Epson PowerLite 1220 System manual

INSTALLATION HANDBOOK

Maintenance

Epson PowerLite 1220 / 1260

Replacing the Lamp

The life span of the projection lamp is about 4,000 hours if Power

Consumption in the Settings menu is Normal (default), and 5,000

hours if this setting is ECO. See page 88 to check the lamp usage.

It is time to replace the lamp when:

The projected image gets darker or starts to deteriorate.

The message Replace the lamp appears on the screen and the

Lamp light flashes orange. To maintain projector brightness

and image quality, replace the lamp as soon as possible.

note

Turn off this product when

not in use to prolong the life

of the projector.

You may also need to replace the lamp if the Lamp light flashes

red. See page 93.

Contact your dealer or call Epson at 800-GO-EPSON

(800-463-7766). Request part number V13H010L58.

Follow these steps to replace the lamp:

1. Turn off the projector and unplug the power cord.

2. Let the projector cool for at least an hour (if it has been on). The

lamp is extremely hot immediately after use.

3. Loosen the lamp cover screw (you cannot remove it). Then slide

the lamp cover off.

Lamp

light

warning

Let the lamp cool fully

before replacing it.

In the unlikely event that

the lamp has broken, small

glass fragments may be

present and should be

removed carefully to avoid

injury. If the projector has

been installed on the ceiling,

you should stand to the side

of the lamp cover, not

underneath it.

If the lamp is used after the

replacement period has

passed, the possibility that

the lamp may break

increases. When a lamp

replacement message

appears, replace the lamp

with a new one as soon as

possible, even if it is still

working.

INSTALLATION HANDBOOK

Maintenance

Epson PowerLite 1220 / 1260

4. Loosen the two screws holding the lamp in place (you can’t

remove them).

5. Hold the lamp as shown and pull it straight out.

6. Gently insert the new lamp. (If it doesn’t fit easily, make sure it is

facing the right way.) Then tighten its screws.

Loosen, but don’t

remove these screws

note

The lamp(s) in this

product contain mercury.

Please consult your state and

local regulations regarding

disposal or recycling. Do not

put in the trash.

7. Replace the lamp cover, then tighten its screw.

8. Reset the lamp timer as described in the next section.

note

Tighten the lamp cover

securely so you do not receive

a lamp cover error when you

turn the projector back on.

INSTALLATION HANDBOOK

Maintenance

Epson PowerLite 1220 / 1260

Resetting the Lamp Timer

After you replace the lamp, you need to reset the lamp timer using the

projector’s menu system.

1. Press the Menu button on the remote control or on the

projector’s control panel. You see the main menu.

2. Select the Reset menu and press Enter. You see this screen:

3. Select Reset Lamp Hours and press Enter.

4. When you see the prompt, select Yes and press Enter.

5. When you’re finished, press Menu to exit.

Checking Lamp Usage

To check the number of hours the lamp has been used, press the

Menu button and highlight the Info menu. You see a screen like this:

The life span of the lamp is about 4,000 hours if Power

Consumption in the Settings menu is Normal (default), and 5,000

hours if this setting is ECO. Make sure you have a spare lamp handy if

the usage hours on this menu are close to the life span of your lamp.

note

The information displayed

depends on the input signal

currently selected.

If you have used the

projector for less than

10 hours, the hours are

listed as 0H.
