EuroSteam 4203 User manual
1
MODEL 4203
Instruction Manual
ITALIAN DESIGN
Eurosteam®is a registered trademark of 974514 AB Ltd.
CANADA: 1-877-387-7770 USA: 1-877-462-5757
www.redfernent.com
EN
ES
FR
Leaders in Professional Marketing and Demostrating
2
EUROSTEAM® MULTI PRO STEAMER
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WHEN USING ANY ELECTRICAL APPLIANCE BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE
USED.
IMPORTANT SAFEGUARDS
READ THESE INSTRUCTION BEFORE USE
WARNING:
1. The Eurosteam® Multi Pro Steamer is for household/residential use ONLY.
2. DO NOT immerse in liquids. ALWAYS turn o and unplug when lling with water.
3. Never leave the appliance unattended when connected to the power supply; unplug it after
every use.
4. Never point steam jets in the direction of people, animals or plants or towards appliances that
contain electrical parts (e.g., oven interiors).
5. Do not use if power cord or plug has been damaged or if any part has been dropped or damaged.
6. Do not attempt to disassemble or repair appliance. Warranty will be null and void if attempted.
7. Never carry by the cord or yank cord to unplug from outlet. To unplug grasp plug to remove
from outlet.
8. Do not handle with wet hands.
9. Keep cord away from heated surfaces as well as sharp edges and corners.
10. Always connect the appliance to a properly earthed socket.
11. Before lling with water or emptying always turn o, unplug and let cool.
12. IMPORTANT: danger of scalds.
NEVER OPEN the cap on the boiler tank DURING USE.
IMPORTANT: Before unscrewing the cap on the boiler tank, proceed as follows:
- switch o the appliance at the main switch and unplug the power cord from the mains
socket;
- bleed out the remaining pressure from the boiler tank, using the steam button on the gun
and pointing the jet into a suitable container;
- leave the appliance to cool for a few minutes;
- slowly loosen the boiler tank cap, part of the way and wait for a few seconds;
- unscrew the cap completely and remove it.
13. Contact with hot metal parts, hot water or steam may cause burns.
14. Be sure that boiler cap is and remains closed during use.
15. NEVER use cleaning solutions, perfumes, oils or chemicals in boiler.
16. Use only City tap, spring or bottled water in boiler. (Not well water)
17. Do not operate near ammable liquids or in areas with fumes.
18. Plug into a standard 120V, 60Hz electrical outlet only. Do not use with extention cords.
19. Store in a cool dry location.
20. If damaged contact Redfern Enterprises Customer Services for repair information.
21. This appliance is not suitable for use by people – including children – with reduced physical,
sensorial or mental capabilities; by people with little or no experience or awareness of the appli-
ance, unless carefully supervised or trained in the use of the appliance by a person responsible
for their safety.
22. It is necessary to supervise children to make sure that they do not play with the appliance.
3
Contact Redfern Enterprises for all Customer Service Inquiries
CANADA
1-877-387-7770
info@redfernent.com
USA
1-877-462-5757
infous@redfernent.com
info@redfernent.com
* Always drain condensed water from hose before use or if the unit has been sitting for any
period of time. To drain hose, direct nozzle into a sink or container and depress steam button.
* Always use extreme care when opening the boiler cap as it may become hot during use and
escaping steam can cause scalding and burns.
*IMPORTANT*
EUROSTEAM® MULTI PRO STEAMER
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
23. Before using the product, make sure that all items, surfaces and fabrics to be cleaned are resist-
ant to or compatible with the high temperature of the steam. Specically, treated terracotta
ooring,wooden surfaces or delicate fabrics, such as silk or velvet, should not be treated with-
out rst consulting the instructions from the manufacturer and carrying out a test on a small
hidden sample part.
24. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL.
SAVE THESE INSTRUCTIONS
4
EUROSTEAM® MULTI PRO STEAMER MODEL 4203
Parts of Steamer
A. Boiler Tank Cap
B. Handle
C. Steam Ready Light
D. On/O Light
E. On/O Switch
F. Appliance Body
G. Gun Nozzle
H. Gun
I. Lock Switch
L. Dispenser Button
Eurosteam® Multi Pro Steamer Unit
5
WHAT IS INCLUDED
What is Included
1. Extension Nozzle
2. Hood
3. Round Brush
4. Angled Nozzle
5. Upholstery Brush
6. Window Brush
7. Floor Brush
8. Extension Tubes
9. Attachment Bag
10. Funnel
11. Measure Cup
12. Floor Cloth
13. Upholstery Cloth
Attachments Included
*ALL ATTACHMENTS FIT THE EUROSTEAM® MINI PRO STEAMER*
MODEL 4203
Eurosteam® Multi Pro Steamer
CHECK ALL PARTS ON OPENING
6
ATTACHMENTS IN USE
Attachments
10 11
78 9
65
4
123
7
Filling the boiler tank before use
* Unscrew the boiler ller cap (A),ll the measure cup (11) to the ll line (DO NOT OVERFILL).
* Use funnel (10) provided to ll the boiler tank (1)
* Screw on the boiler tank cap (A).
* Plug unit into the wall outlet.
* Fit the required attachment to the gun (H).
Switching on
* Plug the appliance power cord into the wall outlet and switch on the appliance using the
On/O switch (E); the On/O light (D) will switch on as will the steam ready light (C) (2).
* After a few minutes, the steam ready light (C) will switch o to show that the boiler tank is
pressurised and the appliance can now dispense steam.
Operation
* The steam ready light (C) will switch on and o during use to show that the boiler tank is
working.
* To prevent the steam from being dispensed accidentally, the lock switch (I) must be moved
from the left to the right to unlock the steam function.
* To dispense the steam, press the button (L) on the gun (H).
* When using for the rst time, it is advised to spray the steam jet into a container to get rid of
any water residue that might be inside the tube (any water coming out is due to condensa-
tion inside the tube). This action needs to be repeated even after a few minutes of inactivity.
* When the gun (H) begins to dispense steam always point the jet downwards to the ground.
Switching o the steamer
* To stop dispensing steam, release the dispensing button (L).
* After use, switch o the appliance, using the switch (E) and unplug it from the outlet.
* Ret the gun (H) over the special handle (B), after placing the slider (I) in the lock position.
* Before unscrewing the cap on the boiler leave the unit to cool for 20-30 minutes.
* Slowly loosen the boiler tank cap part way and wait for a few minutes.
* Unscrew completely and remove cap.
INSTRUCTIONS FOR USE
Instructions for Use
When the Eurosteam® Multi Pro Steamer is not in use ALWAYS
lock the steam dispenser button with the switch (I)
*IMPORTANT*
*TIP: Fill with city tap water, spring water or bottled water. Do not use well water.*
8
ATTACHMENTS
Attachments
Extension Nozzle (1)
With this attachment it is possible to thoroughly clean all surfaces where dirt and germs take hold. The nozzle
can be tted directly to the gun nozzle (G) or the extension tubes (8): after lining up the marks on the gun noz-
zle (G) and the attachment, turn the nozzle 90° clockwise until it locks into place (4).
Hood (2)
This attachment can be tted to the gun nozzle (G) to protect the end.
Round Brush (3)
This attachment is for tting on the extension nozzle (1) and helps to dissolve the most stubborn dirt build up,
such as the type that forms on the cook top or in the grout widths between tiles. It can be used to clean bath-
room xtures, sinks and oven racks. It can also be used in showers and baths to remove all traces of scale (5)
Angled Nozzle (4)
This attachment can be tted to the gun nozzle (G) after inserting the cap (2) or extension nozzle (1). It is very
useful for reaching and cleaning in dicult areas such as vents, shutters, blinds and bathroom xtures.
Upholstrey Brush (5)
The fabric brush can be tted straight on the the gun nozzle (G) or to the extension tubes (8). When the cloth
(13) is tted, it is possible to use the brush to remove dust and for daily cleaning of sofas, armchairs, blankets,
mattresses and cushions (7). The brush can also be used to freshen up fabrics, removing all creases. Be sure to
discharge condensation from the hose into a containers so as not to wet fabrics.
Window Brush (6)
A window wiper brush can be tted to the fabric brush (5): to assemble the two, insert the tabs at the base
of the fabric brush into the hooks at the bottom of the window wiper brush. Use the window wiper brush to
clean windows, mirrors and glossy surfaces (9). Do not use the wiper brush if the surface to be cleaned is cold
as the change in temperature could cause the surface to break.
Floor Brush (7)
This is used on the extension tubes (8) and it has handy cloth grips that can hold the included cloth (13) as well
as any other type of machine washable cloth. To t the cloth, place the bush in the middle, lift the clips at the
ends of the brush, insert a ap of cloth and then release the clips (10).
Extension Tubes (8)
The extension tubes snap together and can be easily separated by pressing the release button. They are useful
for reaching high surfaces with the window wiper (6) or they can be used with the oor brush (7) (11).
Attachment Bag (9)
The Eurosteam® Multi Pro Steamer comes with this bag which is handy for storage as well as for keeping the
attachments close at hand while cleaning.
9
FILLING DURING USE & CLEANING
Filling & Cleaning
Filling the Boiler Tank During Use
If the boiler tank should become empty during use, switch o the unit and unplug from the wall outlet and
proceed as follows:
* Press the steam dispensing button (L) to discharge any residual steam;
* Slowly unscrew the boiler tank ller cap (A) waiting a few seconds for the steam to nish before unscrewing
the cap completely. Wait a few minutes before adding water to the boiler tank;
* Add more water; using the measure cup (11) with the funnel (10) inserted into the boiler, making sure to
pour it in slowly to prevent new bursts of steam from forming.
* It is recommended waiting at least 3 minutes from the time of unplugging the unit before adding more
water to the boiler tank;
* Firmly screw the boiler tank ller cap (A) back into place;
* Plug the unit into the wall outlet;
* Press the on switch (E) and wait for the lights to indicate that the unit is ready to use.
Cleaning and Maintenance
* It is important to clean the boiler tank at least once a month to remove any scale residues which could af-
fect the normal operation of the Eurosteam® Multi Pro Steamer.
* Switch o the unit and unplug from the wall outlet.
* Leave unit to cool before cleaning out the boiler tank to prevent the risk of scalds or burns.
* Drain out any pressure remaining in the boiler tank using the steam button (L) on the gun (H), being sure to
point the jet into a suitable container.
* Slowly unscrew the boiler tank ller cap (A) and remove it completely.
* Fill the boiler tank with tap water, shake vigorously and then turn upside down to empty.
* Repeat this process a few times.
* Never add scale removers, vinegar or other perfumed substances to the tank as these risk damaging the
unit and will immediately null and void the warranty.
TIPS
* To extend the life of your brushes, do not put excessive pressure on the brush. Let
the steam do the work and use the brush to loosen prior to wiping with a cloth.
* Be sure to store your Eurosteam® Multi Pro Steamer with the boiler tank empty and
the screw cap o. This will allow the boiler to breathe and minimize build up.
* Do not over ll your boiler. When over lled only hot water will come out of the noz-
zle until the water level is down enough to make steam.
* Always store your steamer away from animals and children, it is not a toy and may
be damaged if used for use other than intended.
10
TROUBLESHOOTING
PROBLEM CHECK POSSIBLE
CAUSES
POSSIBLE
REMEDY
No steam comes
out of the nozzle
Steam ready light
(C) on Cold boiler tank
Wait for the steam
ready light (C) to
switch off
No steam comes
out of the nozzle
Steam ready light
(C) off
No water in the
boiler tank
Fill the boiler tank
as described in the
paragraph «Filling
the boiler tank dur-
ing use» page 8
No steam comes
out of the nozzle
Steam ready light
(C) off – water in the
boiler tank
Malfunction
Contact Redfern
Enterprises
Canada
1-877-387-7770
USA
1-877-462-5757
The nozzle is
dispensing little
steam
Steam ready light
(C) on
The boiler tank is
cold
Wait for the boiler
tank to heat up
Troubleshooting
