ESAB Origo Mig C170 3ph User manual

Origo™

Instruction manual

0463 344 101 GB 20220103 Valid for: serial no. 626-xxx-xxxx

MigC1703ph, MigC2003ph,

MigC2503ph

TABLE OF CONTENTS

0463 344 101 © ESAB AB 2022

1SAFETY ....................................................................................................... 4

1.1 Meaning of symbols ............................................................................... 4

1.2 Safety precautions ................................................................................. 4

2INTRODUCTION.......................................................................................... 7

2.1 Equipment ............................................................................................... 7

3TECHNICAL DATA ...................................................................................... 8

4INSTALLATION............................................................................................ 9

4.1 Location................................................................................................... 9

4.2 Assembly of components...................................................................... 9

4.3 Electrical installation ............................................................................. 10

4.4 Mains power supply ............................................................................... 10

5OPERATION ................................................................................................ 12

5.1 Connection and control devices ........................................................... 13

5.2 Welding without gas............................................................................... 13

5.3 Wire feed pressure ................................................................................. 14

5.4 Replacing and inserting wire................................................................. 14

5.5 Overheating protection .......................................................................... 14

6MAINTENANCE........................................................................................... 15

6.1 Inspection and cleaning......................................................................... 15

7TROUBLESHOOTING ................................................................................. 16

8ORDERING SPARE PARTS ........................................................................ 17

DIAGRAM ............................................................................................................ 18

ORDERING NUMBERS....................................................................................... 22

WEAR PARTS...................................................................................................... 23

ACCESSORIES ................................................................................................... 24

Rights reserved to alter specifications without notice.

1 SAFETY

0463 344 101 -4- © ESAB AB 2022

1 SAFETY

1.1 Meaning of symbols

As used throughout this manual: Means Attention! Be Alert!

DANGER!

Means immediate hazards which, if not avoided, will result in immediate,

serious personal injury or loss of life.

WARNING!

Means potential hazards which could result in personal injury or loss of life.

CAUTION!

Means hazards which could result in minor personal injury.

WARNING!

Before use, read and understand the instruction manual

and follow all labels, employer´s safety practices and

Safety Data Sheets (SDSs).

1.2 Safety precautions

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety

precautions must meet the requirements that apply to this type of equipment. The following

recommendations should be observed in addition to the standard regulations that apply to

the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the

equipment. Incorrect operation of the equipment may lead to hazardous situations which can

result in injury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

○ its operation

○ location of emergency stops

○ its function

○ relevant safety precautions

○ welding and cutting or other applicable operation of the equipment

2. The operator must ensure that:

○ no unauthorised person is stationed within the working area of the equipment

when it is started up

○ no-one is unprotected when the arc is struck or work is started with the

equipment

3. The workplace must:

○ be suitable for the purpose

○ be free from drafts

1 SAFETY

0463 344 101 -5- © ESAB AB 2022

4. Personal safety equipment:

○ Always wear recommended personal safety equipment, such as safety glasses,

flame-proof clothing, safety gloves

○ Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which

could become trapped or cause burns

5. General precautions:

○ Make sure the return cable is connected securely

○ Work on high voltage equipment may only be carried out by a qualified

electrician

○ Appropriate fire extinguishing equipment must be clearly marked and close at

hand

○ Lubrication and maintenance must not be carried out on the equipment during

operation

WARNING!

Arc welding and cutting can be injurious to yourself and others. Take precautions

when welding and cutting.

ELECTRIC SHOCK - Can kill

• Install and ground the unit in accordance with instruction manual.

• Do not touch live electrical parts or electrodes with bare skin, wet gloves or

wet clothing.

• Insulate yourself from work and ground.

• Ensure your working position is safe

ELECTRIC AND MAGNETIC FIELDS - Can be dangerous to health

• Welders having pacemakers should consult their physician before welding.

EMF may interfere with some pacemakers.

• Exposure to EMF may have other health effects which are unknown.

• Welders should use the following procedures to minimize exposure to

EMF:

○ Route the electrode and work cables together on the same side of

your body. Secure them with tape when possible. Do not place your

body between the torch and work cables. Never coil the torch or work

cable around your body. Keep welding power source and cables as

far away from your body as possible.

○ Connect the work cable to the workpiece as close as possible to the

area being welded.

FUMES AND GASES - Can be dangerous to health

• Keep your head out of the fumes.

• Use ventilation, extraction at the arc, or both, to take fumes and gases

away from your breathing zone and the general area.

ARC RAYS - Can injure eyes and burn skin

• Protect your eyes and body. Use the correct welding screen and filter lens

and wear protective clothing.

• Protect bystanders with suitable screens or curtains.

NOISE - Excessive noise can damage hearing

Protect your ears. Use earmuffs or other hearing protection.

1 SAFETY

0463 344 101 -6- © ESAB AB 2022

MOVING PARTS - Can cause injuries

• Keep all doors, panels and covers closed and securely in place. Have only

qualified people remove covers for maintenance and troubleshooting as

necessary. Reinstall panels or covers and close doors when service is

finished and before starting engine.

• Stop engine before installing or connecting unit.

• Keep hands, hair, loose clothing and tools away from moving parts.

FIRE HAZARD

• Sparks (spatter) can cause fire. Make sure that there are no inflammable

materials nearby.

• Do not use on closed containers.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

CAUTION!

This product is solely intended for arc welding.

WARNING!

Do not use the power source for thawing frozen pipes.

CAUTION!

Class A equipment is not intended for use in residential

locations where the electrical power is provided by the

public low-voltage supply system. There may be

potential difficulties in ensuring electromagnetic

compatibility of class A equipment in those locations,

due to conducted as well as radiated disturbances.

NOTE!

Dispose of electronic equipment at the recycling

facility!

In observance of European Directive 2012/19/EC on

Waste Electrical and Electronic Equipment and its

implementation in accordance with national law,

electrical and/or electronic equipment that has reached

the end of its life must be disposed of at a recycling

facility.

As the person responsible for the equipment, it is your

responsibility to obtain information on approved

collection stations.

For further information contact the nearest ESAB dealer.

ESAB has an assortment of welding accessories and personal protection equipment

for purchase. For ordering information contact your local ESAB dealer or visit us on

our website.

2 INTRODUCTION

0463 344 101 -7- © ESAB AB 2022

2 INTRODUCTION

Mig C170 3ph, Mig C200 3ph and Mig C250 3ph are step controlled power sources of a

compact design, intended for welding with solid steel, stainless steel or aluminium wire as

well as tubular wire with or without shielding gas. It is possible to weld with homogeneous

wire/shielding gas and weld with gasless tubular wire by switching the + and - connections on

the switching terminal by the wire feed unit.

ESAB accessories for the product can be found in the "ACCESSORIES" chapter of

this manual.

2.1 Equipment

The power source is supplied with:

• Welding torch

• Return cable with return clamp

• Shelf for gas cylinder

• Instruction manual

3 TECHNICAL DATA

0463 344 101 -8- © ESAB AB 2022

3 TECHNICAL DATA

Mig C170 3ph Mig C200 3ph Mig C250 3ph

Voltage 400–415 V,

3~50/60Hz

400–415 V,

3~50/60Hz

230/400–415 V,

3~50/60Hz

Permissible load at

100 % duty cycle 100 A 120 A 150 A

60 % duty cycle 130 A 150 A 190 A

35 % duty cycle 170 A 200 A 250 A

Setting range (DC) 30–170 A 30–200 A 40–280 A

Open circuit voltage 18.0–34.8 V 16.0–31.8 V 15.0–37.0 V

Open circuit power 310 W 210 W 340 W

Power factor at max load 0.97 0.97 0.94

Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz 42 V, 50/60 Hz

Wire feed speed 1.0–17 m/min 1.0–17 m/min 1.0–17 m/min

Burnback time 0.02–0.25 s 0.02–0.25 s 0.02–0.25 s

Spot welding 0.2–2.5 s 0.2–2.5 s 0.2–2.5 s

Welding torch connection EURO EURO EURO

Wire dimension range 0.6–0.8(Fe, SS) 0.6–1.0(Fe, SS) 0.6–1.2(Fe, SS)

1.0(Al) 1.0(Al) 1.0–1.2(Al)

0.8(FCW) 0.8–1.0(FCW) 0.8–1.2(FCW)

0.8–1.0(CuSi) 0.8–1.0(CuSi) 0.8–1.0(CuSi)

Max diameter/weight of

wire bobbin

300 mm/15 kg 300 mm/15 kg 300 mm/15 kg

Dimensions l×w×h 860x420x730 mm 860x420x730 mm 860×420×730 mm

Weight 67.5 kg 72.5 kg 82 kg

Operating temperature -10 to +40 °C -10 to +40 °C -10 to +40 °C

Transportation

temperature

-20 to +55 °C -20 to +55 °C -20 to +55 °C

Enclosure class IP 21 IP21 IP21

Application classification

Duty cycle

The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or

cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.

Enclosure class

The IP code indicates the enclosure class, i.e. the degree of protection against penetration

by solid objects or water.

Equipment marked IP21 is intended for indoor use.

Application class

The symbol indicates that the power source is designed for use in areas with increased

electrical hazard.

4 INSTALLATION

The installation must be carried out by a professional.

NOTE!

Connect the power source to the electricity mains with a network impedance of

0.268 (C250 3ph) ohm or lower. If the network impedance is higher, there is a risk of

flicker in the illuminators.

CAUTION!

This product is intended for industrial use. In a domestic environment this product

may cause radio interference. It is the user's responsibility to take adequate

precautions.

4.1 Location

Position the welding power source in such way that its cooling air inlets and outlets are not

obstructed.

4.2 Assembly of components

WARNING!

For packing and shipment of the power source the wheels are detached from

the unit.

Before use attach the wheels according to instruction.

4 INSTALLATION

4.3 Electrical installation

4.4 Mains power supply

Check that the unit is connected to the correct mains power supply voltage, and that it is

protected by the correct fuse size. A protective earth connection must be made, in

accordance with regulations.

Rating plate with supply connection data

Recommended fuse sizes and minimum cable area

Mig C170 3ph Mig C200 3ph Mig C250 3ph

Voltage V 400-415 V,

3~50/60 Hz

400-415 V,

3~50/60 Hz

230/ 400-415 V,

3~50/60 Hz

Current A

at 100% duty cycle 4.0 4.83 12.1/6.06

at 60% duty cycle 6.1 7.3 17.6/9.99

at 35% duty cycle 8.9 10.87 25.3/15.21

Other manuals for Origo Mig C170 3ph

This manual suits for next models

Table of contents

Other ESAB Welding System manuals

Popular Welding System manuals by other brands

Berner

Berner PLASMACUT 54 instruction manual

Pro Spot

Pro Spot PR-155 Assembly instructions

Forney

Forney 210 operating manual

Thermal Arc

Thermal Arc 400S operating manual

Lincoln Electric

Lincoln Electric HANDYMIG 170I Operator's manual

GYS

GYS PROTIG 201 AC/DC Original instructions

TAFA

TAFA 30*8B35 owner's manual

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Technical specifications

CIGWELD

CIGWELD 636804 use instructions

Red-D-Arc

Red-D-Arc DC-400 Operator's manual

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 owner's manual

Elettro

Elettro HI-MIG 3000 SYNERGIC instruction manual

WIA

WIA Weldmatic 270 CP132-2 Operator's manual

Sonics

Sonics H520T instruction manual

Miller

Miller Big Blue 400D owner's manual

NewArc

NewArc RT2000 Operational manual

Hypertherm

Hypertherm powermax1000 Operator's manual

Lincoln Electric

Lincoln Electric POWER WAVE I400 Operator's manual
