Model:-FS-2LAN+1POTS+WiFi Dual Mode
HGU User Manual V1.0
Chapter2: Installation
2.1Installation Requirements
Installation Environment Requirements
HGU equipment must be installed in the interior, and to ensure the following conditions:
Confirmation at the HGU installation at sufficient space to facilitate cooling machine.
HGU suitable operating temperature of -5 ℃~ 55 ℃,humidity10% to 90%.
Device workplace should avoid radio transmitters,radar stations, and high-frequency
interference from power equipment.
Equipment Installation
1. installed on the desktop
Place the machine on a clean bench, this installation is relatively simple, you can observe the
following operation:
Ensure the smoothworkbench.
Around the device enough space for heat dissipation.
2. mounted on the wall
Observation HGU equipment chassis two cruciform recess, in accordance with the position
ofthe groove, installed two screwsin the wall.
The original selected two mounting screws gently snap into recesses aligned.
Slowly let go,so that the device under the supportof the screw hanging on the wall.
2.2Panel
Figure 3 Panel lights
