Envision H2460w User manual
Table of Contents
About This Guide ..............................................................................................................1
National Conventions........................................................................................................1
FCC Notice .......................................................................................................................2
WEEE Declaration ............................................................................................................2
Hg Declaration ..................................................................................................................3
Precautions.......................................................................................................................3
Setup the stand and base .................................................................................................4
Adjusting Viewing Angle....................................................................................................4
Attaching the Cables.........................................................................................................5
Wall Mounting ...................................................................................................................6
Setting the Optimal Resolution..........................................................................................6
External Controls...............................................................................................................7
OSD Settings ....................................................................................................................8
Function Control Illustration ..............................................................................................9
LED Indicators.................................................................................................................12
i-Menu software...............................................................................................................12
Drivers.............................................................................................................................13
Technical Support...........................................................................................................15
Frequently Asked Questions...........................................................................................15
Product Information.........................................................................................................16
Specifications..................................................................................................................16
Preset Display Modes.....................................................................................................17
Pin Assignments .............................................................................................................18
Plug and Play..................................................................................................................19
About This Guide
This guide describes the monitor's features, setup, and operation. lnformation in this document is
subject to change without notice.
The sections are as follows:
•Safety Instructions: lists safety information.
•Setup: describes the initial setup process.
•Using the Monitor: gives an overview of how to use the monitor.
•Drivers: provides driver installation instructions for Windows.
•Technical Support : provides tips and solutions for common problems.
•Product Information: lists the technical specifications of the monitor.
•Warranty Statement: Warranty Statement used in Europe.
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic
type. These blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of your
computer system
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data
and tells you how to avoid the problem
WARNING: A WARNING indicates the potential for bodily harm and tells you how to
avoid the problem
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases,
the specific presentation of the warning is mandated by regulatory authority.
1
FCC Notice
FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED
MODELS)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
NOTICE :
1. The changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the
emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modification to this equipment. It is there sponsibilities of the user to correct such interference.
WEEE Declaration
Disposal of Waste Equipment by Users in Private Household in the European Union.
This symbol on the product or on its packaging indicates that this product must not be disposed of with
your other household waste .Instead, it is your responsibility to dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city office, your household waste disposal service or the shop where
you purchased the product .
2
Hg Declaration
SAFETY: Lamp Disposal
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED
OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION, CONTACT
THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.EIAE.ORG.
Precautions
WARNING: Use of controls, adjustments, or procedures other than those specified in this
documentation may result in exposure to shock, electrical hazards, and/or mechanical hazards
Read and follow these precautions when connecting and using your computer monitor:
PRECAUTIONS
•Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub,
swimming pool or in a wet basement.
•Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a
person and cause serious damage to the appliance. Use only a cart or stand recommended by
the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a
mounting kit approved by the manufacturer and follow the kit instructions.
•Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of the monitor and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not
place the monitor near or over a radiator or heat register. Do not place the monitor in a
bookcase or cabinet unless proper ventilation is provided.
•The monitor should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.
•The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin.
This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not
accommodate the three-wire plug, have an electrician install the correct outlet, or use an
adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.
•Unplug the unit during a lightning storm or when it will not be used for long periods of time. This
will protect the monitor from damage due to power surges.
•Do not overload power strips and extension cords. Overloading can result in fire or electric
shock.
•Never push any object into the slot on the monitor cabinet. It could short circuit parts causing a
fire or electric shock. Never spill liquids on the monitor.
•Do not attempt to service the monitor yourself; opening or removing covers can expose you to
dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.
•To ensure satisfactory operation, use the monitor only with UL listed computers which have
appropriate configured receptacles marked between 100 - 240V AC, Min. 5A.
•The wall socket shall be installed near the equipment and shall be easily accessible.
•For use only with the attached power adapter (Output 12Vdc) which have UL,CSA listed
license(Only for monitors with power adapter).
•Please make sure to clean the cabinet regularly with the provided cloth , you can use
soft-cleanser to clean the stain , instead of severe spray cleanser which will cauterize the
monitor cabinet.
•Don’t leak liquid into monitor which will result in the damage of chassis or component. Please
unplug before cleaning ,and do not scratch the screen with hard things.
3
Setup the stand and base
Please setup or remove the base following below steps.
Adjusting Viewing Angle
•For optimal viewing it is recommended to look at the full face of the monitor, then adjust the
monitor's angle to your own preference.
•Hold the stand so you do not topple the monitor when you change the monitor's angle.
•You are able to adjust the monitor's angle from -5°to 19 °.
NOTE:
Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD
screen.
4
-5° 19 °
Attaching the Cables
Cable Connections On Back of Monitor and Computer
1. Power
2. Analog
Turn off your computer before performing the procedure below.
1. Connect the power cable to the AC port on the back of the monitor.
2. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other
end to the computer's D-Sub port.
3. Turn on your monitor and computer.
If your monitor displays an image, installation is complete. If it does not display an image, see
Troubleshooting.
5
Wall Mounting
Preparing to Install An Optional Wall Mounting Arm
This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before
this procedure. Follow these steps:
1. Remove the base.
2. Follow the manufacturer's instructions to assemble the wall mounting arm.
3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the
holes in the back of the monitor.
4. Insert the 4 screws into the holes and tighten.
5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting
arm for instructions on attaching it to the wall.
Noted : VESA mounting screw holes are not available for all models, please check with the dealer or
official department of ENVISION.
Setting the Optimal Resolution
The recommended resolution for this monitor is 1920 by 1080. To setup the monitor to this resolution,
follow the steps below.
1. Click START.
2. Click SETTINGS.
3. Click CONTROL PANEL.
4. Double click DISPLAY.
5. Click SETTINGS.
6. Set the resolution SLIDE-BAR to 1920 by 1080.
6
External Controls
Press the power button to turn the monitor on or off. The other control knobs are located at front panel of
the monitor (See Figure ). By changing these settings, the picture can be adjusted to your personal
preferences.
* The power cord should be connected.
* Press the power button to turn on the monitor. The power indicator will light up.
1. Auto / Exit
2. Eco mode (DCR) / -
3. 4:3 or wide / +
4. Menu / Enter
5. Power
7
OSD Settings
•Press the MENU-button to activate the OSD window.
•Press+ or - to navigate through the functions. Once the desired function is highlighted, press the
MENU-button to activate it. If the function selected has a sub-menu, press or again to navigate
through the sub-menu functions. Once the desired function is highlighted, press MENU-button
to activate it.
•Press+ or - to change the settings of the selected function. To exit and save, select the exit
function. If you want to adjust any other function, repeat steps 2-3.
•OSD Lock Function: To lock the OSD, press and hold the Menu button while the monitor is off
and then press power button to turn the monitor on. To un-lock the OSD - press and hold the
Menu button while the monitor is off and then press power button to turn the monitor on.
•Eco Mode and DCR hot key : Press the Eco key continuously to select the Eco mode of
brightness and DCR on when there is no OSD ( Eco mode hot key may not be available in all
models).
•4:3 or wide image ratio hot key: When there is no OSD, press + continuously to change 4:3 or
wide image ratio. (If the product screen size is 4:3 or input signal resolution is wide format, the
hot key is disalbe to adjust).
•Auto configure hot key: When the OSD is closed, pressAuto button for 2 second .will be auto
configure hot key function .
8
Function Control Illustration
Luminance Adjust Range Description
Brightness 0-100 Backlight Adjustment
Contrast 0-100 Contrast from Digital-register
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Eco mode
Sports Sports Mode
Gamma1 Adjust to Gamma1
Gamma2 Adjust to Gamma 2
Gamma
Gamma3 Adjust to Gamma 3
Off Disable dynamic contrast ratio
DCR
On Enable dynamic contrast ratio
9
Table of contents
Other Envision Monitor manuals
Envision
Envision G917w1 User manual
Envision
Envision G2460w User manual
Envision
Envision H819 User manual
Envision
Envision H1981 User manual
Envision
Envision P2071L User manual
Envision
Envision H976WDL User manual
Envision
Envision H170L User manual
Envision
Envision G2219 User manual
Envision
Envision LCD User manual
Envision
Envision EN-8500 User manual
Envision
Envision EN-775e User manual
Envision
Envision EN-7500 User manual
Envision
Envision EN9250 User manual
Envision
Envision EN-7100s User manual
Envision
Envision EN7600 User manual
Envision
Envision H716a4 User manual
Envision
Envision G2261w User manual
Envision
Envision H22W User manual
Envision
Envision EN9410 User manual
Envision
Envision EN7450 User manual
