge, keep
the Charger
plugged in
at all times.
The Charger
may be warm
to the touch.
This is normal.
Figure A
Wall Mounting Base
Figure B
Charging Plug
7
CHARGE AND
LOW BATTERY
INDICATORS
GREEN LIGHT:
Indicates that the vacuum is CHARGING
or „ON“and OPERATING AT AN
ACCEPTABLE LEVEL of power.
RED LIGHT:
The red light will illuminate when
your vacuum is ALMOST OUT OF
POWER and needs to be recharged.
BATTERY INDICATORS | FILTRATION SYSTEM
Green
Red
Charging/On
Low Charge
3STAGE FILTRATION SYSTEM
Dirt Tamer Supreme® has a revolutionary, patented 3stage filtration system that
provides superior suction for a longer period of time.
Stage 1: Large particles of debris are separated from liquids and air. The large
particles remain in the PreFilter for easy disposal (see „Maintenance“
section of this manual for PreFilter and Bowl emptying instructions).
Stage 2: Liquids and smaller dirt particles are separated from air and collected
in the Bowl.
Stage 3: Fine dust/dirt particles are trapped by the standard Foam Filter
(included), or, with the included HEPA filter, 99.97% of dust, pollen,
bacteria and other allergens down to 0.3 microns in size can be captured.
3
2
1
Air Flow
CLEANING TOOLS | DIRT FINDING HEADLIGHT
8
Your DirtTamer Supreme® V2400
vacuum includes the following unique
cleaning tools that will make your
cleaning tasks easier.
1.Extendible Wand/Crevice Tool
This „two in one“ tool works great
as a long reach cleaning wand
(ceiling corners, under appliances,
etc.) or as a crevice tool for tight
places (between car seats, in
corners, etc.).
2.Squeegee
This tool has rubber edges for
picking up liquid spills on hard
surfaces such as floors, countertops,
etc.
3.Upholstery Brush
This tool is used for picking up dirt
and dust debris from upholstery,
tables, etc.
DIRT FINDING HEADLIGHT
Your DirtTamer is equipped with a
unique Dirt Finding Headlight which
allows you to easily see dirt and dust
under furniture or in dark corners.
The headlight will operate when the
vacuum is switched „On“.
Lamp Replacement Instructions
The lamp in you DirtTamer headlight
will last for years of normal household
use.
1.Insert the tip of a flat head screw
driver into the slot (see Image 4) at
the front of the lamp and twist to
open it.
2.Remove the used lamp cartridge.
3.Insert a new replacement lamp
cartridge. Use only a genuine
FilterStream® L200B lamp
cartridge.
For replacement lamp see page 13.
1
23
4
9
PICKING UP DRY DEBRIS
Use your vacuum for picking up dirt,
dust, food crumbs, etc. from counters,
bare floors, rugs, automobile interiors,
upholstered furniture, etc. After dry
pickups, empty and clean the Bowl
and Foam Filter before picking up
liquid or wet spills.
NOTE: If using a HEPA Filter in place
of the Foam Filter, shake loose, or
brush off any dust or debris from the
HEPA Filter if you notice any buildup.
DO NOT WASH OR RINSE THE HEPA
FILTER, as this would damage the
HEPA material.
If the HEPA Filter accidentally gets wet
from vacuuming wet spills, remove
the HEPA Filter, pat it dry with a paper
towel, and allow it to thoroughly air
dry before next use.
HOW TO USE
PICKING UP
LIQUIDS OR WET DEBRIS
For ideal performance, we recommend
the use of the Foam Filter for liquid
debris.
aFor liquid pickups, insert the
Squeegee into the Bowl Nozzle.
bDo not fill the Bowl beyond the end
of the PreFilter. If there is any liquid
in the Bowl, hold the Bowl Nozzle
down to avoid leakage. Tipping the
Bowl Nozzle up may cause the liquid
to enter the fan area.
c After picking up perishable spills
(e.g. milk, juice, etc.), empty your
vacuum‘s Bowl and PreFilter
immediately and thoroughly clean
the Bowl, PreFilter, Filter Cover and
Foam Filter to prevent mould and
mildew from forming.
Remove your vacuum from the Charging Base and slide the On/Off Switch to the
„On“ position to operate. Slide the On/Off Switch to the „Off“ position between
cleaning tasks to conserve power.
CLEANING / REPLACING
FOAM AND HEPA FILTER
To remove/replace the Filter (either
foam or HEPA) from the vacuum,
please follow these steps:
aRemove the Filter
Cover from the
vacuum
Handle/Housing.
bRemove the Filter
from the Handle/
Housing.
c Clean the Filter as
follows.
Foam Filter
Cleaning: Wash
the Foam Filter in
warm, soapy water
unitl clean. Allow the Foam Filter to
dry before reinserting.
NOTE: Use only mild soap. Avoid
detergents, chemical cleaners or
solvents as these may damage the
plastic.
HEPA Filter Cleaning: Use your
finger to lightly clean the paper
surface of the HEPA Filter, clearing off
any dirt, dust, and hair.
NOTE 1: Do not wash the HEPA Filter.
Water will permanently damage the
filter.
NOTE 2: Under normal household use,
the HEPA filter will last 6 months to
1 year.
MAINTENANCE
10
EMPTYING / CLEANING
PREFILTER AND BOWL
aHolding the Bowl with one hand
and the Handle/Housing with the
other, depress the Bowl Latch and
swing the Bowl away from the
Handle/Housing
bRemove the
PreFilter by
grasping the
pulltab on top
of the PreFilter
with your
fingers. Empty
any dirt, debris,
or liquid from
the Bowl and
PreFilter into
the sink or waste
basket.
c Rinse or hand wash the PreFilter,
Bowl and Filter Cover with water (if
needed, with warm, soapy water).
NOTE: The PreFilter, Bowl and
Filter Cover can be washed in the
dishwasher (top rack only).
dAllow the PreFilter, Bowl and
Filter Cover to dry. Then reinsert
the PreFilter into the Bowl, snap
the Filter Cover onto the Handle/
Housing, and reattach the
Bowl to the Handle/Housing.
a
b
a
b
Other manuals for DirtTamer Supreme V2400
1
Table of contents
Languages:
Other FilterStream Vacuum Cleaner manuals
FilterStream
FilterStream DirtTamer Ultima V2510 User manual
FilterStream
FilterStream DustTamer Ultra D4500 Manual
FilterStream
FilterStream DirtTamer V2100 User manual
FilterStream
FilterStream D4200 Manual
FilterStream
FilterStream D4200 User manual
FilterStream
FilterStream DirtTamer Supreme V2400 User manual
FilterStream
FilterStream V2210 User manual
