Englaon X70 Series User manual
X70 Series
User Manual
1
Table of Contents
2
Under Following Conditions
• Power failure or unstable voltage.
• Abnormal sound or smell from the device.
• AC power cord is damaged.
• TV set is damaged due to falling off, knock or impact.
• Any liquid or foreign matters enter into the TV set.
Turn off the TV set immediately, unplug the power cord from the power outlet, and contact
authorized maintenance personnel.
• If coal gas or other flammable gases leak, do not unplug the power cord of the TV set or
other electric appliances; instead, close the valve of the gas immediately and open the doors
and windows
Safety Warning and Notice
2
Thanks for choosing the high-performance and multifunctional intelligent LED TV produced
by our company. This precious thing will bring you better audiovisual enjoyment. The design
of this product has given consideration to factors affecting personal safety, and the product
itself has gone through strict tests prior to delivery. However, improper operation may result
in electric shock and fire disaster. To ensure safety, prolong the service life of this product,
and make sure the best performance of this product can be given full play to, please read
the manual and marking label carefully before using it and comply with the following safety
instructions. Please keep the user manual for later use.
33
44
Physical Setup
5
What’s Included
with your TV
•24” X70 Series 12V TV
6
Mounting your TV
using the base
1. Put the machine flat first, distinguish left and
right base and base installation front and
back direction, then install the bases in the
bottom of the machine back cover as arrow
direction in figure. Align screw holes, then
fasten screws (notice that base module has
to be adjusted at figure status, otherwise it
cannot be installed in.)
2. Place your TV on a stable surface.
3. Ensure the TV is not directly next to an air
conditioner, as moisture condensation can
cause failure.
4. Keep at least 7cm of space between the TV
and the wall to ensure adequate airflow.
7
Mounting your TV to
the wall
•Please purchase a suitable TV wall mount when
mounting your TV on the wall.
•Ensure that the bearing capacity of the wall for
mount installation is no less than 4 times the
weight of the TV set and the wall mount so as to
avoid falling.
•Please refer to the instructions provided with the
TV set and wall mount for installation .
•Make sure there is no cable or conduit in the
wall section where a wall mount will be
installed.
•Please entrust a professional technician to
complete installation . The company shall not be
liable for accidents , personal injury or damage
caused by
8
Connecting power and the
antenna
•Plug one end of your power cable into the TV, and the
other into the outlet.
•Your antenna cable plugs into the TV the same way.
Ensure the other end is correctly connected to the
antenna.
•Refer to the diagram if you have any issues.
9
Software Setup
10
