Emulex Network Adapter 5.01 User manual
Combined Boot
Version 5.01a0
for Emulex HBAs
User Manual
Combined Boot User Manual Page ii
Copyright© 2005 Emulex Corporation. All rights reserved worldwide. No part of this document may be reproduced
by any means nor translated to any electronic medium without the written consent of Emulex Corporation.
Information furnished by Emulex Corporation is believed to be accurate and reliable. However, no responsibility is
assumed by Emulex Corporation for its use; or for any infringements of patents or other rights of third parties which
may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Emulex
Corporation.
Emulex and LightPulse are registered trademarks, and AutoPilot Installer, AutoPilot Manager, BlockGuard,
FibreSpy, HBAnyware, InSpeed, MultiPulse and SBOD are trademarks, of Emulex Corporation. All other brand or
product names referenced herein are trademarks or registered trademarks of their respective companies or
organizations.
Emulex provides this manual "as is" without any warranty of any kind, either expressed or implied, including but not
limited to the implied warranties of merchantability or fitness for a particular purpose. Emulex Corporation may
make improvements and changes to the product described in this manual at any time and without any notice. Emulex
Corporation assumes no responsibility for its use, nor for any infringements of patents or other rights of third parties
that may result. Periodic changes are made to information contained herein; although these changes will be
incorporated into new editions of this manual, Emulex Corporation disclaims any undertaking to give notice of such
changes.
Combined Boot User Manual Page iii
Introduction..............................................................................................................1
Compatibility......................................................................................................1
Things to Know Before You Download ..............................................................1
Known Issues....................................................................................................1
Files Included in This Release...........................................................................1
Loading x86 BootBIOS............................................................................................2
Load x86 BootBIOS Using lputilnt .....................................................................2
Load x86 BootBIOS Using elxcfg ......................................................................3
Load x86 BootBIOS Using lputil........................................................................4
Loading x86 BootBIOS Using lp6dutil................................................................4
Enable x86 BootBIOS on HBAs Using the BIOS Utility .....................................6
Configuring x86 BootBIOS.......................................................................................8
Introduction .......................................................................................................8
Start the BIOS Utility..........................................................................................8
Adapter Configuration Menu Summaries...........................................................9
Change the Default AL_PA..............................................................................10
Change the PLOGI Retry Timer ...................................................................... 11
Change Topology ............................................................................................ 11
Enable/Disable the Spinup Delay .................................................................... 12
Set Auto Scan .................................................................................................13
Enable/Disable EDD 3.0..................................................................................14
Enable/Disable the Start Unit Command .........................................................14
Enable/Disable the Environment Variable........................................................15
Enable/Disable Auto Sector Format Select......................................................15
Configure Boot Devices...................................................................................16
Install Windows 2000 Server on a Fibre Channel Disk....................................17
Use Multi-Boot BIOS .......................................................................................18
Troubleshooting x86 BootBIOS .............................................................................19
The x86 BootBIOS Message Does Not Appear on Bootup..............................19
Retry This Adapter Message...........................................................................19
The .prg File Fails During Downloading...........................................................19
Loading OpenBoot.................................................................................................20
Load OpenBoot using lputil .............................................................................20
Configuring OpenBoot...........................................................................................21
Creating a Fibre Channel Remote Boot Disk...................................................21
Making a Bootable System Disk......................................................................23
Viewing OpenBoot Commands........................................................................26
Troubleshooting OpenBoot....................................................................................27
The System Cannot mount or fsck /etc/vfstab Fibre Channel Boot Disk.......... 27
A Loaded File Is Not Executable .....................................................................27
The System Hangs or Reboots After Displaying Driver Information.................27
Fibre Channel Disk Is Not Found ....................................................................27
Combined Boot User Manual Page 1
Introduction
Combined Boot contains two types of boot code: x86 BootBIOS for x86 systems, and OpenBoot for
SPARC Peripheral Component Interconnect (PCI) and AIX systems. Combined Boot determines your
system platform (x86 or SPARC) and automatically downloads the proper boot code image to the host
bus adapter (HBA).
x86 BootBIOS works with the existing basic input output system (BIOS) on x86 systems. x86 BootBIOS
allows you to designate a Fibre Channel drive as the boot drive.
OpenBoot is a set of FCode instructions in the HBA flash read-only memory (ROM) that allows you to
designate a Fibre Channel hard drive as the boot drive. OpenBoot works with the existing system BIOS
on SPARC PCI systems.
Compatibility
• Combined Boot is compatible with the following Emulex®Fibre Channel PCI HBAs:
• LP9402DC, LP9002DC, LP9002L and LP9000 (minimum firmware version 3.82a1)
• LP8000 and LP8000DC (minimum firmware version 2.81)
Things to Know Before You Download
• Combined Boot is a complete single boot image. Therefore, the HBA utility software enables or
disables two types of boot code (x86 BootBIOS and OpenBoot).
• This download assumes that there is already a local boot disk.
• As a measure of protection, ensure that critical files on your local boot disk are backed up.
• The .PRG files included in this release contain only the boot code overlay (no firmware).
Known Issues
The following issue has been reported at the time of publication.
• None at this time.
Files Included in This Release
This kit includes the following files:
File Name Description
readme.txt Release notes for Combined Boot version 5.01a0
cc501a0.prg LP9402DC, LP9002DC, LP9002L and LP9000 Combined Boot image
dc501a0.prg LP8000 and LP8000DC Combined Boot image
Combined Boot User Manual Page 2
Loading x86 BootBIOS
Before you update x86 BootBIOS, decide which utility to use. Emulex offers a variety of utilities that you
can use to update x86 BootBIOS. The utilities that you can use depend on your operating system and, in
some cases, driver:
After you decide which utility to use, see the appropriate update procedures:
• lputilnt: See Load x86 BootBIOS Using lputilnt on page 2.
• elxcfg: See Load x86 BootBIOS Using elxcfg on page 3.
• lputil: See Load x86 BootBIOS Using lputil on page 4.
• lp6dutil : See Loading x86 BootBIOS Using lp6dutil on page 4.
Load x86 BootBIOS Using lputilnt
Prerequisites
• One of the following drivers is installed and loaded properly:
• SCSIport Miniport driver for Windows Server 2003, Windows 2000 Server or Windows
NT.
• Storport Miniport driver for Windows Server 2003.
• lputilnt is installed properly.
• The x86 BootBIOS file has been downloaded from the Emulex Web site and extracted to a folder
on your local hard drive.
• The system is in a state in which this type of maintenance can be performed:
• I/O activity on the bus has been quieted.
• Cluster software, or any other software that relies on the HBA to be available, has been
stopped or paused.
To load x86 BootBIOS using lputilnt:
1. Start lputilnt: Click Start, Programs, Emulex and lputilnt.
2. Select the desired HBA.
3. Select Firmware Maintenance from the Category list.
4. Click Download and locate the new x86 BootBIOS file.
5. Click Open. The new boot code is transferred to flash ROM.
Operating System lputilnt* elxcfg** lputil lp6dutil***
Windows X X X
Linux X X
Solaris (x86 system) X X
* SCSIport Miniport and Storport Miniport drivers only
** FC Port driver only
*** Requires DOS (will not run in a DOS window)
Combined Boot User Manual Page 3
6. Click Boot Bios Firmware (Figure 1).
Figure 1: lputilnt, Program Type list.
7. If the Disable button appears, the boot code is already enabled; skip to step 9. Otherwise,
continue with step 8.
8. Click Enable; the Enable button changes to Disable and the letter W appears to the left of "Boot
Bios Firmware" in the Program Type list. This indicates that x86 BootBIOS is in use.
9. Continue by enabling x86 BootBIOS on HBAs (page 6).
Load x86 BootBIOS Using elxcfg
Prerequisites
• The FC Port driver for Windows Server 2003, Windows 2000 Server or Windows NT is installed.
• elxcfg is installed properly.
• The x86 BootBIOS file has been downloaded from the Emulex Web site and extracted to a folder
on your local hard drive.
• The system is in a state in which this type of maintenance can be performed:
• I/O activity on the bus has been quieted.
• Cluster software, or any other software that relies on the HBA to be available, has been
stopped or paused.
To load x86 BootBIOS using elxcfg:
1. Start elxcfg: Click Start, Programs, Emulex and elxcfg.
2. Locate and select an HBA from the Available Adapters list (Figure 2).
Figure 2: elxcfg Utility, Available Adapters List
3. Select Download Firmware from the Tools menu. A browse window is displayed.
4. Browse to the folder into which you extracted the x86 BootBIOS file and select the file.
5. Click Open. The file is downloaded, and a confirmation window is displayed.
6. Click OK to close the confirmation window.
7. Enable the x86 BootBIOS Bootup Message Using lp6dutil, if necessary (page 4).
8. Continue by enabling x86 BootBIOS on HBAs (page 6).
Combined Boot User Manual Page 4
Load x86 BootBIOS Using lputil
Prerequisites
• The Emulex driver for Linux or Solaris is installed and loaded properly.
• The x86 BootBIOS file has been downloaded from the Emulex Web site and extracted to a
directory on your local hard drive.
• lputil is installed properly.
To load x86 BootBIOS using lputil:
1. Start lputil by entering the complete path. The path in the example reflects the default installation
path. If the installation path was modified, adjust the command appropriately.
/usr/sbin/lpfc/lputil
2. From the Main menu, enter 3, Firmware Maintenance.
3. From the list that appears, choose the HBA onto which you want to load x86 BootBIOS.
4. Enter 1, Load Firmware Image.
5. Enter the full path to the remote boot image file. The new boot code is transferred to flash ROM.
6. From the Firmware Maintenance menu, press 6, Boot BIOS Maintenance.
7. Press 1, Enable Boot BIOS, to enable the Boot message. (If item 1 is Disable Boot BIOS, the
BIOS message is already enabled.)
8. Continue by enabling x86 BootBIOS on HBAs (page 6).
Loading x86 BootBIOS Using lp6dutil
Prerequisites
• The x86 BootBIOS file has been downloaded from the Emulex Web site and extracted to a
directory on your local hard drive.
All lp6dutil tasks can be performed using the graphical user interface (GUI) screen menus. All screens
require navigation and selection using the keyboard.
To load x86 BootBIOS using lp6dutil:
1. Start lp6dutil:
a. Boot up your system with DOS.
b. From the directory where the lp6dutil.exe file resides, enter the following command:
lp6dutil
2. Press and hold down the < Alt> key and press L. The flash menu is displayed.
Figure 3: lp6dutil, Flash Menu
Note: You cannot start lp6dutil at the screen’s command prompt.
Combined Boot User Manual Page 5
3. Press D. The Download Image window is displayed.
Figure 4: lp6dutil, Download Image Window
4. Specify the location of the image file and the adapter to be updated.
5. Specify the Reset After Download setting.
• Defaults to Yes. If you are updating a single file to one HBA, keep the default setting.
• If you are updating several HBAs or several files to one HBA, select No.
6. Tab to the OK button and press <Enter>. The screen closes and the load process begins.
Various steps of the download process are displayed along with the results of the download
(success or error).
7. Press and hold down the <Alt> key and press L. The flash menu is displayed (Figure 3).
8. Press B. The Change Boot BIOS State window is displayed. This window is used to change the
x86 BootBIOS state for an adapter.
Figure 5: lp6dutil, Change Boot BIOS State Window - Disabled BootBIOS Message
9. Highlight the HBA in the Adapters list.
10. Highlight the x86 BootBIOS image in the BIOS Images list.
11. Tab to Change and press <Enter>. The BootBIOS message is enabled for the selected HBA.
12. Tab to OK and press <Enter> to close the window.
13. Continue by enabling x86 BootBIOS on HBAs (page 6).
Combined Boot User Manual Page 6
Enable x86 BootBIOS on HBAs Using the BIOS Utility
To use any of its features, x86 BootBIOS must be enabled on at least one installed HBA.
Prerequisites
• x86 BootBIOS is loaded on the HBA.
• The BIOS message is enabled.
To enable BootBIOS on the HBA:
1. Boot the system.
2. Press <Alt E> immediately (within five seconds) when the x86 BootBIOS message is displayed
to start the BIOS utility. A menu displays a list of HBAs (Figure 6).
Figure 6: BIOS Utility, HBA Listing
3. Select the HBA by entering the appropriate number.
4. The main configuration menu is displayed (Figure 7).
Figure 7: BIOS Utility, Main Configuration Menu
Combined Boot User Manual Page 7
5. Press 2to configure the HBA. The adapter configuration menu is displayed (Figure 8).
Figure 8: BIOS Utility, Adapter Configuration Menu
6. Press 1to Enable or Disable BIOS.
7. Exit the BIOS utility and reboot the system. After x86 BootBIOS is enabled on the HBAs, refer to
the Configuration section for information on other adapter configuration menu options.
This manual suits for next models
1
Table of contents
Other Emulex Software manuals
