4CH DVR_FXV-H1304
FRONT PANEL CONTROLS
①②③④⑤⑥⑦⑧
⑨⑩⑪⑫⑬
Play back in normal speed.
Port for USB external devices.
⑤LED Display
(From left to right)
Power: Power is on.
HDD: Hard disk is in use.
LAN: Connected to the internet (in red): Remote user logged in.
REC: Recording.
PLAY: Playing back.
Input sensor for the remote control.
In SETUP mode, press to move cursor down. In PLAYBACK mode, press
to stop playing back.
In SETUP mode, press to move cursor up. In PLAYBACK mode, press to
slow down.
In SETUP mode, press to increase value. In PLAYBACK mode press to
play forwards.
In SETUP mode, press to reduce value. In PLAYBACK mode, press to
play rewind.
In SETUP mode, press to enter values. In PLAYBACK mode, switch
between full, quad, 9-channel, 16-channel display in order.
In LIVE or PLAYBACK mode, switch to 4-channel display。
In LIVE or PLAYBACK mode, switch to CH1。
In LIVE or PLAYBACK mode, switch to CH2。
In LIVE or PLAYBACK mode, switch to CH3。
In LIVE or PLAYBACK mode, switch to CH4。
In LIVE mode, display with picture in picture format.
In LIVE or PLAYBACK mode, enlarge the display of a channel.
Enable / Disable Key Tone.
In LIVE mode, press to display the BACKUP menu. In SETUP mode,
press to return to previous page.
In LIVE mode, press to display menu. In PLAYBACK mode, press to pause
playback.
