Fellowes Powershred PS25 User manual

Models: PS25 PS50

PS25 PS50 Plus

PS30 PS55

PS30 Plus PS55CC

PS40 PS45

DM-3 PS35

Operating Instructions

Mode d’emploi

Instrucciones de funcionamiento

Bedienungsanleitung

Bedieningsinstructies

Istruzioni sul funzionamento

Powershred® Personal Series

Safety Instructions

• Read and save these instructions.

• Follow all warnings and instructions marked on the product.

• Always turn off and unplug the machine before moving, cleaning, or conduct other than normal operation.

• Operate shredder from the power source indicated on the serial label or power supply. If you are not sure of the

type of power available, consult your dealer or a power company.

• Power cord should be easily accessible because it serves as the disconnect switch. If the power cord is damaged,

call the number listed under “Contact for Service”.

• If the shredder does not come with a wastebasket, be certain the basket you select provides a stable base for the

shredder. Tall or narrow baskets may be top heavy and unstable.

• Keep loose objects (jewelry, ties, long hair) away from shredder.

• CAUTION: Do not insert aerosol cleaners or lubricants into or around the machine. Some agents may combust,

causing serious injury.

• Empty wastebasket frequently.

• Do not place shredder near water, over a radiator or a heat register.

• Do not rest anything on the power cord. Do not place machine where people will walk on the cord.

• The use of an extension cord is not recommended.

• Do not service this product yourself. An opened cover may expose you to dangerous voltage points or other risks,

and will void manufacturer’s warranty.

• Do not exceed recommended sheet capacity or usage. (See “Sheet Capacity and Usage”, Table A).

• Do not shred continuous forms.

• Do not shred labels, transparencies, glossy paper, newsprint, plastic or cardboard.

• Keep out of the reach of children and pets.

• Never insert your hand or fingers into feed opening.

• Practice caution when shredding paper that contains paper clips and staples. Shredder is intended for paper only,

although clips and staples will not harm the cutting system nor void the 5 year cutter warranty, but the added

thickness may decrease sheet capacity.

Installation

All Models

• Where applicable, plug power cord into jack on the unit.

• Position shredder securely on basket.

• Plug power cord into a standard AC outlet with the appropriate power requirements as

stated on the serial number label adhered to the bottom of the shredder.

PS25

PS30

PS50

Fits wastebaskets from 13 1/4” - 16 1/2” (337 - 419mm) wide.

• Position shredder securely over basket and extend adjustable arm so shredder solidly rests

on basket edges.

Operation

Cleaning

Sheet Capacity and Usage

• Do not exceed recommended sheet capacity for your model.

• Folding paper to fit the entry increases the thickness and recommended capacity may be exceeded.

• Clips and staples increase the thickness and may decrease sheet capacity.

PS25

PS25 Plus

PS30

PS30 Plus

PS35/PS40

• Follow instructions for sheet capacity. (See Table A)

• Position paper over entry.

• Depress power switch to the ON (I) position to start cutting system.

• Return the power switch to the OFF (O) position to stop cutting system.

PS50

PS50 Plus

PS55*

PS55CC*

DM-3*/PS45*

• Follow instructions for sheet capacity. (See Table A)

• Depress the power switch to the ON (I) position to activate the standby mode.

*Green Ready light will come on if model has indicator lights.

• Shredder automatically starts when paper is placed in the entry and stops when

finished shredding.

All Models • Unplug the unit from the wall before cleaning.

• Housing can be cleaned with a cloth, dampened with a mild soap and water solution.

US 20# Paper 64 GSM 80 GSM 80 GSM

Model: Sheets per Pass Sheets per Pass Sheets per Pass Sheets per Pass

120V/50Hz 100V/50Hz 230V/50Hz 240V/50Hz

PS55CC 3 N/A N/A N/A

PS25 5 7 5 5

PS25 Plus 5 7 5 5

PS 30 5 7 5 5

PS30 Plus 5 7 5 5

PS35 & PS40 5 7 5 5

PS50 5 7 5 5

PS50 Plus 5 7 5 5

PS55 (non-100/120V) N/A N/A 5 5

PS55 (100/120V) 77N/A N/A

DM-3/PS45 7 7 N/A N/A

TABLE A Different paper weights and electrical currents will affect capacity.

Safety & Maintenance of PS55CC

The PS55CC cross cut shredder creates small particles that, if allowed to accumulate, cause the shredder to jam.

Follow these simple precautions to significantly reduce the likelihood that particles will accumulate and to keep your

cross cut shredder operating at peak efficiency:

• Do not allow the basket to overfill. The power of this shredder will compress paper particles into the basket even

when it is full. The life of your shredder may be reduced if the cutting system continues to operate with particles

packed around it.

• Reverse the shredder often. Reversing helps the shredder flush out small cut particles. Empty basket if it is full

before reversing.

Oil the cutters:

When...

• Every second or third time you empty the basket;

• If the shredder’s cutting capacity is diminished;

• If the cutting cylinders stop with a squeak or a rubbing sound after power is removed.

How...

Use Powershred Lubricant #35250 or a suitable alternative with an extension nozzle. Alternatives can be 3 in 1 or

Sewing Machine Oil. Oil must be non-flammable material and a non-degreaser! Do not use a can spray. Accelerants

are combustible. See order form in this manual.

Squeeze the lubricant across the full width of the cutters and then turn the machine on and run the cutting system

forward for a few seconds. (Since cross-cut machines have auto start, it will be necessary to block the photo eye with

a piece of paper in order to run the cutting system forward).

Then, depress the reverse button and run the cutting system for a few seconds. Repeat the procedure.

Safety of PS55CC

• Do not operate PS55CC without the basket it was shipped with.

• Do not use without the safety flap. Injury may result.

• Do not attempt to defeat the safety interlock switch.

Paper Jams

1. Immediately return power switch to OFF (O) position.

2. Depress power switch to the REVERSE (R) position until the jammed paper has been fully removed from the cutter.

3. DO NOT PULL ON PAPER. Damage to the drive system could occur.

4. If the REVERSE (R) function will not operate when pressed, the internal overload protection device has been

activated. Release the power switch from the REVERSE (R) POSITION, wait 15 seconds and repeat.

5. If the machine jams in reverse, unplug the unit and cut all excess paper off the top and bottom of the machine

before repeating the jam-clearing procedure.

6. Shred smaller quantities. See sheet capacity (Table A).

Model

When operating this product, you must use the enclosed power supply.

Failure to do so will void the manufacturer’s warranty and may damage the unit.

North America Australia

Europe Japan

Parts Identification

Wastebaskets not included with some models.

DM-3

PS45

PS55

PS55CC

Red light = capacity exceeded.

1. Empty the basket if it is full.

2. Reverse out the paper being fed into the shredder.

3. Divide the paper being shred into smaller packets that are within the stated

capacity of the shredder.

4. If the jam persists, slowly move the shredder’s power switch back and forth

between FORWARD (I) and REVERSE ( R ), always stopping for a moment in the

OFF position (O). Rapid switching can create force that will damage your

shredder.

PS55CC only 5. See “Maintenance of PS55CC Cross Cut Shredder.”

POWERSHRED PS 10

1. Power Jack or Power Cord

2. Power Switch

3. Housing

4. Paper Entry

5. Wastebasket

6. Indicator Lights (on select models)

PS25, PS30, PS50

PS35, PS40, PS45,

PS55, PS55CC, DM-3

Overload Protection

This shredder is protected by a built-in thermal overload

device that serves to protect the motor from overuse.

When continuous shredding is conducted for an extended

period of time, the shredder will automatically turn itself

off to cool down. When shredding is automatically

stopped, allow the unit to stand for about 30 minutes

before using it again.

Important Note

This paper shredder is not intended to shred high volumes

of paper. Please refer to the specifications for the

recommended daily usage and sheet capacity of this

shredder. Please note that if the paper is wider than the

entry, and you fold it to fit, the paper thickness increases

and the recommended capacity may be exceeded.

Limited Warranty

Fellowes Manufacturing Company warrants the cutting cylinders of all Fellowes shredders to be free from defects

in material and workmanship for five years from the date of purchase by the original consumer. Fellowes warrants all

other parts of the machine to be free of defects in material and workmanship for one year from the date of purchase

by the original consumer. If any part is found to be defective during the warrant period, your sole and exclusive

remedy will be repair or replacement, at Fellowes’ option and expense, of the defective part.

This warranty does not apply in cases of abuse, mishandling or unauthorized repair. ANY IMPLIED WARRANTY,

INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION

TO THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any

consequential or incidental damages attributable to this product. This warranty gives you specific legal rights. You

may have other legal rights that vary from state to state.

For more detail or to obtain service under this warranty, please contact Fellowes Customer Service at 1-800-955-

0959, Monday through Friday, 8 AM - 5 PM (Central Standard Time).

For specific instructions on obtaining service under this warranty on machines purchased outside the USA, contact the

appropriate location listed in the Contact for Service section of this instruction manual.

Warrantor: Fellowes Manufacturing Company.

Model Shredding Speed Dimensions Weight

PS25 Plus 20 fpm 15” x 16 1/2” x 10” 8 lbs.

PS30 Plus (6 m/min) (380 x 419 x 254 mm) (3.6 kg)

PS40 20 fpm 17 1/4” x 14 3/4” x 10” 9.25 lbs.

PS35 (6 m/min) (438 x 375 x 254 mm) (4.2 kg)

PS25 20 fpm 2 1/2” x 15” x 5” 7 lbs.

PS30 (6 m/min) (63.5 x 380 x 127 mm) (3.2 kg)

PS50

PS50 Plus 20 fpm 15” x 16 1/2” x 10” 8 lbs.

(6 m/min) (380 x 419 x 254 mm) (3.6 kg)

PS55 20 fpm 17 1/4” x 14 3/4” x 10” 9.25 lbs

DM-3/PS45 (6 m/min) (438 x 375 x 254 mm) (4.2 kg)

PS55CC 12 fpm 17 1/4” x 14 3/4” x 10” 9.5 lbs.

(3.6 m/min) (438 x 375 x 254 mm) (4.3 kg)

Specifications:

Entry width = 9” (230 mm)

Power Source: 120V-60Hz (N. America)

240V-50Hz (Australia)

230V-50Hz (U.K., Europe)

100V-50HZ (Japan)

Power Cord: 6 Feet (1.9 meters)

Shred Size:

PS55CC

5/32” x 4/5” (3.9mm x 20mm)

All others

7/32” (5.8mm) strip

Declaration of Conformity

Fellowes Manufacturing Company

Doncaster Road, Kirk Sandall

Doncaster, South Yorkshire, DN31H England

declares that the product

Models PS25, PS30, PS35 and PS40, with or without the suffix “Plus” conforms with the requirements of the Low

Voltage Directive (73/23 EEC) and the Electromagnetic Compatibility Directive (89/336 EEC) and the following

harmonized European Normes (EN Standards) and IEC Standards.

Safety: EN60950 ‘Information Technology Equipment’

EMC: StandardSeverity Level Performance Criteria

EN 55014 Table 1&2 N/A

EN 61000-3-2 Class A N/A

Itasca, Illinois, USA _____________________

April 30, 1999 Anthony Storrie

Declaration of Conformity

Fellowes Manufacturing Company

Doncaster Road, Kirk Sandall

Doncaster, South Yorkshire, DN31H England

declares that the product

Models PS50 and PS55, with or without the suffix “Plus”

conform with the requirements of the Low Voltage Directive (73/23 EEC) and the Electromagnetic Compatibility

Directive (89/336 EEC) and the following harmonized European Normes (EN Standards) and IEC Standards.

Safety: EN60950 ‘Information Technology Equipment’

EMC: StandardSeverity Level Performance Criteria

EN 55014 Table 1&2 N/A

EN 55104 T. 5,2 N/A

EN 61000-3-2 Class A N/A

EN 61000-4-4 Level 2 B

EN 61000-4-5 Level 2 B

EN 61000-4-2 EN 55104 T.6,1 B

EN 61000-4-11 EN 55104 T.6,7 C

ENV 50141 EN 55104 T.6,3 A

Itasca, Illinois, USA _____________________

April 30, 1999 Anthony Storrie

Consumer Helpline

Australia 1-800-33-11-77

Canada 1-800-665-4339

Mexico 001-800-234-1185

United States 1-800-955-0959

Europe 00 800 1810 1810

Fellowes Locations

Australia 011-613 93303211

Benelux 011-31-3473-77988

Canada 905-475-6320

France + 33 (0) 2-99-22-71-22

Germany + 49 (0) 5131-4977-0

Italy + 39 (0) 071-730041

Japan 011-81-3-5496-2401

Korea 82-2-3464-2884

Poland + 48-22-837-7356

Singapore 65-6221-3811

United Kingdom + 44 (0) 1302-836836

This manual suits for next models

Table of contents

Other Fellowes Paper Shredder manuals

Fellowes

Fellowes 225Ci User manual

Fellowes

Fellowes POWERSHRED C-480 User manual

Fellowes

Fellowes P-12C User manual

Fellowes

Fellowes Fortishred 3250SMC User manual

Fellowes

Fellowes OS12Cs User manual

Fellowes

Fellowes POWERSHRED 62MC User manual

Fellowes

Fellowes 29850J User manual

Fellowes

Fellowes P500-2W User manual

Fellowes

Fellowes powershred 450Ms User manual

Fellowes

Fellowes POWERSHRED 99Ci User manual

Fellowes

Fellowes Powershred M-7Cm User manual

Fellowes

Fellowes AutoMax 300C User manual

Fellowes

Fellowes AutoMax AutoMax 200C User manual

Fellowes

Fellowes Personal Shredmate User manual

Fellowes

Fellowes OD1500 User manual

Fellowes

Fellowes SB-99Ci User manual

Fellowes

Fellowes Powershred 12C User manual

Fellowes

Fellowes POWERSHRED DS-2 User manual

Fellowes

Fellowes POWERSHRED P-48C User manual

Fellowes

Fellowes POWERSHRED DS-1 User manual

Fellowes

Fellowes POWERSHRED DS-1 User manual

Fellowes

Fellowes POWERSHRED Shredmate User manual

Fellowes

Fellowes FORTISHRED 3250C User manual

Fellowes

Fellowes Powershred W11C User manual

Popular Paper Shredder manuals by other brands

Swingline

Swingline STACK-AND-SHRED200X&200XL 60X Start here

GBC

GBC ShredMaster CC055 instruction manual

UNITED OFFICE

UNITED OFFICE UAV 190 A1 operating instructions

UNITED OFFICE

UNITED OFFICE UAV 190 A1 operating instructions

Rexel

Rexel Optimum AutoFeed+ 45X instruction manual

Martin Yale

Martin Yale 227284S1 instruction manual

Bonsaii

Bonsaii DocShred C223-A instruction manual

HSM

HSM Pure 740 max operating manual

TRU RED

TRU RED TR-BMC20A Operator's manual

GBC

GBC SHREDMASTER 1236SE operating instructions

Gude

Gude GH 2600 P operating instructions

Ativa

Ativa DQ80M operating instructions

Q-Connect

Q-Connect Q8CC instruction manual

Olivetti

Olivetti Privacy 5000C Operational manual

UNITED OFFICE

UNITED OFFICE UAV 190 A1 operating instructions

Dahle

Dahle paperSAFE 22022 instructions

Formax

Formax OnSite FD 87 Operator's manual

GEHA

GEHA Home & Office S7 CD manual
