FUNCTION DESCRIPTION
1. Power Switch Button
Control AC power supplier, the power indicator lights up when “on”, indicating that
the power supply is connected ; the power indicator is switched off when“off ”,
indicating that the power supply is disconnected.
2. Auxiliary 1 Voice Control Knob
Control the volume of AUX1 input channel and increase the volume of sound as
rotates clockwise. When turned counterclockwise , attenuates the volume.
3. Auxiliary 2 Voice Control Knob
Control the volume of AUX2 and MP3, and raise the volume as it rotates clockwise.
When turned counterclockwise, attenuates the volume.
4. Tweeter Tone Adjustment Knob
Adjustable microphone and AUX1、A UX2、MP3 the treble part, When the needle
rotates, the treble is raised, and when the needle rotates counterclockwise, the treble
is attenuated.
5. Bass Tone Control Knob
Adjustable microphone and AUX1、 A UX2、 MP3 the bass part, when clockwise
rotating , lift the bass, and when rotating counterclockwise, attenuate the bass.
6. Microphone 1 Input Hole
Microphone 1 has the priority kinetic energy, when playing the music with the
microphone 1 call, the music will automatically attenuate the small, to achieve
microphone broadcast priority.
7. Microphone2 Input Hole
8. Microphone3 Input Hole
9. Power-driven Display Lamp
The power supply is on and off. When the light is on, the power is turned on.
10. Protect Power Standby Lights
On boot, the light indicates that the machine is in standby mode, about 3 seconds
after lights out. Extinguish: if it is lit for a long time, it means that the machine is
out of order and should be turned off at once Power, find qualified maintenance
personnel to find out the cause.
11/12/13/14. Level Indicator
Display the music level, the light indicates the strength of the music signal.
