ERRECOM JET GUN User manual
ERRECOM SPA Via Industriale 14 - 25030 Corzano - (BS) - Italy - T: +39 030 9719096
errecom.com
JET GUN is a practical portable high-pressure machine with shoulder strap
specifically designed and tested to be used indifferently with acid / alkalin
cleaners, disinfectants and water for cleaning indoor and outdoor A/C units.
We recommand to use Jet Gun with Sanibact, the disinfectant for surfaces by
Errecom to sanitize not only AC/R systems but even other surfaces. In this case
JetGun should be combined with SaniGun - a special gun developed in order to
disinfect environments and granting the best efficiency of the treatment.
The 3 interchangeable bags – supplied together with JetGun – can be filled with
acid / alkaline cleaners, disinfectants or water. It can be interchanged quickly
according to the desired application.
JET GUN works with a recharcheable battery that allows the continous erogation
of 90 litres of the cleaning liquid. Thanks to its high pressure of 6 BAR (85psi) JET
GUN is able to increase its cleaning power without damaging the finned coils of
the internal and external parts of the system.
The brass nozzle allows to easily change diffusion mode from sprinkeling to
nebulization.
Portable High Pressure Cleaning Machine for AC/R Systems
-Portable high-pressure cleaning machine.
-Developed to clean with acid/alkaline cleaners,
disinfectants or water.
-Non-stop dispensing up to 90 litres.
-Developed to sanitize AC/R systems.
-Lightweight.
-Re-sealable bags.
Characteristics
Technical Characteristics
Jet Gun
JG
Non-stop dispensing up to 90 litres.
Rechargeable lead battery 12V - 2.200mAh.
Working pressure: 6 BAR (85 psi).
Lenght of the tube 300 cm.
No. 3 interchangeable re-sealable bags.
Regulable gun to easily change diffusion mode.
from sprinkeling to nebulization.
Battery charger 110-220V.
1Spreading gun with regulable brass nozzle.
2Circuit braker ON/OFF.
3Battery charging port.
4Zip battery pocket.
5Jack for battery placing.
Description of the Product
1
5
4
3
2
List of components
3 interchangeable bags up to 9 Litres
Battery charger 110 - 220 V with European plug
Instruction Manual
Spreading Gun with brass nozzle
ERRECOM SPA Via Industriale 14 - 25030 Corzano - (BS) - Italy - T: +39 030 9719096
errecom.com
1. Open the zip of JetGun.
2.
Rimove the internal bag unhooking the quick coupling without clining it to avoid the exit of the liquid.
3. Fill the bag with a cleaner or with water up to 3/4 of its refillable volume.
4. Relocate the bag into the inside and attack it with the quick coupling.
5. Turn on JetGun and switch down the botton.
6. Regular the nozzle of the gun to choose the mode of diffusion you desire.
7. Activate the gun for spreading.
Instructions
51 2 3 4 6 7
Packaging available
The boxes are fabricated in 100% recycled carton.
Box in carton containing:
- JetGun
- 3 re-sealable bags up to 9 litres
- Spreading Gun with brass nozzle
- Battery charger 110-220V with european plug
- Instruction manual
Art.-Nr. Description
VP1050.01 JetGun 01
Spare parts available
RPL001.01 Shoulder Strap -
FL1100.01 Bag -
R P 10 6 7. 01 Spreading Gun made with plastic -
RG9014.01 Gaskets for Quick Coupling with Spreading Gun in plastic -
R V6 0 3 7.0 1 Female Quick Coupling in plastic for black tube -
RV6038.01 Male Coupling in plastic to connect internal bag -
RV6039.01 Fem Coupling in plastic to connect internal bag -
TB1025.01 Tube made with black PVC - 3 mt. -
PW1005.01 Battery Charger EU for Jet Gun -
PW1008.01 Battery Charger USA for Jet Gun -
