Electrolux EZB3400AOX User manual

EZB3400AOX

User Manual

Oven

electrolux.com/register

Welcome to Electrolux! Thank you for choosing our appliance.

In our drive to be sustainable, we are reducing paper assets and provide full user

manuals online. Access your full user manual at electrolux.com/manuals

Get usage advice, brochures, trouble shooter, service and repair information at

electrolux.com/support

1. PRODUCT DESCRIPTION

1.1 General overview

1 43 52 6

1Control panel

2Power lamp / symbol

3Knob for the heating functions

4Display

5Control knob (for the temperature)

6Temperature indicator / symbol

7Air vents for the cooling fan

8Heating element

9Lamp

10 Fan

11 Shelf support, removable

12 Shelf positions

2. CONTROL PANEL

2.1 Sensor fields / Buttons

To set the time.

To set a clock function.

To set the time.

2 ENGLISH

2.2 Display

A B

A. Clock functions

B. Timer

3. BEFORE FIRST USE

3.1 Before first use

The oven can emit an odour and smoke during preheating. Make sure that the room is

ventilated.

Step 1 Step 2 Step 3

Set the clock Clean the oven Preheat the empty oven

1. Press: .

2. , - press to set the hour.

Press: .

3. , - press to set the mi‐

nutes. Press: .

1. Remove all accessories and re‐

movable shelf supports from

the oven.

2. Clean the oven and the acces‐

sories with a soft cloth, warm

water and a mild detergent.

1. Set the maximum temperature

for the function: .

Time: 1 h.

2. Set the maximum temperature

for the function: .

Time: 15 min.

3. Set the maximum temperature

for the function: .

Time: 15 min.

Turn off the oven and wait until it is cold. Place the accessories and the removable shelf supports in the oven.

4. DAILY USE

4.1 How to set: Heating function

Step 1 Turn the knob for the heating functions

to select a heating function.

Step 2 Turn the control knob to select the tem‐

perature.

Step 3 When the cooking ends, turn the knobs

to the off position to turn off the oven.

4.2 Heating functions

Oven function Application

The oven is off.

Oven light

Even baking, tenderness, drying

Energy saving

Preserving food

ENGLISH 3

Oven function Application

Defrosting

Toasting, grilling

Roasting meat, making gratin,

browning

Traditional baking, crispiness,

crust gloss

4.3 Notes on: Moist Fan Baking

This function was used to comply with the

energy efficiency class and ecodesign

requirements according to EU 65/2014 and

EU 66/2014. Tests according to EN 60350-1.

The oven door should be closed during

cooking so that the function is not interrupted

and the oven operates with the highest

energy efficiency possible.

For the cooking instructions refer to "Hints

and tips" chapter, Moist Fan Baking. For

general energy saving recommendations

refer to "Energy Efficiency" chapter, Energy

Saving.

5. CARE AND CLEANING

5.1 Notes on cleaning

Cleaning Agents

Clean the front of the oven with a soft cloth with warm water and a mild detergent. Clean and

check the door gasket around the frame of the cavity.

Use a cleaning solution to clean metal surfaces.

Clean stains with a mild detergent.

Everyday Use

Clean the cavity after each use. Fat accumulation or other residue may cause fire.

Moisture can condense in the oven or on the door glass panels. To decrease the condensa‐

tion, let the oven work for 10 minutes before cooking. Do not store the food in the oven for

longer than 20 minutes. Dry the cavity with a soft cloth after each use.

Accessories

Clean all accessories after each use and let them dry. Use a soft cloth with warm water and

a mild detergent. Do not clean the accessories in a dishwasher.

Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects.

6. TROUBLESHOOTING

6.1 What to do if...

In any cases not included in this table please

contact with an Authorised Service Centre.

Problem Check if...

The oven does not heat

up.

The fuse is blown.

4 ENGLISH

Problem Check if...

The door gasket is dam‐

aged.

Do not use the oven.

Contact an Authorised

Service Centre.

The display shows

"12.00".

There was a power cut.

Set the time of day.

The lamp does not work. The lamp is burnt out.

6.2 Service data

If you cannot find a solution to the problem

yourself, contact your dealer or an

Authorised Service Centre.

The necessary data for the service centre is

on the rating plate. The rating plate is on the

front frame of the oven cavity. Do not remove

the rating plate from the oven cavity.

We recommend that you write the data here:

Model (MOD.) .........................................

Product number (PNC) .........................................

Serial number (S.N.) .........................................

7. ENERGY EFFICIENCY

7.1 Product Information and Product Information Sheet*

Supplier's name Electrolux

Model identification EZB3400AOX 944064908

Energy Efficiency Index 94.9

Energy efficiency class A

Energy consumption with a standard load, conventional mode 0.83 kWh/cycle

Energy consumption with a standard load, fan-forced mode 0.75 kWh/cycle

Number of cavities 1

Heat source Electricity

Volume 57 l

Type of oven Built-In Oven

Mass 28.6 kg

* For European Union according to EU Regulations 65/2014 and 66/2014.

For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017, Annexes A and B.

For Ukraine according to 568/32020.

Energy efficiency class is not applicable for Russia.

EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods

for measuring performance.

7.2 Energy saving

The oven has features which

help you save energy during

everyday cooking.

Make sure that the oven door is closed when

the oven operates. Do not open the oven

door too often during cooking. Keep the door

gasket clean and make sure it is well fixed in

its position.

ENGLISH 5

Use metal cookware to improve energy

saving.

When possible, do not preheat the oven

before cooking.

Keep breaks between baking as short as

possible when you prepare a few dishes at

one time.

Cooking with fan

When possible, use the cooking functions

with fan to save energy.

Residual heat

When the cooking duration is longer than 30

min, reduce the oven temperature to

minimum 3 - 10 min before the end of

cooking. The residual heat inside the oven

will continue to cook.

Use the residual heat to warm up other

dishes.

Keep food warm

Choose the lowest possible temperature

setting to use residual heat and keep a meal

warm.

Moist Fan Baking

Function designed to save energy during

cooking.

8. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put

the packaging in relevant containers to

recycle it. Help protect the environment and

human health by recycling waste of electrical

and electronic appliances. Do not dispose of

appliances marked with the symbol with

the household waste. Return the product to

your local recycling facility or contact your

municipal office.

6 ENGLISH

867360570-A-522020
