EPOCH BATTERIES DP12120H User manual
DP12120H User Manual
Epoch Batteries
Lithium Iron Phosphate Battery with Smart Monitoring
Epoch Batteries
Address:164 Andrew Drive, Stockbridge GA 30281
Email: [email protected]
Web：https://www.epochbatteries.com/
2
Contents
1.Safety ________________________________________________________________4
1.1 Statement ________________________________________________________________4
1.2 Specification______________________________________________________________4
1.3 Critical safety info. ________________________________________________________4
1.4 Battery maintaining________________________________________________________5
1.5 Waste disposal ___________________________________________________________6
2.Installation___________________________________________________________6
2.1 Tools and Equipment ______________________________________________________6
2.2 Battery placement_________________________________________________________6
2.3 Battery supporting materials________________________________________________8
3.Introduction to Epoch DP series batteries _______________________________8
3.1 Main features_____________________________________________________________8
3.2 Product appearance._______________________________________________________9
3.3 Functional characteristics _________________________________________________15
3.4 Heating function _________________________________________________________16
4.Series and parallel connection of batteries _____________________________16
4.1 Introduction _____________________________________________________________16
4.2 Parallel usage ___________________________________________________________17
4.3 Serial usage_____________________________________________________________18
4.4 Simultaneous series and parallel___________________________________________19
4.5 Battery communication ___________________________________________________20
4.5.1 Communication terminal connection ________________________________________________20
3
4.5.2 Networking method: _____________________________________________________________21
4.5.3 APP interface display ___________________________________________________________23
5. Charging requirements _______________________________________________24
5.1 AC-DC charger___________________________________________________________24
5.2 Photovoltaic charging_____________________________________________________24
5.3 Charging with an AC generator through a DC-DC charger ____________________25
5.4 Recommended charging voltage ___________________________________________25
5.5 Passive balance function__________________________________________________25
6. Battery recycling ____________________________________________________25
7. Transportation and Storage ___________________________________________25
8. Warnings and reminders______________________________________________26
4
1.Safety
1.1 Statement
Please read this manual carefully before installation, operation, and maintenance, and pay attention to
various warning signs and statements on the equipment. After reading this manual, please keep it
properly for future reference.
1.2 Specification
This manual contents using the following symbols should be paid special attention to during operation.
Symbol
Statement
Attention, caution, warning: Reminder of precautions during
operation
Danger, Reminder that there is a risk of electric shock
during operation and protective measures need to be taken
Explanation or reminder, Matters that require special
explanation or reminder
1.3 Critical safetyinfo.
Before installing, operating, or maintaining the battery, the following operating and maintenance
instructions must be read.
Before installing
•It is very important and necessary to carefully read the user manual before installing or using
the battery. Failure to follow any instructions or warnings in this document may result in electric
shock, serious injury, or damage to the battery and the entire system.
•Before connecting the battery pack to your device, check the voltage and ensure that they
are within the limits of your device specifications. Failure to comply with these specifications will
voi d your warranty.
5
During installation:
•Personnel familiar with the electrical specifications of their country or region are required to in
stall battery packs. For optimal safety, please follow the steps described in this manual.
Battery operation:
•①Prohibit connecting batteries to different types of batteries；
•②Do not use faulty or mismatched chargers to charge the battery；
•③he environmental conditions specified in the product specification must be followed;
•④If the battery is found to be deformed, abnormally hot, or emitting an odor, please
immediately cut off the power and stop using it.
1.4 Battery maintaining
① Professional personnel should take care of the charging operation, ensure good contact
between the plug and socket during the charging process, ensure normal operation of the
charging equipment, and ensure good contact at all connection points of the battery pack. If there
is an abnormality, it needs to be repaired before charging;
②If there is a large amount of dust, metal shavings, or other debris on the upper cover and
pole of the battery pack, clean it with Vacuum cleaner a timely manner to avoid using water or
objects soaked in water for cleaning;
③Try to avoid splashing water or other conductive objects onto the battery cover and pole
during charging and discharging, such as when exposed to heavy rain for use;
④Estimate the charging and discharging time of the battery or battery pack based on its actual
usage status. Pay attention to observing whether there are any abnormalities in the battery or
battery pack at the end of charging and discharging, such as voltage difference issues;
⑤Check whether the conductive strip, voltage collection terminal, and other nodes are loose,
detached, rusted, or deformed, ensuring that the batteries used in series or parallel connection
are fixed and reliable (once/3 months);
6
1.5 Waste disposal
Please handle packaging and replace components in accordance with the law
s and regulations of the country or region where the battery pack is located.
Do not mix batteries with daily life.
Dispose of garbage together
2. Installation
2.1 Tools and Equipment
insulating gloves Safety shoes Tool
2.2 Battery placement
Gently place the battery pack face up on the support surface, do not lay it on its side or
upside down, and do not place any covers above the pack. The schematic diagram of battery
pack placement is shown in Figure 3
✔
✘
7
Figure 1 Installation and Placement Diagram
✘
✘
8
2.3 Battery supporting materials
Table 1: Material List
SN
Material name
Chart
QTY/pc
SPEC
1
Inter-communic
ation cable
1
500mm long, M1
2 circular communica
tion interface at both
ends.
2
Battery
1
12.8V120Ah or 1
2.8V200Ah or 12.8V3
00Ah
3
Screw
2
M8 * 12 stainles
s steel screw
3. Introduction to EPOCH DP series batteries
3.1 Main features
a. LiFePO4 chemistry - providing excellent safety and lifespan
b. High reliability
c. Maintain consistent performance over a wide temperature range
e. With higher heat dissipation effect, it can maintain high current charging and discharging of the
battery for a longer time
f. The communication function enables the battery to communicate with external devices through
CAN, enabling better battery management.
9
3.2 Product appearance.
Figure 2 Battery Appearance
No.
Component Description
Name
Statement
1
Fin
Disperse the heat insi
de the battery, be careful
not to touch it with your
hands
2
Pole
M8 Terminal
10
3
Panel
Check the soc. runni
ng light to preliminarily de
termine whether the batte
ry operates normally
4
Power
Switch
When the battery is
not used for a long time,
it can be disconnected to
reduce self-consumption.
5
Label
Carefully read the lab
el and use the battery co
rrectly according to the la
bel content
6
Handle
Convenient handling
of batteries
7
Port
Battery to battery co
mmunication, battery to e
xternal communication
8
Pressure
relief
valve
IP67 to prevent lithiu
m batteries from explodin
g in special
circumstances
9
Bracket
Convenient for fixing
the battery on the ground
Table 1: Component Description
