Eureka 4750A - Lightweight No Touch Bag System Upright... User manual

What’s in the carton

STEP

Easy assembly

Slide vacuum back onto base.

Fasten with one long screw.

Slide tool caddy onto back.

Fasten with two short screws.

Slide handle onto tool caddy.

Fasten with one long screw.

Attach hose to vacuum back.

Fasten with two short screws.

STEP

Get ready to vacuum

Step on power switch to turn

on; step on again to turn off.

Step on handle release to

lower handle into position.

Push cord into top cord

retainer. Plug into outlet.

For accessories: Loosen lower

end of hose and attach tool.

STEP

Use a Phillips

screwdriver.

PROBLEM SOLVING

Refer to Owner’s Gui e.

MAINTENANCE SCHEDULE

Refer to back of ust cup or Owner’s Gui e.

QUICK START GUIDE

4750 Series

Before returning, call

Eureka Customer Service

HELPLINE

1-800-282-2886

8 a.m. to 7:30 p.m. (CST), Monday - Friday

10 a.m. to 6:30 p.m. (CST), Saturday - Sunday

www.eureka.com

Attach hose retainer with one

short screw. Pull retainer out

to position hose.

Pull up cord and push into

lower cord retainer. Wrap cord.

Place hose over

hose hook on handle.

Push end of hose into

opening on vacuum base.

Place dust cup on base

and snap into place.

Place wand/crevice tool in

holder on side of vacuum.

Place dusting brush on

back of handle.

Some models: Snap

Power Paw®into clip on front.

Vacuum Base Dust Cup

and Filter

Dust Bag

Style PL

Handle

Important Safeguards

Dusting

Brush

Hose

Retainer

Vacuum

Back

Tool Caddy

2 Long and

5 Short Screws

Hose

Extension

Wand and

Crevice Tool

REGISTRATION

WNER’S

GUIDE

Stair Hose

Ext-U Belt

SPECIAL FEATURES

Available on some models

Power Paw®

Handle

with

Power Paw®

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

Moving parts! Assemble the vacuum cleaner before using.

Do not use the vacuum cleaner without isposable

ust bag an motor filter in place.

Twist cover counter-clockwise

and lift off.

Place bag inside dust cup. Position holes in cardboard

collar over posts in cup.

Line up dust cup cover;

twist clockwise to lock.

PN81158_Lights BagQS.qx :front englsh 3/4/09 4:59 PM Page 1
