Faber Fyn 600 User manual

Installation manual

Fyn 600

40011131-1840 Fyn 600 ENG

1 < <<<

1.1

1.2

1.3

1.4

1.5

2 < <<<

2.1

2.2

2.3

2.4

2.5

2.6

3 < <<<

4.1

4.2

4.3

4.4

3.1

3.2

4 < <<<

1Dear user

Congratulations on purchasing your Faber

product, a quality product that will provide

you with the warmth and atmosphere for

many years. Please read the user manual

before using the fire. Should a malfunction

occur despite the careful final checks, then

you can always contact your Faber dealer.

In order to claim the guarantee, it is

important that you register the fire. For this

we have created a special site. You will find

all information regarding the warranty

during registration.

Please note:

The data of your fire is available in

the user manual.

You can register your fire at:

www.faber-fires.eu

1.1 Introduction

Installation and maintenance of the fire must

be carried out by a professional expert who

has proven knowledge and demonstrable

competence. A professional craftsman takes

into account all technical aspects such as

heat delivery, gas connection as well as flue

gas discharge requirements.

Where the installation instructions are not

clear, you must follow national / local

regulations.

1.2 Please check

Check the fire for transport damage and

report any damage immediately to your

dealer.

1.3 CE Declaration

Glen Dimplex Benelux certifies that this Faber

fire complies with the essential requirements

of the gas appliances directive.

Product: gas room heater

Model: Fyn 600

This appliance complies with the Gas

Appliance Regulation (EU) 2016/426.

Harmonized standards applied:

EN 613 2000/A1 2003.

This declaration is invalid, if without the

written permission of Glen Dimplex Benelux:

•Changes are made to the appliance.

•The fire is connected to other exhaust

materials than specified.

2Safety instructions

Please note:

It is advisable to always install a screen for

the fireplace if children, elderly or disabled

people are present in the same room as the

fireplace. If regularly vulnerable persons

can be present in the room without

supervision, sufficient protection must

always be placed around the fireplace.

The appliance is designed for

atmospheric and heating purposes,

meaning that all visible surfaces,

including the glass, can become

hotter than 100°C.

Do not use the remote control and /

or app outside the room where the

fire is located. So that you are always

aware of the situation around the

fireplace when it is being operated.

The appliance should be placed,

connected and annually checked in

accordance with these installation

instructions and valid national and

local Gas Safety (Installation and Use)

Regulations.

Check whether the data on the

registration plate are in agreement

with the local type of domestic gas

and pressure.

The fitter is not permitted to change

these adjustments or the construction

of the appliance!

Do not place any additional imitation

logs or glowing coals on the burner or

in the combustion chamber.

Do not place any inflammable

materials within a of 0,5m. of the

radiation of the appliance and

ventilation grills.

Due to natural air circulation of the

appliance, moisture and volatile

components from paint, building

materials, floor coverings etc. that

haven’t yet set, can be drawn through

the convection system and can be

deposited on cold surfaces as soot.

That is why you should not use the

appliance shortly after a renovation.

The first time the appliance is

switched on, Let the fire run on

maximum setting for several hours so

that the lacquer coating will have an

opportunity to set and possible

vapours released can be safely

removed by ventilation. We advise

you to be outside the room as much

as possible during this process!

5 < <<<

Please note:

1. All transport packaging should be

removed.

2. Children or pets should not be

present in the room.

3Installation requirements

3.1 The fire

This appliance must be installed in a

chlorine-free environment.

The appliance must be built into an

existing or a newly to be constructed

false chimney breast.

3.2 False Chimney breast

The false chimney breast must be

constructed of an non-combustible

material.

Always ventilate the space above the

appliance by means of the grills or a

comparable alternative with a

minimum air supply of 200cm².

Keep a free distance of min. 50mm on

the back site of the fire.

The false chimney breast and its

construction may not rest on the

appliance

For the finish, use special stucco

(min. 100°C resistant) or glass fibre

wallpaper to prevent discoloration or

cracks etc. Recommended drying

time: for plaster is a minimum of 24

hours per mm of coat applied.

3.3 Requirements flue system and

outlets

You should always make use of the

materials prescribed by Faber. Only

by using these materials can Faber

guarantee a proper functioning.

The outside of the concentric flue

material can reach a temperature of

Approx 150°C. Make sure of proper

insulation and protection in case of

transit through combustible wall or

ceiling constructions. And observe

sufficient distance.

Make sure that the concentric flue

materials are bracketed every 2m.

When they have an extended length,

so that the weight of the flue

material is not resting on the

appliance itself.

You may never start with a cut-down

concentric pipe directly on to the

appliance.

3.4 terminals

The flue outlet can end on an external

wall or a roof. Check whether the outlet

desired by you complies with local

requirements concerning good function

and ventilation systems .

Please note:

For a proper functioning the terminal

should be at least 0,5m. away from:

Corners of the building.

Roof overhangs and balconies.

Eaves (with the exception of the

roof ridge, see chapter 15).

3.5 Existing chimney

You can also connect the appliance to an

existing chimney. The existing chimney will

function as an air supply and a flexible

stainless steel pipe drawn up through the

chimney will remove the combustion gas.

The flexible stainless steel pipe of Ø100mm

should have a CE mark for temperatures up to

600°Celsius.

The chimney should comply with the following

requirements:

The diameter of the flue system

must be at least 150x150mm.

There should be no more than 1

appliance connected to a flue pipe.

The chimney must be in good

condition

oNo leakage and

oIt should be properly swept.

For more information about connections to

existing flue systems, see the manual

“connections”.

4Preparation and Installation

instructions

4.1 Gas connection

The gas connection must comply with locally

valid standards.

We advise pipe work from the meter to the

appliance must be of adequate size, with near

the appliance a shut-off valve that should

always be accessible. Place the gas

connection in such a way that this is easily

accessible, and that before service, the

burner unit can be disconnected at all times.

4.2 Electric connection

If an adapter is used for the power supply,

then a wall socket 230VAC –50Hz must be

mounted in the close neighbourhood of the

hearth.

6 < <<<

4.3 Preparation of the appliance

Remove the packaging of the

appliance . Make sure the gas pipes

underneath the appliance are not

damaged.

Clear a safe space to store the cover

lists and the glass.

Remove the cover lists and the glass

and take the separately wrapped

parts out of the appliance

Prepare the gas connection to the gas

control valve.

4.4 Placing the appliance

Take the installation requirements into

account (see chapter 3).

Place the appliance into the proper

position.

There is no possibility to adjust the

height of the fire.

4.5 Mounting the smoke emission outlet

materials

In case of a wall or roof terminal, the

hole must be at least 5mm bigger

than the diameter of the flue

material.

Horizontal parts must be installed at a

(3 degree) slope up away the

appliance.

Build up the system from the

appliance. If this is not possible, you

should make use of an adjustable

pipe.

For fitting the system an 0,5m. cut-

down pipe should be used. Make sure

the inner pipe is always 2cm longer

than the outer pipe. Wall and roof

terminal are also shortened. These

parts must be secured with a self-

tapping screw.

Do not insulate but ventilate build-in

flue material (approx.100cm²).

4.6 Building a false chimney breast

Before constructing the chimney breast we

advise you to perform a function test with the

appliance as described in chapter 7 “Checking

the installation”.

Construct the false chimney breast

from non-combustible material in

combination with metal profiles or of

brickwork / aerated concrete bricks.

Take the grills into account. (see fig.

1.1 and 1.2). Place a protective shield

made of non-inflammable material

above the grills. (see fig. 1.1A).

Always use a lintel if the chimney

breast is constructed of brickwork.

These should not be placed directly

onto the appliance.

Construct the chimney breast against

the build-in frame (see fig. 1.1B).

Keep a minimum margin of 3 mm

between chimney breast and the

appliance in connection with the

expansion of the appliance

The depth of the recess into the

chimney breast has no influence on

the removal of the glass.

5Removing the glass

Remove the cover strips left and

right. (See fig. 2.1).

Remove cover strip on the bottom.

(See fig. 2.2).

Remove the cord list on both sides.

(See fig. 2.3).

Place the suction discs onto the glass.

(See fig. 1.5).

Remove the sealing cord from the

groove.

Slide the glass upwards so that it is

released from the groove. Now

gradually move the glass outwards

and downwards. (See fig. 2.4).

To replace the glass repeat the process in

reverse order.

Remove all fingerprints from the glass, these

will be burned into it once the hearth is used.

6Placing the decorative material

It is not allowed to add different or more

materials to the combustion chamber.

Always keep the pilot burner free from

decorative material!

Do not toss all the decorative material onto

the burner all at once, as the very fine dust

may block the holes in the burner.

6.1 Imitation logs

Preferably distribute the vermiculite

granules by hand over the tube

burner. The surface of the granules

may protrude above the burner plate

but must be flat over the entire

length.

Place the imitation logs according to

instructions. (see fig. 3.1. or the log

set instruction card).

Place the supplied chips. Prevent

chips from covering the burner, this

has a negative effect on the fire

image.

7 < <<<

Start the fireplace as described in the user

manual. Move chips until a good flame

distribution occurs. Place the front glass and

check the fire image again.

6.2 Pebbles

Place the pebbles over the burner and

the bottom. Spread the pebbles

evenly to a double layer. The surface

of the pebbles may be very slightly

higher than the burner tube (see fig.

3.2).

Place the glass and check the flame

picture into the appliance.

Start the pilot and main burner according to

the instructions in the user’s manual. Assess

whether the flame distribution is correct.

Place the glass and check the flame picture

again.

7Checking the installation

7.1 Checking the ignition of the pilot

burner, main burner

Start the pilot and main burner according to

the instructions in the user’s manual.

Check whether the pilot light is

properly positioned above the main

burner and is not covered by chips, an

imitation log or pebbles.

Check the ignition of the main burner

at full mark or low mark.

(the ignition should take place quickly

and easily).

7.2 Checking for gas leakage

Check all connections and joins for possible

gas leaks by means of a gas leak detector or

spray.

7.3 Checking the burner pressure and the

pre-pressure

Check that the burner pressure and the inlet

pressure correspond to the data stated in this

manual, chapter 14 “Technical data”.

Measuring the inlet-pressure:

Turn off the gas control tap.

Open the pressure gauge nipple A (see

figure 1.4) a few turns and connect a

pressure gauge hose to the gas control

valve.

Carry out this measurement when the

appliance is on at full gas mark and

when it is on the pilot light.

If the inlet pressure is too high you

are not permitted to connect the

appliance.

Measuring the burner pressure:

Only perform this measurement if the inlet-

pressure is correct.

Open the pressure gauge nipple B (see

fig. 1.4) a few turns and connect a

pressure gauge hose to the gas control

valve.

The pressure must correspond with

the value indicated in the technical

info of this manual (Chapter 13). In

case of deviations, get in touch with

the manufacturer.

Please note:

Close the pressure gauge nipples and

check these for gas leaks.

7.4 Checking the flame picture

Allow the appliance to burn for at least 20

minutes at full and then check the flame

picture for:

1. Distribution of the flames.

2. Colour of the flames.

If either one or both points are unacceptable,

then check:

The positioning of the imitation logs

and/or the quantity of pebbles or

chips on the burner.

The connections of the Flue materials

for leakage (in case of blue flames)

Whether the correct flue restrictor

has been mounted.

The outlet:

oWall terminal is installed

correctly

oRoof terminal is fitted and

sited correctly

oThe flue system is correctly

calculated.

7.5 Flue gas analyser

With CO/CO2 measure equipment you have

the possibility to measure the quality of the

flue gases and fresh air.

There are two measure points between the

glass and build-in frame.

One for measuring the air intake B (fig. 2.6)

and one for the flue gases A. (fig. 2.6).

The ratio of CO2 and CO level may not exceed

1:100.

Example:

If CO2 is 4,1 % max CO 410ppm

If the ratio exceeds 1:100 or flue gases are

measured in the fresh air you should also

check the above points.

8 < <<<

8Instructing the client

Recommend that the appliance be

serviced annually by a competent

person in order to guarantee a safe

use and a long lifespan.

Advise and instruct the client about

maintenance and cleaning of the

glass. Emphasize the risk of burning in

fingerprints.

Instruct the client about the

operation of the appliance and the

remote control unit, including the

replacement of the batteries and

adjusting the receiver for initial use.

Hand over to the client:

oInstallation manual

oUser’s manual

oImitation logs instruction card

oSuction lifters

9Annual maintenance

9.1 Service and cleaning:

Check and clean if necessary after

checking:

oThe pilot light

oThe burner

oThe combustion chamber

oThe glass

oThe logs for possible fractures

oThe outlet

Replace if necessary:

ochips/embers.

9.2 Cleaning the glass

Most of the deposits can be removed with a

dry cloth. Clean the glass with Faber glass

polish.

Note:

prevent fingerprints on the glass. these will

be burned into it once the appliance is used

and cannot be removed anymore!

Carry-out the check-up according to the

instructions in chapter 7 “checking the

installation’.

10 Conversion to a different type of

gas (e.g. propane)

This can only be done by installing the proper

burner unit. for this purpose get in touch with

your supplier.

Always mention the type and serial number of

the appliance when ordering.

9 < <<<

11 Calculation of flue system

A simple way to calculate whether the

exhaust configuration is possible in

combination with your fire, use the free

“Faber Flue App” and download it from:

INTERNET:

BlackBerry, Android, PC (Windows Store)

APP store:

iPhone, iPad and Mac.

Google Play:

Android smartphones and Android tablets.

Alternatively use the exhaust calculation

table (see chapter 13).

The alternatives of outlet lengths and any

restrictors are set out in the restrictor table,

see 11.1. In the table we work with start

length (STL), total vertical height (TVH) and

total horizontal length (THL).

Start length (STL):

This is the first part that is placed on the fire

and represents a certain value (fig. 12.1, 12.2

and 12.3 A, N and F). This value is in the top

row of the table (see restrictor table 11.1 and

11.2).

Total vertical height (TVH):

TVH is the difference in height measured from

the top of the unit to the outlet; it can be

measured or determined from the building

plan. For clarification see the TVH indication

in the drawings (fig. 12.1, 12.2 and 12.3).

Total horizontal length (THL):

THL is the total horizontal length and consists

of elbows and pipes which are entirely in the

horizontal plane. Elbows I, K and Q and the

elements H, J, L, M, P and R (fig. 12.1 and

12.2).

Length horizontal plane:

The horizontal length consists of the elements

H, J, L, M, P and R (fig. 12.1 and 12.2).

Elbows 90° in the horizontal plane:

Horizontal bends are bends which are entirely

in the horizontal plane (fig. 12.1, 12.2 and

12.3 I, K and Q).

Bends 45° or 30° in the horizontal

plane:

Horizontal bends are bends which are entirely

in the horizontal plane.

Elbows 90° vertical to horizontal

plane:

These are 90° elbows, which proceed from

horizontal to vertical (fig. 12.2 and 12.3 G, O

and S).

Bends 45° or 30 °vertical to

horizontal plane:

These are 30° or 45° bends with a vertical

offset of less than 45° (fig.12.1 B and D).

Pipes under a tilt angle:

These are pipes which are vertically

ascending at an angle of 30° or 45° (fig. 12.1

C). Fill in only in combination with at least 2x

30 or 45° bends in the vertical part.

Restrictor table (see 11.1):

See the restrictor table at the right vertical

(TVH) and horizontal length (THL).

For “x” and if the values are outside the

table, then the combination is not allowed.

Only then adjust the TVH or THL.

If a value is indicated, check that the

calculated STL value is not lower than

indicated in the table. In this case STL must

be adjusted.

The found value indicates the width of the

restrictor (“0” means no restrictor).

Generally a 30mm restrictor is pre-installed

(fig. 2.5).

Note:

When only a vertical flue length is used, than

you most install the additional air restrictor

under in the appliance (see fig. 4.1 up to

4.4).

Other manuals for Fyn 600

Table of contents

Other Faber Indoor Fireplace manuals

Faber

Faber VASKA C11 User manual

Faber

Faber VASKA B11 User manual

Faber

Faber Lumina User manual

Faber

Faber CAS500 User manual

Faber

Faber Clear User manual

Faber

Faber Concept l-450 User manual

Faber

Faber MatriX 450 Series User manual

Faber

Faber Duet XL User manual

Faber

Faber NIVA NV20BL User manual

Faber

Faber Torch framed User manual

Faber

Faber e-MatriX 1050/400 I User manual

Faber

Faber Relaxed Premium M User manual

Faber

Faber Blokhus 40011609-1545 User manual

Faber

Faber Relaxed Premium L User manual

Faber

Faber Marssum User manual

Faber

Faber Honest User manual

Faber

Faber E-SLIM LINEAR 1200/450 I User manual

Faber

Faber Jelling opti-myst User manual

Faber

Faber BASKET BSK20 User manual

Faber

Faber NIGHT 13 User manual

Faber

Faber Concept III-700 User manual

Faber

Faber e-MatriX 800-500 I User manual

Faber

Faber Aspect Premium ST L User manual

Faber

Faber SILENCE Assembly instructions

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
