Elkay HRC2-10-1D User manual

98244C (3/06)

HRC2-10-1D

NOTE: It is important to insure proper ventilation. Allow a

minimum clearance of 6 inches (152 mm) in front and 3

inches (76mm) in the rear of the unit. If unit is to be in-

stalled in an enclosure, allow the following clearances

around unit 1 inch (25mm) each side, 3 inches (76mm) in

the rear, 3 inches (76mm) inches above wall.

This chiller has been designed for use with potable water

and includes an o-ring seal on the drain plug. This fitting

should be replaced if the unit is to be used with more

aggressive fluids.

Refrigeration Packages

Installation Instructions

A=3/8"O.D.TUBEWATEROUT

B=3/8"O.D.TUBE WATER INLET

C=3/8"O.D. TUBE TANKDRAIN

D= TEMPERATUREADJUSTMENT

E=ELECTRICAL

LEGEND:

98244C (3/06)

HRC2-10-1D

27666C

31513C

31490C

30664C

20282C

70018C

70009C

66305C

50189C

66203C

35774C

35818C

36222C

35795C

30180C

36221C

35806C

31797C

30181C

30182C

19037000

100806740570

66311C

27665C

70772C

28399C

27663C

28400C

27664C

27667C

35882C

27669C

27668C

ITEM

NO. 10 GPH

PART NO.

11*

ITEMIZEDPARTS LIST

DESCRIPTION

Cover - Terminal Box

Control - Cold

Motor - Fan

Fan - Blade

Fan - Bracket

Fan - Nut

Screw - Motor Mounting

Condenser

Shroud

Drier

Compr. ServPakEmbraco

Compr. Serv Pak Tecumseh

Overload (Embraco)

Overload (Tecumseh)

Overload Spring (Tecumseh)

Relay (Embraco)

Relay (Tecumseh)

Cover - Relay (Embraco)

Cover - Term (Tecumseh)

Compr. Bale Strap (Tecumseh)

Clip

Grommet

Evaporator - Assy

Cover - Insulation Box

DrainPlug

Base Assy

Panel - Insul Box (Rear)

Panel-End

Box - Insulation (Front)

Terminal Box Assy

Control-Freeze Protect

Grille - Front

Grille - Rear (Not Shown)

8,9 25 21

3, 4, 5, 6, 7

12,13,14

15,16

*INCLUDESRELAY& OVERLOAD. IFUNDER WARRANTY,

REPLACE WITH SAME COMPRESSOR USED IN ORIGINAL

ASSEMBLY.

NOTE: All correspondence pertaining to any of the

above water cooler or orders for repair MUST include

model number and serial number of cooler, name and

part number of replacement part.

NOTE: For use with photo processing applications,

adjust thermostat to warmer settings.
