Electrolux EOC68000 User manual

user manual

Built-In Electric Oven

EOC68000

We were thinking of you

when we made this product

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class

product from Electrolux, which hopefully

will provide you with lots of pleasure in

the future. The Electrolux ambition is to

offer a wide variety of quality products

that make your life more comfortable.

You will find some examples on the cov-

er in this manual. Please take a few min-

utes to study this manual so that you

can take advantage of the benefits of

your new machine. We promise that it

will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

4electrolux contents

Contents

Safety instructions 5

Description of the Appliance 7

Before Using for the first time 13

Using the Oven 15

Cleaning and Care 51

What to do if … 63

Installation Instructions 64

Disposal 69

Guarantee/Customer

Service 70

Index 72

Service 74

he following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

3General information and tips

2Environmental information

safety instructions electrolux 5

Safety instructions

This appliance conforms with the

following EU Directives:

–73/23/EEC dated 19.02.1973 Low

Voltage Directive

–89/336/EEC dated 03.05.1989 EMC

Directive inclusive of Amending Di-

rective 92/31/EEC

–93/68/EEC dated 22.07.1993 CE

Marking Directive

Electrical safety

•This appliance must be only con-

nected by a registered electrician.

•In the event of a fault or damage to

the appliance: Take the fuses out or

switch off.

•Repairs to the appliance must only

be carried out by qualified service

engineers. Considerable danger

may result from improper repairs. If

repairs become necessary, please

contact our Customer Services or

your dealer.

Child Safety

•Never leave children unsupervised

when the appliance is in use.

Safety whilst Using

•This appliance is intended to be

used for cooking, roasting and bak-

ing food in the home.

•Take care when connecting electric

appliances to sockets nearby. Do

not allow connecting leads to come

into contact with or to catch beneath

the hot oven door.

•Warning: Risk of burns! The interi-

or of the oven becomes hot during

use.

•Using ingredients containing alcohol

in the oven may create an alcohol-air

mixture that is easily ignited. In this

case, open the door carefully. Do not

have embers, sparks or naked

flames in the vicinity when opening

the door.

Information on acrylamides

According to the latest scientific

knowledge, intensive browning of

food, especially in products con-

taining starch, can constitute a

health risk due to acrylamides.

Therefore we recommend cooking

at the lowest possible temperatures

and not browning foods too much.

6electrolux safety instructions

How to avoid damage to the

appliance

•Do not line the oven with aluminium

foil and do not place baking trays,

pots, etc. on the oven floor, as the

heat that builds up will damage the

oven enamel.

•Fruit juices dripping from the baking

tray will leave stains, which you will

not be able to remove. For very moist

cakes, use a deep tray.

•Do not put any strain on the oven

door when open.

•Never pour water directly into the

oven when it is hot. This could cause

damage to or discoloration of the

enamel.

•Rough handling, especially around

the edges of the front panel, can

cause the glass to break.

•Do not store any flammable materi-

als inside the oven. These could ig-

nite when the oven is switched on.

•Do not store any moist foods inside

the oven. This could damage the

oven enamel.

•After switching off the cooling fan, do

not keep uncovered dishes in the ov-

en. Moisture may condense in the

oven interior or on the glass doors

and may get into the units.

Note on enamel coating

Changes in the colour of the oven’s

enamel coating as a result of use do not

affect the appliance’s suitability for nor-

mal and correct use. They therefore do

not constitute a defect in the sense of

the warranty law.

description of the appliance electrolux 7

Description of the Appliance

General Overview

The oven switches off after 2 min-

utes, if no function is selected and is

changed at the oven nothing, the

light remains however on.

In order to switch off the light bar,

oven switch on with and switch

off again.

Oven door

Oven displays

and Touch Control sensor fields

Door

handle

Light bars.

8electrolux description of the appliance

The electronic oven controls

Indicators

Symbols

Various symbols will now be shown in

the display depending on the selected

function.

Menu option symbol

(with oven shelf level)

Clock

Time functions

Heat indicator

Temperature

Weight

Symbol Display

(examples) Function

Short timer 4:30 The short timer is active.

Time 10:00 Shows the set time.

Duration

1:00 Shows the time required for the cooking cycle.

End Time

14:05 Shows when the cooking cycle will finish.

End time calculated when

Meatprobe

is inserted.

Start 0:45 Shows when the cooking cycle started.

Temperature Shows the temperature the oven has reached.

Quick heat is active (reduced heating-up time).

Weight 1.5 kg Possibilities:

–

Automatic weight system is active.

–

Weight can be changed.

Meatprobe

75°C Possibilities:

–Meatprobe

is inserted.

–Meatprobe Automatic

is active.

–

Core temperature can be changed.

Heat+Hold

80°C

Heat+Hold

is activated.

Odour filter The odour filter is switched on.

description of the appliance electrolux 9

Touch Control sensor fields

The appliance is operated using Touch

Control sensor fields. You control the

functions by touching the sensor fields.

When you are using the controls

make sure that you only touch one

sensor field. If your finger is applied

too flat, a neighbouring sensor field

could be touched as well.

On/Off Set values

Main menu

Scroll

Select

options

Confirm

10 electrolux description of the appliance

Sensor

field Function Comment

, To move down and up in the

menu.

When a function is active:

•

Press once: Change to the higher menu

(function remains active), after 5 seconds

move again into the active menu option

•

Press twice: Up and down in the higher

menu (function switches off)

To display main menu. Functions set switch off

(except for countdown timer).

To confirm.

To switch appliance on or off.

To select time functions, addi-

tional functions and

Meat-

probe

, To set values (e.g. temperature,

time, weight, degree of cook-

ing).

•

To activate value:

–

Press once: Present symbol flashes

–

Press twice: Value can be set

•

To set values:

–

Press once: To set value in single steps

–

Hold down key: To set value in fast steps

•

When setting a cook time or time the dis-

play can be re-set to zero if

and are

pressed at the same time.
