Erbauer EPR710 User manual
EPR710
EAN: 3663602796282
ORIGINAL INSTRUCTIONS
710W router MNL_EPR710_TPS_GB_V2_BX220IM-10-8-2020
6/6/18 8:40 AM
2
Safety instructions 7
Product description 17
Assembly 20
Use 24
Care & maintenance 28
Guarantee 31
Declaration of conformity 32
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 2 6/6/18 8:40 AM
3
1
x1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 3 6/6/18 8:40 AM
4
Product description
1
14c
14 14b 14a
15c
15a 15
15b
16
1 2 3 4
5
7
13
12 1711
10
9
8
6
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 4 6/6/18 8:40 AM
5
A
17
12
10
1.
3.
2.
4.
B
2. 1.
4.
5.
6.
3.
13
14
C D
15c15a
15b 13
11
1. 3.
4.
6.
5.
2.
16
E F
ON
OFF
23
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 5 6/6/18 8:40 AM
6
G
3.
1.
2.
4. H
I J
K
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 6 6/6/18 8:40 AM
7
Safety instructions
GENERAL POWER TOOL SAFETY WARNING
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 7 6/6/18 8:40 AM
WARNING Read all safety warnings, instruc-
tions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching out-
lets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
8
4)
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 8 6/6/18 8:40 AM
an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
NOTE The term “residual current device (RCD)” can be replaced
by the term “ground fault circuit
interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
9
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 9 6/6/18 8:40 AM
part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove
the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s
10
SAFETY WARNINGS FOR ROUTER
c) The power tool shall not be wet or applied in wet
environment.
d) The voltage of the power source must agree with the
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 10 6/6/18 8:40 AM
operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of the
power tool for operations different from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces do
not allow for safe handling and control of the
tool in unexpected situations.
5) Service
a) Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
a) Hold the power tool by insulated gripping surfaces only,
because the cutter may contact its own cord. Cutting a
"live" wire may make exposed metal parts of the power tool
"live" and could give the operator an electric shock.
b) Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by your hand or against the body leaves it unstable
and may lead to loss of control.
