Eonon L0606 User manual
www.eonon.com
Model: L0606
Please read this manual before using and
save this manual for future reference.
User manual
12
Monitor
12345678910
(1) Audio out (Earplug)
(2) Audio / video in
(3) 16:9/4:3 mode switch
(4) AV switch
(5) Decrease button
(6) Menu
(7) Increase button
(8) Power switch
(9) Remote control reception window
(10) Power indicator
Remote controller
MD
L/R
U/D
AV
TFT-LCD
MONITOR REMOTE
1
2
3
4
5
6
7
8
9
10
(1) Mute
(2) 16:9 / 4:3 Mode switch
(3) L/R switch
(4) U/D switch
(5) AV switch
(6) Power switch
(7) Brightness + -
(8) Contrast + -
(9) Color + -
(10) Volume + -
Connections
Red 12V
Black grounding
Reverse control line (green)
Video V2 (yellow)
Video V1 (yellow)
Audio input (red)
Fusebox
Display size: 9
Display format: 16:9
Power supply: 12V
Resolution: 640 (H) RGB 234 (W)
Parameters
Model: L0606
1 2 3 4 5 6 7 8 9 10
MD
L/R
U/D
AV
TFT-LCD
MONITOR REMOTE
1
2
3
4
5
6
7
8
9
10
34
