EVBIKE EVBIKE-SET-CMS User manual
INSTALLATION MANUAL
Mid-Drive Electric Bicycle Kit
EVBIKE-SET-CMS
EVBIKE-SET-CMS-48
EVBIKE-SET-CMS-68
EVBIKE-SET-CMS-100
Thank you for purchasing EVBIKE product and we hope that you will become a happy user.
Carefully read the enre manual prior to installaon and rst use!
If you nd any fact in the manual that would prevent you from using our product, please contact your reseller for
further discussion and keep the original packaging. The reseller will advise you how to proceed properly.
Note: This user manual was translated from the Czech original.
CAUTION
EVBIKE SET IS SOLD AS THE CONVERSION KIT. SAFETY AND COMPLIANCE WITH LEGISLATIVE
REQUIREMENTS OF THE FINAL PRODUCT IS FULLY GUARANTEED BY THE OPERATOR OF A BIKE
OR WHOEVER BUILT AND THAN SOLD THE CONVERSED BIKE. WE RECOMMEND THAT YOU
ENTRUST CONVERSION OF THE BIKE TO AN AUTHORIZED SERVICE CENTER.
PLEASE READ CAREFULLY THIS INSTALLATION MANUAL BEFORE YOU WILL START EVBIKE
CONVERSION.
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
TABLE OF CONTENTS
1. Central motor installaon
2. Installaon of LCD display, le brake, accelerator and wheel speed sensor
3. Baery installaon
4. Diagnosc of malfuncons and service
5. Usage
6. Maintenance
SPECIFICATIONS
EVBIKE-SET-CMS-48 EVBIKE-SET-CMS
Motor power: 750 W 250 W
Motor torque: nominal 70, peak 100 Nm nominal 50, peak 80 Nm
Designed for baery voltage: 48 V 36 V
Motor weight: 3,8 kg 3,7 kg
Water-Dust protecon: IP65 IP65
Operang temperature range: -25°C ~ 55°C -25°C ~ 55°C
Maximum speed: 25 km/h (limiter turned ON) 25 km/h (limiter turned ON)
EVBIKE-SET-CMS-68 EVBIKE-SET-CMS-100
Motor power: 1000 W 1000 W
Motor torque: nominal 130, peak 160 Nm nominal 130, peak 160 Nm
Designed for baery voltage: 48 V 48 V
Motor weight: 4,8 kg 4,8 kg
Water-Dust protecon: IP65 IP65
Operang temperature range: -25°C ~ 55°C -25°C ~ 55°C
Maximum speed: 25 km/h (limiter turned ON) 25 km/h (limiter turned ON)
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
PACKAGE CONTENT
for sUccesfUl assemBlY of eVBiKe, YoU Will also Need folloWiNg:
— ribbons for cables fastening
— screws, nuts, washers
— special bo om bracket tools (see pictures a, b, c)
— basic technical skills
1 a - Compact
Crank Puller
Picture 1
1 b - Casse e Lockring
Remover Tool
1 c - Tool for easy assembly
of bo om bracket lock rings
Motor unit
Main wiring harness 2x Brake leverAccelerator
M8 nut
M33 Fixing plateM6
Cranks
M5
Chainwheel
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
1 CENTRAL DRIVE UNIT INSTALLATION
5x M5 Nut.
Teeth facing
toward
the engine.
Insert motor into
the hole for boom
bracket cartridge.
Chainwheel will be
on the right side
(the driving direcon)
Higher surface.
1) Fasten chainwheel onto the main drive. Chainwheel is fastened on the motor, so that the teeth facing toward the
engine (see picture).
2) Remove the original boom bracket including cartridge and cups. Use special boom bracket tools (see pictures
1 a, b). Remove the derailleur, if the bike is ed with it. The interior thoroughly clean and make sure that nothing
prevents inseron of the motor. Axle of the motor must go slip freely.
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
5 mm
In the case of using a frame for the boom bracket of width 68-72 mm,
you must ll space between the engine and xing washer using a ring or
nuts (not included in package).
For instalaon on bike with central axle 100 mm is necessary to use
special motor with 100 axle for correst instalaon.
* Motor CMS-100 is central axle 100 mm.
The surface with teeth of xing plate towards inside, then x the plate on drive unit with 2pcs M6 Nuts.
OK WASHER NEEDED
68 mm
100 mm *
75 mm
107 mm
Fixing plate with teeth. 2x M6 Nut. Teeth of the xing plate must face
towards the bicycle frame!
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
Now gently pull the motor towards the bicycle frame and ghten the rst M33 nut onto axle tube with maximal
force. You can also use glue for nuts. Then ghten the second nut onto axle tube. The movement and ghten
second M33 nut with force againts rst (so called „contra nut“). Use special tool (see picture 1c).
In the case of using a frame for the boom bracket
of width 73 mm (105 mm), is possible to install
only one M33 nut.
Is recommended to secure nut with a special
glue for screws (not included in package).
M33 Nut.
Contra M33 Nut.
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
Now place the le and right crank (watch the label L and R) and ghten M8 nuts with reasonable force
aer 50-100 km check the nuts. Aer ghtening, install pedals (watch out for right and le-hand thread).
Le Crank.
Right Crank. M8 Nut.
M8 Nut.
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
2 INSTALLATION OF CONTROLS AND SPEED SENSOR
First remove the original equipment from le side of the handlebar. Grip, the brake lever and shier. In reverse
order mount LCD display, LCD controller, accelerator, brake lever and grip. LCD controller and accelerator can be
oponally installed on the right side of the handlebar.
Brake lever
Grip
Handlebar
LCD controller LCD display
LCD display holder
Brake lever
Right side
Aer installing all controls, connect their connectors to the main harness.
Fasten Speed Sensor to the frame of the rear fork in an appropriate place so between the sensor and the magnet is
not a distance greater than 5 mm. Now install the magnet on the spoke and set it, his magnec side,
to the sensor. Check, that the distance is 5 mm. If the sensor and magnet are installed correctly, when rotang the
LED on the sensor is acvated and ashes when passing through the magnet.
Connect controllers to the main harness
and then connect the connector from
motor unit.
Accelerator
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
Connect sensor connector with
output from the motor unit.
Fasten or underlay and make sure, that distance between
the magnet and the sensor is not greater than 5 mm.
NOTICE
The manufacturer reserves
the right to change shape and
appearance of the sensor.
Its funconality will not be
aected. Therefore, the
appearance may dier from
those illustrated in this manual
this is not a defect of the
product.
www.EVBIKE.cz
Importer: GWL Power a.s., EU-VAT ID: CZ25948253
