Electrolux 726202 User manual

Electrolux benefit counters

Remote refrigerating unit

The Electrolux range of benefit counters combines the convenience of worktop space with cold storage. The

models detailed on this sheet are benefit counters with a remote refrigerating unit and with various

combinations of doors and drawers.

Model 726203

CONSTRUCTION

• Internal and external doors, front

and side panels and removable

worktop (50mm thick) in 304 AISI

stainless steel.

• Back in galvanized steel.

• Insulation guaranteed by high

density expanded cyclopenthane

50 mm in thickness.

• Legs (150 mm high) in 304 AISI

stainless steel with plastic interior

and adjustable in height.

• CFC and HCFC free.

• All models comply with the

standards required by the main

international approval bodies and

are H marked.

PERFORMANCES

• Digital control panel allowing the

easy and precise setting and

control of the internal temperature.

• Completely automatic defrosting.

• Forced air cooling system

guaranteeing great uniformity of

the temperature in the counter and

excellent conservation of the food

quality.

• Operating temperature:

-2/+10ºC.

• Refrigerant gas R404a.

• Possibility to install on socklet.

• Kit with 1/2 sized drawers

available as accessory.

• The refrigeration unit can

operate in tropical climates (+43°C

ambient temperature).

• High standards of hygiene and

ease of cleaning are guaranteed

by the rounded internal corners of

the cabinet and easily removable

runners and grids (without the use

of tools).

• The door self-closes when

opened less than at a 90° angle

and is equipped with a door seal

to guarantee perfect closure.

Electrolux benefit counters

Remote refrigerating unit

Internet: http://www.electrolux.com/foodservice

HBAD0602010-05-28Subject to change without notice

TWO ½ DRAWER KIT 880023 880023 880023

STRUCTURE TO SUPPORT 3 GRIDS(RIGHT+LEFT) 880047 880047 880047

S/S STRUCTURE TO SUPPORT 6 GRIDS (R+L) 880140 880140 880140

REMOTE UNIT FOR 4 DOOR REFRIG.TABLES 880045

REMOTE UNIT FOR 2-3 DOOR REFRIG.TABLES 880044 880044

PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457

PLASTIC CONTAINER GN 1/1 H=65 MM 881038 881038 881038

PLASTIC CONTAINER GN 1/1 H=150 MM 881040 881040 881040

LOCK KIT 880024 880024 880024

KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205 880205

KIT HACCP EKIS 922166 922166 922166

KIT DOOR REVERSIBILITY FOR REF.TABLES 880046 880046 880046

KIT 4 WHEELS (2 W/BRAKE)+4 (40MM)SPACERS 880025 880025 880025

KIT 2 S/S GRIDS GN1/1 FOR REFRIG.TABLES 880139 880139 880139

AUTOMATIC DEFROST WITH WASTE EVAPORATION 880028 880028 880028

ACCESSORIES

1/1 GN GREY "RILSAN" GRID 2 3 4

INCLUDED ACCESSORIES

Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

Net weight - kg. 107 130 174

Noise level - dBA 48 48 48

installed-electric 0.009 0.015 0.009

Power - kW

at evaporation temperature - °C -23 -20 -20

Refrigerant power

Refrigerant type R404a R404a R404a

N° defrost in 24 hrs. every 6 hours every 6 hours every 6 hours

N° and type of grids (included) 2, GN 1/1 3, GN 1/1 4, GN 1/1

Door hinges 1 Left+1 Right 1 Left+2 Right 2 Left+2 Right

Door - n. 2 3 4

Min/Max internal humidity - % 50 50 50

Top material 304 AISI 304 AISI 304 AISI

Worktop type Stainless Steel Stainless Steel Stainless Steel

height 850 850 850

depth/with open doors 700, 1102 700, 1102 700, 1102

width 1108 1587 2071

External dimensions - mm

Control type Digital Digital Digital

Cooling unit Remote Remote Remote

Gross capacity (D.I.N. 8952) - l. 265 415 560

Operating mode Ventilated Ventilated Ventilated

Operating temperature - min/max °C -2/10 -2/10 -2/10

TECHNICAL DATA

RCSN2M2R

726202

RCSN3M3R

726210

RCSN4M4R

726213

Electrolux benefit counters

Remote refrigerating unit

Internet: http://www.electrolux.com/foodservice

HBAD0602010-05-28Subject to change without notice

EI - Electrical connection 230 V, 1N, 50

ED - Remote electrical connection ●

D - Water drain 16mm

LEGEND

RCSN2M2R

726202

Electrolux benefit counters

Remote refrigerating unit

Internet: http://www.electrolux.com/foodservice

HBAD0602010-05-28Subject to change without notice

EI - Electrical connection 230 V, 1N, 50

ED - Remote electrical connection ●

D - Water drain 16mm

LEGEND

RCSN3M3R

726210

Electrolux benefit counters

Remote refrigerating unit

Internet: http://www.electrolux.com/foodservice

HBAD0602010-05-28Subject to change without notice

EI - Electrical connection 230 V, 1N, 50

ED - Remote electrical connection ●

D - Water drain 16mm

LEGEND

RCSN4M4R

726213
