Emerson HD9971 User manual

PERSONALCD PLAYER

with40 SECOND ELECTRONIC

ANTI-SKIPPROTECTION

HD9971

OWNER’SMANUAL

Visitourweb siteatwww.emersonradio.com

HD9971_ib_drafts.p65 19/4/2002, 15:5218

Thankyou.........

Forpurchasing thisEmerson PersonalCD Player.The CD playerhasa22 track

programmablememorysoyou can listen tothe songson yourfavoriteCD'sinany

orderyou choose.Oryou can usethe Randomplayback featureand letthe player

selectthe playback orderforyou.Usethe 3-wayRepeatfeaturetorepeatasingle

track,the entiredisc,oraprogrammed sequenceoftracks,indefinitely.We've

alsoincluded a40 Second Electronic

Anti-SkipMemorywhichmakesthisplayervirtuallyskip-free during mostactive

uses.There'saDynamicBass BoostControlthatincreasesand enhancesthe

bass response.

Pleaseread thisinstruction manualcompletelyand carefullytomakesureyou

understand the properoperation ofthisproduct, and getthe maximumenjoyment

outofall the featuresofthisstate-of-the-artCD player.

Onceagain,thanks forpurchasing thisEmerson product.

The serialnumberofyourCD playercan be found on the bottomcabinet. We

suggestthatyou recordthe serialnumberofyourunitinthe spacebelowforfuture

reference.

ModelNumber:HD9971

SerialNumber:

HD9971_ib_drafts.p65 19/4/2002, 15:521

WARNING: TOPREVENTFIREORSHOCKHAZARD,

DONOTEXPOSETHISUNITTORAINORMOISTURE.

Thisdevicecomplieswithpart15 ofthe FCC rules.Operation issubjecttothe

condition thatthisdevicedoesnotcauseharmfulinterference.

CLASS 1LASERPRODUCT

APPAREILÁLASERDECLASSE 1

PRODUCTOLASERDECLASE 1

CAUTION

INVISIBLELASERRADIATION

WHENOPENAND INTERLOCKS

DEFEATED.

AVOIDEXPOSURETOBEAM

ThisproductcontainsalowpowerLaserDevice.

•Placesexposed todirectsunlightor

losetoheatradiating appliancessuch

aselectricheaters.

Avoidinstalling the unitinlocationsdescribed below:

•Dustyplaces.

•Placessubjecttoconstant

vibration.

•Humidormoistplaces.

CAUTION

THISLASERCOMPACTDISCPLAYERFUNCTIONSBY HELPOFINVISIBLE

LASERLIGHTAND ISEQUIPPEDWITHSAFETYSWITCHES TOAVOID

EXPOSUREWHENDOORISOPENAND SAFETYINTERLOCKS ARE

DEFEATED.ITISDANGEROUSTODEFEATORBYPASS SAFETYSWITCHES.

IMPORTANTNOTES

DANGEROUSVOLTAGE

Uninsulated DangerousVoltage,thatmaybe ofsufficient

magnitude toconstitutearisk ofelectricshock topersonsis

presentwithinthisproduct'senclosure.

ATTENTION

The Owner'sManualcontainsimportantoperating and

maintenanceinstructions.

Foryoursafety,itisnecessarytorefertothe manual.

HD9971_ib_drafts.p65 19/4/2002, 15:522

LOCATIONOFCONTROLSAND INDICATORS

1.)HOLDON/OFF Switch.

2.)STOPButton.

3.)REPEATButton.

4.)P.(Play)MODEButton.

5.)ElectronicSkipProtection

On/Off Button.

6.)CDDoor.

7.)DC IN4.5VInputJack.

8.)BatteryCompartment.

(Bottomcabinet)

9.)Headphone Jack.

10.)LINEOUTJack.

11.)VOLUMEControl.

12.)CDDoorOPENButton.

13.)SKIP/SEARCH Button.

14.)SKIP/SEARCH Button.

15.)PLAY/PAUSE Button.

16.)DBBS ON/OFF Switch.

17.)LCD Display.

HD9971_ib_drafts.p65 19/4/2002, 15:523

1.)ElectronicSkipProtection Indicator–flashing icon indicatesElectronic

SkipProtection isactivated.

2.)PGM(Program) Indicator–Appearswhen programming tracks or

playing programmed tracks.

3.)RPTIndicator–Appearswhen the Repeatplayback mode isselected.

4.)RND (Random) Indicator–Appearswhen Randomplayback mode is

selected.

5.)INTROIndicator–Appearswhen Introplayback mode isselected.

6.)RepeatA-BIndicators–Appearswhen Repeatbetween 2designated

points.

7.)Elapsed TimeAnd TotalPlaying TimeIndicator.

8.)Track NumberDisplay–Showsthe track whichisbeing played,and

the totaltracks on the disc.

9.)BatteryIndicator–Lightswhen using batteriespower.Flasheswhen

batteriesneeded tobe replaced.

LCD DISPLAYINDICATORS

(3)

(2)(4)

(6)

(7)

(8)

(9)

(1)

(5)

HD9971_ib_drafts.p65 19/4/2002, 15:524

POWERSOURCE

ThisCD playercan be operated on either120V60HzAChousecurrentwithan

optionalACadapter(notincluded)oron 3VDC (2"AA"batteries,notincluded).

BATTERYOPERATION

1.)Open the batterycompartmentdooron the bottom

cabinetbysliding itinthe direction ofthe arrowand

then lifting itopen.Topreventloss,the doorcannot

be removed fromthe unit.

2.)Insert2"AA"batteries(notincluded)intothe

compartment. Usealkaline batteriesforlongestlife.

Followthepolaritymarkingsinside the compartment.

If the batteriesareinserted incorrectlythe unitwill

notwork.

NOTE:

Inordertooperatethe playeron batteriesthe ACadaptermustbe disconnected

fromthe DC INjack.

BATTERYREPLACEMENT

When the batteriesbecometoo weakthe batterylevelindicator“ ”flashess

and operation maybecomeerratic.When thisoccursreplacethe batteries

immediately.

BATTERYPRECAUTIONS

Followtheseprecautionswhen using batteriesinthisdevice:

1.Useonlythe sizeand type ofbatteriesspecified.

2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery

compartment. Reversed batteriesmaycausedamage tothe device.

3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkaline and Carbon-Zinc)oroldbatteries

withfreshones.

4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent

damage orinjuryfrompossiblebatteryleakage.

5.Donottrytorecharge batteriesnotintended tobe recharged;theycan overheatand rupture

(Followbatterymanufacturer’s directions.)

HD9971_ib_drafts.p65 19/4/2002, 15:525

AC OPERATION(AC Adapternotincluded)

ConnecttheACadaptertoyour120VACoutlet. Then connectthe small plug tothe

"DC IN4.5V"jack on the back ofthe playerasshowninthe following illustration.

NOTE:

ThisoptionalACadapter,shouldbe rated asfollows:

Input:120V/60HzAC.

Output:4.5VDC 500mA.

The adaptermusthaveafemale-type plug withapositivecenter:

•Besurethe adapterisULlisted.If you usea“Universal”-type adapter,be sureto

setthe outputselectorto“DC 4.5V”.

•If theACadapterwill notbe used foran extended period oftime,removeitfrom

the wall outletbypulling on the adapterhousing.Donotremovethe adapterby

pulling on the cord.Donottouchthe ACadapterwithwethands.

Positive(+)Negative(–)

HD9971_ib_drafts.p65 19/4/2002, 15:526

OPERATINGINSTRUCTIONS

NORMALPLAYBACK

1.) Connect the headphones to the Headphone jack.

2.) Set the VOLUME control to minimum.

3.) Press the CD door OPEN

button to open the CD door. Place

your CD on the center spindle,

label side up and gently press

down until it is firmly held in place.

4.) Close the CD door and push down

on the “CLOSE” position, to make

sure that the door locks properly.

5.) Slide the HOLD switch to the “OFF” position.

6.) Press the PLAY/PAUSE button and the total number of tracks and total

playing time will show on the display window. The player will then start playing

track 1 automatically. Track number and elapsed playing time are displayed.

7.) Adjust the VOLUME and DBBS (Bass Boost)controls as desired.

8.) When all tracks have been played the player stops and the display shows the

total tracks and playing time on the disc. After approximately 1 minute the

power shuts off and the display goes blank.

To stop playback before the disc ends press the STOP button at any time.

Press the STOP button again to shut the power off immediately..

9.) Press the OPEN button to open the door and remove your disc. Close the

CD Door and return your disc to its protective storage case.

VOLUME

HD9971_ib_drafts.p65 19/4/2002, 15:527

PAUSE CONTROL

Press the PLAY/PAUSE button during

playback topausemomentarily.The sound

stops.The timedisplayflashesbutthe disc

continuestospin.

Press the PLAY/PAUSE button againtocancelpauseand resumeplayback.

The sound returnsand the displaystopsflashing.

SKIP/SEARCH CONTROLS

Toskipforwardorreversetoanothertrack duringplayback press

the orbuttonsrepeatedlyuntil the desired track number

appearsinthe display.Playback will beginon the desired track.

Tosearchforwardorbackwardwithinatrack tolocateaspecificmusicalpassage

press and holdeitherthe orbuttons.The playermovesforwardorreverse

athigh speed.When you reachthe desired pointinthe track,releasethe buttons

and normalplayback resumes.

REPEATPLAYBACK

Repeat One Track

1.) Press the REPEAT button until the

RepeatIndicator (RPT) is flashing onthe

display.

2.) Select the desired track by pressing the /buttons.

3.) Press the PLAY/PAUSE button. The selected track will be repeated

continuously.

Repeat All Tracks

1.) Press the REPEAT button until the Repeat

Indicator “RPT” remains on the display.

2.) Press the PLAY/PAUSE button. The

entire disc will be repeated continuously.

HD9971_ib_drafts.p65 19/4/2002, 17:008

“Point A” To “Point B” Repeat

1.) Press the PLAY/PAUSE button to start the disc and use the SKIP/SEARCH

button to advance the player until it is close to the point where you want to

begin repeating (Point A).

2.) Press the REPEAT button 3 times until

the “RPT” (Repeat) indicator stays on

and the “A”indicator is flashing.

3.) When you reach the point where you want to

begin repeat playback, press the PLAY/

PAUSE button once. The “A” indicator

stays ”On” and the “B” indicator begins to

flash.

4.) When you reach the point where you want to

end repeat playback, press the PLAY/PAUSE

button once more. The “B” indicator stops

flashing and remains “On”. The player will

begin repeating the portion of the disc between your selected points Aand B.

TO CANCEL REPEAT PLAY MODES

• Press the REPEAT button until all of the repeat indicators are ‘Off’.

• Pressing the STOP button or opening the CD door also cancels the repeat

playback modes.
