Electrolux UniRapido User manual

Thank you for choosing an Electrolux UniRapido vacuum cleaner. UniRapido is a rechargeable stick vacuum cleaner intended for use

on light dry household debris. In order to ensure the best results, always use original Electrolux accessories. They have been

designed especially for your vacuum cleaner.

BEFORE STARTING

•Unpack all details and check that the package includes all accessories relating to your UniRapido.

•Read the Instructions for Use carefully.

•Pay special attention to Safety advice chapter.

Enjoy your Electrolux UniRapido!

TABLE OF CONTENTS

Unpacking and charging 3-4

Cleaning the filters and dustcontainer 5

Cleaning brush roll, wheels and bellows 6

Removing the batteries and disposal 7

Safety precuations 8

Consumer information 9

DESCRIPTION OF YOUR UNIRAPIDO

1 Soft touch handle

2 On/off button

3 Charging/running indicator light

4 Container release button

5 Dust container

6 Parking rubber knob

7 Locking screw

8 Brush roll

9 Brush roll release button

10 Hatch cover for brush roll

11 Fine filter (inner filter)

12 Pre filter (outer filter)

13a Charging station, floor unit

13b Charging station, wall unit

14 Adaptor

UNPACKING AND ASSEMBLY

1 Fit the handle by carefully inserting it

into the lower main body Make sure

that the cable does not jam.

2 Secure the handle by tightening the

locking screw supplied Use a

screwdriver or a coin.

1 Position the charging station close to

a mains (well away from heat

sources, direct sunlight or wet

places) Insert the adaptor into the

mains socket and connect it to the

charging station.

2 The wall unit can also be mounted on

a wall Always ensure that the wall

can bear the weight of UniRapido.

CHARGING STATION

UNPACKING AND CHARGING

CHARGING

1 Place UniRapido in the charging

station always make sure that

UniRapido is turned off when placed

in the charging station .

2 charging!

First use: up to 24 hours charging

Fully discharged: 16 - 24 hours charging

Leave UniRapido on charge when not in

use. Warm adaptor is normal.

START/STOP

2 Charging!

1 Start UniRapido by pushing the on/off

button

A Press for start/stop (Start on

maximum cleaning power)

B Press for intermediate power

VACUUMING FLOORS AND CARPETS

Avoid scratching sensitive areas by

checking that nozzle wheels and brush

roll are clean.

CLEANING THE FILTERS AND DUSTCONTAINER

UniRapido’s dust container must be

emptied regularly, plus dust container

and filters need to be cleaned to maintain

a high suction power.

Clean the filters every third emptying or

when UniRapido has low suction power

Make sure parts are dry before

reassembling.

1 Release the whole dust container by

pushing the release button. 2 Take out both filters.

3 Empty the content into a wastepaper

basket. 4 Separate filters. Shake them clean or

rinse separately using warm water.

Make sure fi lters are dry before

reassembling in reverse order.

5 Put the filters back and press back

the dust container in reverse orde.r

CLEANING BRUSH ROLL AND WHEELS

If the brush roll becomes blocked or

jammed, a protection circuit will block the

power supply to the motor. Then clean

the brush.

1 Push the brush roll release button.

The hatch cover will come slightly free

and the brush roll can now be

removed.

2 Carefully use a sharp object to

remove hair or threads. Replace the

brush roll and make sure that it fi ts

into its guiding tracks, and that it can

spin freely. Replace the hatch cover.

1 If the wheels needs to be cleaned,

remove them carefully by using a

small screwdriver.

2 Remove objects that have become

jammed in the wheel shafts.

Reassemble the wheels by pressing

them back into their tracks.

1 Occasionally objects can get stuck in

the bellows, and this can affect

suction power. Clean the bellows

after removing the dust cup.

CLEANING THE BRUSH ROLL

CLEANING THE WHEELS CLEANING THE BELLOWS

DISPOSAL

REMOVING BATTERIES

Only remove batteries if product is to be

scrapped.

1 Run batteries fl at and disconnect

UniRapido from the charging station

Undo the 11 screws (2 of them hidden

under the release button).

2 Release the button and carefully lift

the hood. 3a Unclip the connecting cables and lift

out the batteries Batteries should be

removed from the appliance before it

is scrapped.

3b Unclip the connecting cables and lift

out the batteries Batteries should be

removed from the appliance before it

is scrapped.

Used batteries should always be

taken to a recycling Station.

SAFETY PRECUATIONS

UniRapido should only be used by adults and only for normal vacuuming in adomestic environment. Make sure the vacuum cleaner

is stored in a dry place. Allservicing and repairsmust be carried out by an authorized Electrolux service centre.

This appliance is notintended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

Please remove the plug from the socket outlet before cleaning or maintaining the appliance.

Children should be supervised to ensure that they do not play with the appliance.

Each vacuum cleaner is designed for a specific voltage. Check that your supply voltage is the same as that stated on the rating

plate. Use only the original charging adaptor designed for this model.

Never use the vacuum cleaner

•In wet areas.

•Close to flammable gases, etc.

•When housing shows visible signs of damage.

•On sharp objects or fluids.

•On hot or cold cinders, lighted cigarette butts, etc.

•On fine dust, for instance from plaster, concrete, flour, hot or cold ashes.

•Do not leave the vacuum cleaner in direct sunlight.

•Avoid exposing the vacuum cleaner or battery to strong heat.

•The battery must not be dismantled, shortcircuited, placed against a metal surface or exposed to strong heat.

•Without filter.

Using the vacuum cleaner in the above circumstances may cause serious damage to the product. Such damage is not covered by

the warranty.

Servicing or repairs

In cases of breakdown or faults, your UniRapido must be taken to an authorized Electrolux service centre. If the supply cord is

damaged, it must be replaced by Electrolux or its service agent or a similarly qualified person in order to avoid a hazard.

CONSUMER INFORMATION

Electrolux decline all responsibility for all damages arising from any improper use of the appliance or in cases of tampering

with the appliance.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person in order to

avoid a hazard.

This product is designed with the environment in mind. All plastic parts are marked for recycling purposes.

For details see our web site:

www.electrolux.com

If you have any comments on the cleaner or the Instructions for Use booklet please e-mail us at:

[email protected]

If you can´t find accessories to your Electrolux vacuum cleaner, please visit our website at

www.electrolux.co.uk

or call 08706 055 055.
