Congratulations on purchasing your Urban S electric motorcycle! Welcome to the Evoke Motorcycle
rider community. This manual will provide you with a better understanding of your motorcycle’s op-
eration and basic maintenance requirements.
Evoke is constantly improving product design and quality. Therefore, this manual contains the most
current product information available at the time of printing.
If you choose to sell your Evoke Urban S, remember to pass this manual to the new owner, as it is an
important part of the vehicle.
On behalf of all the Evoke team, we wish you an amazing journey and open, clear roads!
Have questions concerning operation or maintenance of your motorcycle?
Contact us!
Email: [email protected]
WeChat: Evokemotorcycles
Important Message from Evoke

8
General Information
Important labels and locations
Caution indicates that minor or
moderate injury could happen.
Warning indicates that serious
injury or death may result.
Danger indicates that serious
injury or death will occur.
Evoke Urban S motorcycle series is an electric
motorcycle. As such, there are warnings you
should be aware of when touching or discon-
necting elements.
These labels indicate that the user should take
precautions to avoid harm, and are frequently
seen in the following areas:
•Main Power Connection
•Phase Wire Connection
•Battery Charger
•Battery Box

9
Improper accessories or modications can cause a
crash in which you can be seriously hurt or killed.
Follow all instructions in this owner’s manual re-
garding accessories and modications.
We strongly advise you not to remove any orig-
inal equipment or modify your Urban S in any
way that would change its design or operation.
Such changes could seriously impair your Urban
S handling, stability, and braking, making it un-
safe to ride.
Removing or modifying your lights or other
equipment can also make your Urban S illegal.
Accessories and Modifications
General Information

10
At Evoke, we want all riders to have a great time
on their bikes, while also keeping in mind these
precautions to avoid harm to yourself, your bike,
others, and the environment:
1. Wear protective-grade clothing
•It could save your life!
2. Ride defensively
•Give yourself time and space to respond to
other motorist’s actions.
3. Be visible
•Other motorists may have diculty seeing
and reacting to motorcycles; always ride
in the part of the lane where you are most
likely to be seen.
4. Know your bike and how to use it
•Get formal training on motorcycle opera-
tion and take refresher courses.
5. Never drive while under the inuence
•Drugs and alcohol impair judgement and
reaction speed, putting you and other mo-
torists in danger.
6. Always follow road rules
•This includes speed limits, using proper
signaling, and avoiding weaving between
lanes or other motorists.
7. Use caution in adverse weather condi-
tions
•Your bike and other vehicles need twice the
distance to stop in adverse weather condi-
tions.
Safety precautions
General Information
