Ezgo 622014 User manual
622014
Owner’s Guide
ISSUED JULY 2011 REVISED APRIL 2013
WELCOME
Thank you for purchasing this vehicle. Before driving the vehicle, we ask you to spend some time reading this
Owner’s Guide. This guide contains the information that will assist you in maintaining this highly reliable vehicle.
Some illustrations may show items that are optional for your vehicle. This guide covers the operation of several vehi-
cles; therefore, some illustrations may not represent your vehicle. Physical differences in controls will be illustrated.
Most of the service procedures in this guide can be accomplished using common, automotive hand tools. Contact
your service representative on servicing the vehicle in accordance with the Periodic Service Schedule.
Repair or replacement parts are available through your E-Z-GO retailer or E-Z-GO Genuine Service Parts.
The following information is needed when contacting E-Z-GO concerning service or parts for your vehicle:
Vehicle Model ____________________________________________________________________________
SERIAL Number / PIN Number / VIN Number __________________________________________________
Page i
FOREWORD
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
OWNER’S GUIDE
48 V ELECTRIC POWERED VEHICLE
EXPRESS S4
EXPRESS L4
STARTING MODEL YEAR 2012
Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed
beyond the factory specifications. Such modifications can cause serious personal injury or death. E-Z-GO Division of Textron, Inc. pro-
hibits and disclaims responsibility for any such modifications or any other alteration which would adversely affect the safety of the vehi-
cle.
E-Z-GO Division of Textron, Inc. reserves the right to incorporate engineering and design changes to products in this manual, without
obligation to include these changes on units sold previously.
The information contained in this manual may be revised periodically by E-Z-GO Division of Textron, Inc., and therefore is subject to
change without notice.
E-Z-GO Division of Textron, Inc. DISCLAIMS LIABILITY FOR ERRORS IN THIS MANUAL, and SPECIFICALLY DISCLAIMS LIABILITY FOR
INCIDENTAL AND CONSEQUENTIAL DAMAGES resulting from the use of the information and materials in this Manual.
These are the original instructions as defined by 2006/42/EC.
TO CONTACT US
E-Z-GO Division of Textron Inc.
1451 Marvin Griffin Road.
Augusta, Georgia, USA 30906-3852
North America:
Technical Assistance & Warranty PHONE: 1-800-774-3946 FAX: 1-800-448-8124
Service Parts PHONE: 1-888-GET-EZGO (1-888-438-3946) FAX: 1-800-752-6175
International:
PHONE: 001-706-798-4311 FAX: 001-706-771-4609
FOREWORD
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
Page ii
This vehicle has been designed and manufactured in the United States of America (USA).
The Standards and Specifications listed in the following text originate in the USA unless oth-
erwise indicated.
The use of non-Original Equipment Manufacturer (OEM) approved parts may void the war-
ranty.
Failure to properly maintain batteries may void the warranty. Refer to the battery manual for
instructions on the proper maintenance and care of the batteries.
BATTERY PROLONGED STORAGE
All batteries will self-discharge over time. The rate of self-discharge varies depending on the
ambient temperature, the age and condition of the batteries.
A fully charged battery will not freeze in winter temperatures unless the temperature falls
below -75°F (- 60°C).
For winter storage, the batteries must be clean, fully charged and disconnected from any
source of electrical drain.
The battery charger may be left connected to the vehicle to maintain a full charge on the bat-
teries, provided the charger is plugged into an active electrical source. If power to the elec-
trical source is disconnected or interrupted the battery charger will continue to check the
charge on the battery pack, this will draw power from the battery pack and eventually drain
the batteries if power is not restored in a timely manner.
As with all electric vehicles, the batteries must be checked and recharged as required or at a
minimum of 30 day intervals.
Page iii
TABLE OF CONTENTS
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
SECTION PAGE NO.
SAFETY............................................................................................................................................................................... 1-1
GENERAL SPECIFICATIONS............................................................................................................................................. 2-1
INTRODUCTION.................................................................................................................................................................. 3-1
OPERATING PROCEDURES.............................................................................................................................................. 4-1
MAINTENANCE................................................................................................................................................................... 5-1
DELCARATION OF CONFORMITY ................................................................................................................ APPENDIX A-1
Page iv
TABLE OF CONTENTS
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
Notes:
1 - 1
SAFETY
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
1
TITLE PAGE NO.
SAFETY................................................................................................................................................................. 1-3
NOTICES, CAUTIONS, WARNINGS, AND DANGERS......................................................................................... 1-3
GENERAL ............................................................................................................................................................. 1-4
GENERAL OPERATION ....................................................................................................................................... 1-5
MAINTENANCE .................................................................................................................................................... 1-5
VENTILATION ....................................................................................................................................................... 1-6
LABELS AND PICTOGRAMS ............................................................................................................................... 1-7
1 - 2
SAFETY
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
Notes:
1
1 - 3
SAFETY
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
1
SAFETY
For any questions on material contained in this manual, contact an authorized representative for clarification.
Read and understand all labels located on the vehicle. Always replace any damaged or missing labels.
On steep hills it is possible for vehicles to coast at greater than normal speeds encountered on a flat surface. To pre-
vent loss of vehicle control and possible serious injury, speeds should be limited to no more than the maximum
speed on level ground. See GENERAL SPECIFICATIONS. Limit speed by applying the service brake.
Catastrophic damage to the drivetrain components due to excessive speed may result from driving the vehicle above
specified speed. Damage caused by excessive speed may cause a loss of vehicle control, is costly, is considered
abuse and will not be covered under warranty.
Use extra caution when towing the vehicle. Do not tow a single vehicle at speeds in excess of 12 mph (19 kph). If the
vehicle is to be used in a commercial environment, signs similar to the ones illustrated should be used to warn of sit-
uations that could result in an unsafe condition.
Observe these NOTICES, CAUTIONS, WARNINGS and DANGERS; be aware that servicing a vehicle requires
mechanical skill and a regard for conditions that could be hazardous. Improper service or repair may damage the
vehicle or render it unsafe.
NOTICES, CAUTIONS, WARNINGS, AND DANGERS
Throughout this guide NOTICE, CAUTION, WARNING, and DANGER will be used. Please observe these NOTICES,
CAUTIONS, WARNINGS, and DANGERS; be aware that servicing a vehicle requires mechanical skill and a regard for
conditions that could be hazardous. Improper service or repair may damage the vehicle or render it unsafe.
Address practices not related to personal injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WASH HANDS
AFTER HANDLING!
Battery posts,
terminals and related
accessories contain
lead and lead compounds,
chemicals known
to cause cancer and
reproductive harm.
BATTERY WARNING
WASH HANDS
AFTER HANDLING!
WARNING: Battery posts, terminals and related
accessories contain lead and lead compounds,
chemicals known to cause cancer and reproductive harm.
BATTERIES
CONTAIN LEAD
AND RELATED PARTS
!
<
14
°
25
%
DO NOT
DRIVE ACROSS
SLOPES IN
EXCESS OF 14˚
NOTICE
DANGER
SAFETY
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
1 - 4
1
This manual has been designed to assist in maintaining the vehicle in accordance with procedures developed by the
manufacturer. Adherence to these procedures and troubleshooting tips will ensure the best possible service from the
product. To reduce the chance of personal injury or property damage, the following must be carefully observed:
Certain replacement parts can be used independently and/or in combination with other accessories to modify an E-
Z-GO-manufactured vehicle to permit the vehicle to operate at or in excess of 20 mph. When an E-Z-GO-manufac-
tured vehicle is modified an any way by the Distributor, Dealer or customer to operate at or in excess of 20mph,
UNDER FEDERAL LAW the modified product will be a Low Speed Vehicle (LSV) subject to the strictures and
requirements of Federal Motor Vehicle Safety Standard 571.500. In these instances, pursuant to Federal law the
Distributor or Dealer MUST equip the product with headlights, rear lights, turn signals, seat belts, top, horn and all
other modifications for LSV’s mandated in FMVSS 571.500, and affix a Vehicle Identification Number to the product
in accordance with the requirements of FMVSS 571.565. Pursuant to FMVSS 571.500, and in accordance with the
State laws applicable in the places of sale and use of the product, the Distributor, Dealer or customer modifying the
vehicle also will be the Final Vehicle Manufacturer for the LSV, and required to title or register the vehicle as man-
dated by State law.
E-Z-GO will NOT approve Distributor, Dealer or customer modifications converting E-Z-GO products into LSV’s.
The Company recommends that all E-Z-GO products sold as personal transportation vehicles BE OPERATED ONLY
BY PERSONS WITH VALID DRIVERS LICENSES, AND IN ACCORDANCE WITH APPLICABLE STATE REQUIRE-
MENTS. This restriction is important to the SAFE USE AND OPERATION of the product.
All customers should adhere to this SAFETY RESTRICTION, in connection with the use of all E-Z-GO products, new
and used, the Distributor or Dealer has reason to believe may be operated in personal transportation applications.
Information on FMVSS 571.500 can be obtained at Title 49 of the Code of Federal Regulations, section 571.500, or
through the Internet at the website for the U.S. Department of Transportation - at Dockets and Regulation, then to Title
49 of the Code of Federal Regulations (Transportation)
GENERAL
All vehicles can be used for a variety of tasks beyond the original intended use of the vehicle; therefore, it is impossible
to anticipate and warn against every possible combination of circumstances that may occur. No warning can take
replace good common sense and prudent driving practices.
Good common sense and prudent driving practices do more to prevent accidents and injury than all of the warnings
and instructions combined. E-Z-GO strongly suggests that all users and maintenance personnel read this entire man-
ual paying particular attention to the CAUTIONS, WARNINGS and DANGERS contained therein.
If you have any questions regarding this vehicle, contact your E-Z-GO dealer or write to the address on the back cover
of this publication, Attention: Customer Care Department.
E-Z-GO reserves the right to make design changes without obligation to make these changes on units previously sold.
The information contained in this manual is subject to change without notice.
E-Z-GO IS NOT LIABLE FOR ERRORS IN THIS MANUAL. E-Z-GO IS NOT LIABLE FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES THAT RESULT FROM THE USE OF THE MATERIAL IN THIS MANUAL.
This vehicle conforms to the current applicable standard(s) for safety and performance requirements.
These vehicles are designed and manufactured for off-road use. They DO NOT conform to Federal Motor Vehicle
Safety Standards of the United States of America (USA) and are not equipped for operation on public streets. Some
communities may permit these vehicles to be operated on their streets on a limited basis and in accordance with local
ordinances.
