eove 70 User manual
The guide do not replace
the user manual
For people knowing
the setting
Quick Guide
05/2019 - Photo credit: © Air Liquide - Design and illustration CHANH THI
Choice of the breathing system
Breathing system assembly
EOVE-70
Contact
EOVE
Helioparc - 4 Bd Lucien Favre
64000 Pau France
+33 (0)5 59 21 86 84
www.eove.fr
Simple limb
circuit
Intentional leak
(only on the PRM Mode)
Mask
Mouthpiece
Filter
Connect the breathing system to the patient circuit port.
INEX Mode: Simple limb circuit without leak
PRM Mode: Simple limb circuit with intentional leaks
MOVE AND CARE CONCEPT BY
MOVE AND CARE CONCEPT BY
Unlock the clinical mode
Push on the “menu” button, then, unlock clinical mode
and Validate
Treatment settings
Push on the button “Settings”, then, choose the treatment
mode
Choose your settings (selection, settings, validation)
Push on “Save” to memorize the settings
Save a preset
During the step “Treatment settings”, push on Validate
Choose the preset place,
personalize the name and then,
Validation
Modification of the current settings
Push on the setting you want to modify, adjust it,
and Validation
Breathing system calibration
Execute the calibration from the clinical menu following the
instructions. Then, Validation and come back to the home
screen.
Turn on the EOVE-70
Manage the treatment
Select the preset
Start the session: push on
Stop the session: push on
INEX manual mode: move your finger on the touch screen
(from the right to the left)
Switch off the device
Long push on + Validate
2
3
Press on
1
