Emerson HD8120 User manual

PERSONALCD /MP3PLAYER

withLIGHTWEIGHT

STEREOHEADPHONES

HD8120

OWNER’SMANUAL

Visitourweb siteatwww.emersonradio.com

HD8120_022004.p65 20/2/2004, 11:2327

Thankyou.........

ForpurchasingthisEmerson PersonalCD/MP3Player.TheCD/MP3player

hasa20 track programmablememorysoyou can listen tothe songson

yourfavoriteCD'sinanyorderyou choose.Oryou can usethe Random

playback featureand letthe playerselectthe playback orderforyou.Use

the 3-wayRepeatfeaturetorepeatasingletrack,the entiredisc,ora

programmed sequenceoftracks,indefinitely.We'vealsoincluded 100

second ElectronicAnti-SkipProtection (MP3)whichmakesthisplayer

virtuallyskip-free during mostactiveuses.

Pleaseread thisinstruction manualcompletelyand carefullytomakesure

you understand the properoperation ofthisproduct, and getthe maximum

enjoymentoutofall the featuresofthisstate-of-the-artCD/MP3player.

Onceagain,thanks forpurchasing thisEmerson product.

The serialnumberofyourCD/MP3playercan be found on the bottom

cabinet. Wesuggestthatyou recordthe serialnumberofyourunitinthe

spacebelowforfuturereference.

ModelNumber:HD8120

SerialNumber:

HD8120_022004.p65 20/2/2004, 11:221

WARNING: TOPREVENTFIREORSHOCKHAZARD,

DONOTEXPOSETHISUNITTORAINORMOISTURE.

Thisdevicecomplieswithpart15 ofthe FCC rules.Operation issubjecttothe

condition thatthisdevicedoesnotcauseharmfulinterference.

CLASS 1LASERPRODUCT

APPAREILÁLASERDECLASSE 1

PRODUCTOLASERDECLASE 1

CAUTION

INVISIBLELASERRADIATION

WHENOPENAND INTERLOCKS

DEFEATED.

AVOIDEXPOSURETOBEAM

ThisproductcontainsalowpowerLaserDevice.

•Placesexposed todirectsunlightor

closetoheatradiatingappliancessuch

aselectricheaters.

Avoidinstalling theunitinlocationsdescribedbelow:

•Dustyplaces.

•Placessubjecttoconstant

vibration.

•Humidormoistplaces.

CAUTION

THISLASERCOMPACTDISCPLAYERFUNCTIONSBY HELPOFINVISIBLE

LASERLIGHTAND ISEQUIPPEDWITHSAFETYSWITCHES TOAVOID

EXPOSUREWHENDOORISOPENAND SAFETYINTERLOCKS ARE

DEFEATED.ITISDANGEROUSTODEFEATORBYPASS SAFETYSWITCHES.

IMPORTANTNOTES

DANGEROUSVOLTAGE

Uninsulated DangerousVoltage,thatmaybe ofsufficient

magnitude toconstitutearisk ofelectricshock topersonsis

presentwithinthisproduct'senclosure.

ATTENTION

The Owner'sManualcontainsimportantoperating and

maintenanceinstructions.

Foryoursafety,itisnecessarytorefertothe manual.

HD8120_022004.p65 20/2/2004, 11:222

PREPARATIONFORUSE

REMOVE THE TRANSIT CARD

This personal CD/MP3 player is shipped with a dummy CD ‘transit card ‘ inside the

CD compartment. The purpose of this card is to prevent the laser from moving

during shipment of the product. This card must be removed before using the CD

player.

Slide the OPEN switch to the right to unlock the CD door. Remove the ‘transit card’

from the player and discard it.

POWER SOURCES

This personal CD/MP3 player is designed to operate on two “AA” batteries, not

included. Use a well known brand of Alkaline batteries for longest life and best

performance.

This player can also be operated by with an optional AC/DC converter/adapter, not

included. If you decide to purchase an optional AC/DC adapter the specification

must be as follows:

Input: 120V 60Hz AC

Output: 4.5V DC, 700 mA.

Plug: 1.7 mm Female Type with Positive Center, UL Listed.

You may also purchase a “Universal” type AC/DC adapter which allows you to

select the required output voltage and plug polarity, and normally includes multiple

plug sizes to fit most brands of equipment. Always look for the “UL” listing mark

when you purchase an adapter.

Positive(+)Negative(–)

HD8120_022004.p65 20/2/2004, 11:223

INSTALLING THE BATTERIES

Note: The battery compartment is located inside the CD compartment.

1.) Slide the OPEN switch to the right to open the CD door. If you have not already

done so, remove the dummy CD ‘transit card’ and discard it.

2.) Press the battery door locking tab in the direction of the ‘Arrow’ to open the

battery door. Lift the door upward as shown.

3.) Insert two alkaline “AA”batteriesin the battery compartment. Besure to observe

the polarity markings engraved in the battery compartment. If the batteries are

inserted incorrectly the unit will not work.

4.) Fold the battery removal ribbon over the top of the batteries, close the battery

door, and push the battery door downward until you hear a ‘click’ sound to

lock the door again.

5.) Close the CD door.

REPLACING THE BATTERIES

When the battery symbol appears in the display the batteries are becoming

weak and should be replaced.Always replace both batteries at the same time with

new fresh alkaline batteries. Do not mix old and new batteries or different types of

batteries together.

If the display remains blank when you press thePLAY/PAUSE button, the batteries

are completely dead. Replace them immediately. If dead batteries are left inside

the battery compartment for a long period of time they may leak and cause damage

to the unit, and such damage or corrosion from leaking batteries is not covered by

your warranty.

HD8120_022004.p65 20/2/2004, 11:234

CONNECTING THE OPTIONAL AC ADAPTER (NOT INCLUDED)

1.) Connect the small female plug of the optionalAC adapter to the “DC IN 4.5 V”

jack on the right side of the CD player.

2.) Connect the adapter housing to your 120V 60HzAC outlet.

Notes:

• Never connect or disconnect the adapter from the AC outlet while your hands

are wet.

• The housing of the AC adapter may become warm during operation. This is

normal.

• The female plug of the AC adapter must be completely disconnected from the

CD player in order to operate the player on batteries.

BATTERYPRECAUTIONS

Followtheseprecautionswhen using batteriesinthisdevice:

1.Useonlythe sizeand type ofbatteriesspecified.

2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery

compartment. Reversed batteriesmaycausedamage tothe device.

3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkaline and Carbon-Zinc)oroldbatteries

withfreshones.

4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent

damage orinjuryfrompossiblebatteryleakage.

5.Donottrytorecharge batteriesnotintended tobe recharged;theycan overheatand rupture

(Followbatterymanufacturer’s directions.)

DC 4.5V INPUT JACK

TO 120V/60Hz AC OUTLET

OPTIONAL AC/DC ADAPTER

HD8120_022004.p65 20/2/2004, 11:235

CONNECTING THE STEREO HEADPHONES

Connect the plug of the supplied stereo headphones to the green-colored

headphone jack on the left side of the cabinet.

NOTE: Make sure the headphone plug is inserted into the headphone jack as

far as it will go. If the plug is not fully inserted, you may only hear sound from

one side of the headphones.

IMPORTANT!

Always set the VOLUME control to a low level before you put the headphones on

and begin playing a CD. Then start playback and gradually increase the volume to

a comfortable listening level. Do not play the CD at loud volume levels that might

prevent you from hearing warning sounds such as car horns, etc.

HD8120_022004.p65 20/2/2004, 11:236

1.)OPENSwitch–Slide tothe righttounlock and open the CD door..

2.)VOLUMEControl–Raisesorlowersthe volume.

3.)PHONES Jack –Connectstereo headphones,included,tothisjack.

4.)HOLDSwitch.

5.)PROG (Program)/EQButton –Used when programming tracks.Alsoused to

selectthe desired presetEQsetting.

6.)PLAY/PAUSE Button.

7.)SKIPREV Button.

8.)ALB(Album)/ESP Button.

9.)LCDDisplay–ShowsTrack number,Playing time,Anti-Skipstatus,Program,

Repeat, Shuffle,and Intromodes.

10.)MODEButton –Selectsthe playback mode:Repeat1/All,Shuffle,orIntro.

11.)SKIPFWDButton.

12.)STOPButton.

13.)DC IN4.5VInputJack –ConnectanACadapter(notincluded)tothisjack to

use120V60Hzhousecurrent.

14.)CDDoor.

15.)BatteryCompartment(Inside CD Compartment).

LOCATIONOFCONTROLSAND INDICATORS

HD8120_022004.p65 20/2/2004, 11:237

1.)Scrolling information Display.

2.)Directory(Album) Number.

3.)Track NumberDisplay.

4.)PROG (Program) Indicator–Appearswhen programming tracks or

playing programmed tracks.

5.)DIR(Directory)Indicator.

6.)SHUFF (Shuffle)Indicator–Appearswhen Randomplayback mode

isselected.

7.)INTROIndicator–Appearswhen Introplayback mode isselected.

8.)MP3Indicator–Appearswhen playing CD’s containing mp3 audio

files.

9.)CD Indicator–Appearswhen playing normalCD discs.

10.)HOLDIndicator–Appearswhen HOLDswitchissetto‘On’position.

11.)REPT(Repeat)1/ALL Indicators–AppearswhentheRepeatplayback

mode isselected.

12.)BatteryStatusIndicator.

13.)Elapsed Time(Seconds)Display.

14.)ESP Indicator–IndicatesAnti-SkipProtection isactivated.

15.)Elapsed Time(Minutes)Display.

LCD DISPLAYINDICATORS

4 5 6 7 8 9 10 11 12

HD8120_022004.p65 20/2/2004, 11:238

OPERATINGINSTRUCTIONS

SPECIAL FUNCTIONS

HOLD Switch

The HOLD switch on the left side of the cabinet must

be in the ‘Off’ (left) position to start the CD player. If

you plan to carry the CD player in a handbag,

briefcase, school bag,backpack,etc,slidethe HOLD

switch to the ‘On’ (right) position. While the HOLD switch is ‘On’ all of the controls

on the CD door are disabled. This prevents the player from starting accidentally by

something pressing against the PLAY/PAUSE button.

After you begin CD playback you may also slide the HOLD switch to the ‘On’ (right)

position to disable all the controls on the CD door. You can then place the player in

a handbag, backpack, etc, and do not have to worry that the player will be

accidentally turned off by something pressing against the STOP button or Track

Skip buttons.

Dynamic Bass Boost (DBB) and Preset Equalizer (EQ) Functions

During CD playback you may press the PROG/EQ button repeatedly to activate

the Dynamic Bass Boost function or select one of the four preset equalizer settings

(POP/CLASSIC/JAZZ/ROCK).

Pressing thePROG/EQ button repeatedly will cycle the player through the following

modes:

DBB (Dynamic Bass Boost ‘On) POP CLASSIC JAZZ ROCK

FLAT (EQ ‘Off’) DBB.

The selected mode will appear in the display for a few seconds and then the PLAY

indicator reappears.

When the disc stops and is removed from the player the EQ returns to the original

default setting (DBB ‘Off’/ EQ ‘Off’).

PLAY

CD HOLD

HD8120_022004.p65 20/2/2004, 11:239
