Thank you for choosing one of our high-quality products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfectly

and most efficiently. To refer to this manual any time you need to, we recommend

you to keep it in a safe place. And please pass it to any future owner of the appliance.

We wish you much joy with your new appliance.

Contents

Operating instructions 3

Safety information 3

Electrical safety 3

Safety during use 3

How to avoid damage to the appliance

Description of appliance 4

General view 4

Control panel 5

Display 5

Oven layout 6

The electronic oven controls 7

Menus and operation 7

Auto Cooking 8

Heating Functions 9

Specials 9

Basic Settings 10

Cleaning Menu 10

Additional Functions 10

Operation 11

Prior to first use 11

Switching on and off 11

Auto cooking 11

Conventional baking and roasting 12

Meatprobe 13

Setting the countdown timer 14

Key Lock 14

Switch-on lock 14

Automatic switch-off of the oven 14

Smell Filter 15

Inserting the grill rack, baking tray, and

roasting pan 15

Inserting/Removing the Grease Filter 16

option 17

Tips, charts and information 18

Auto Cooking 18

Manual baking and roasting 24

Cleaning and servicing 33

Grease filter 33

Pyrolytic cleaning 34

Cleaning Assistant 34

Cleaning Reminder 34

Shelf supports 34

Oven light 35

Oven door 36

Oven door glass 38

What to do if ... 41

Disposal 42

Subject to change without notice

2Contents

Operating instructions

Safety information

Electrical safety

•This appliance must only be connected by a qualified installation engineer.

• In the event of a fault or damage to the appliance: Take the fuses out or switch off.

•Repairs to the appliance must only be carried out by qualified service engineers.

Considerable danger may result from improper repairs. If repairs become necessary,

please contact our Customer Care Department or your dealer.

Children's safety

• Never leave small children unattended while the appliance is in operation.

• To protect against unauthorised use the appliance is equipped with a switch-on lock.

Safety during use

• This appliance should be used only for normal domestic cooking, roasting and baking of

food.

• Be careful if connecting electrical appliances to sockets near to this appliance. Electrical

leads must not be caught under the hot oven door.

•Warning: Risk of burns! The interior surfaces of the oven become very hot during use.

• If you use ingredients containing alcohol in the oven, a slightly flammable mixture of

alcohol and air may ensue. In this case, be careful when opening the door. Do not handle

any sources of heat, sparks or naked flames when doing so.

• People (including children), who, because of their physical, sensory or mental capabilities

or their inexperience or ignorance, are not able to use the appliance safely, should not

use this appliance without supervision by or instruction from a responsible person.

Information on acrylamides

According to the latest scientific knowledge, intensive browning of food, especially in

products containing starch, can constitute a health risk due to acrylamides. Therefore we

recommend cooking at the lowest possible temperatures and not browning foods too much.

How to avoid damage to the appliance

• Do not line the oven with aluminium foil and do not place a baking tray or saucepan

etc. on the floor, as otherwise the oven enamel will be damaged by the heat build-up.

• Fruit juices dripping from the baking tray will leave stains, which you will not be able to

remove. For very moist cakes, use a deep tray.

• Do not put any strain on the oven door when open.

• Never pour water directly into the oven when it is hot. This could cause damage to and

discoloration of the enamel.

• Rough handling, especially around the edges of the front panel, can cause the glass to

break.

• Do not store any flammable materials inside the oven. These could ignite when the oven

is switched on.

• Do not store any moist foods inside the oven. This could cause damage to the enamel.

Safety information 3

• Do not leave dishes uncovered in the oven after switching off the cooling fan. Moisture

may form inside the oven or on the glass door and also get onto the units.

Information on the oven enamel

Changes to the colour of the oven's enamel surface as a result of use do not affect the

appliance's suitability for normal and correct use. They therefore do not constitute a defect

in terms of warranty law.

Description of appliance

General view

1Control panel

4Description of appliance

2Oven door

Control panel

Overview

2 1

3 4

1AN/AUS-Button: to switch on, press and hold for longer

2Display

3Turning knob with OK button to select a menu option

4Additional functions key

5Sensor button to select a cooking category

Display

The information shown in the display varies according to the oven's operating status.

If the oven has been switched off, the time of day is shown. If the oven is still hot, a bar

appears in the display and shows the residual heat remaining in the oven.

When the oven is switched on, the display shows the menu and information about the

oven's operating status.

Symbols

Minute Minder

Time of Day

Duration

End Time

Running Time

Oven Temperature

Calculation

Rapid Heat Up

Temperature Display

Description of appliance 5

Oven layout

1Top heat and grill elements

2Oven light

3Meat probe connector

4Grease filter

5Oven light

6Ring heating element, fan

7Bottom oven element

8Side rails, removable

9Oven levels

10 Rotary spit drive mechanism

11 Smell Filter

Oven accessories

Baking tray

For cakes and biscuits.

Drip pan

For baking and roasting or for use as atray to catch

fat.

Shelf

For cookware, cake tins, roasts and grilling food.

Meat probe

6Description of appliance

For determining exactly how well done pieces of

meat are during cooking.

Rotary spit with support

For roasting larger joints of meat and poultry.

The electronic oven controls

Menus and operation

You use the menu to operate the oven. The Main Menu contains:

Main Menu

Auto Cooking

Heating Functions

Cleaning Menu

Basic Settings

Specials

Selecting the menu options

• Turn the knob clockwise to get to the next function.

• Turn the knob anti-clockwise to get to the previous menu option.

Opening the main menu

Press the On/Off button to get to the main menu. The Auto Cooking function is selected

by default.

Opening the menu Auto Cooking

Press the On/Off button to get to the main menu. The Auto Cooking function is selected

by default.

1. Press the sensor key for the category you want.

2. Use the knob to select the menu or subcategory you want.

3. Follow the instructions in the display.

The electronic oven controls 7

Selecting a menu option in the menu

1. Select the menu option you want by turning the knob.

2. When the menu option you want is shown in the display, press the OK button to call

it up.

"back" at the end of each menu takes you back to the previous menu

Auto Cooking

General

The menu "Auto Cooking" Is divided into five subcategories. Use these categories to select

the optimum setting for a variety of dishes. Press the relevant sensor key. The categories

are divided into various subcategories and dishes, which are then programmed with the

appropriate settings.

Refer to the supplier quick guide for an overview of all the categories and dishes from the

Auto Cooking menu. For help on how the dishes have been classified into the various

categories, see the supplied Cooking and Baking Overview.

Symbol Category

Baking

Roasting

Convenience

Oven dishes

Pan pizza

Principle

With Auto Cooking , the oven calculates the cooked time needed.

Unlike conventional cooking, you do not need to set a type of heat or cooking time. Instead,

you simply select the desired food type from the category menu.

" You can use Auto Cooking on one oven level only.

Only use the fat filter when roasting! Otherwise the oven cannot calculate an optimal

cooking time.

To attain optimum results, you should use the recommended cookware and/or accessories.

You can find further information in the section Tips, Charts and Advice.

8The electronic oven controls

Heating Functions

To manually set Heating Functions and cooking temperature.

Heating Functions

Fan Cooking For baking on up to three levels simultaneously.

Set the oven temperatures 20 – 40° lower than

Conventional Cooking

Conventional Cooking For baking and roasting on one level

Pizza Setting For baking on one oven level dishes that require

more intensive browning and a crispy base. Set

the oven temperatures 20 – 40° lower than Con-

ventional Cooking

Turbo Grill For roasting larger joints of meat or poultry on

one level. Also suitable for gratinating and

browning.

Turbo Grill + Spit Roast Especially for poultry, temperature setting

190-210°C

Economy Grill For grilling flat foods which are placed in the

middle of the rack and for toasting.

Economy Grill + Spit Roast For grilling a chicken or small rolled roasts

Dual Grill For grilling flat foods in large quantities and for

toasting.

Dual Grill + Spit Roast For grilling two chickens or one rolled roast

Bottom Heat For baking cakes with crispy or crusty bases.

Slow Cook For preparing particularly tender, succulent

roasts

Specials

For selecting additional heating functions

Special functions

Defrost

Drying

Keep Warm

Preserving

Plate Warming

The electronic oven controls 9

Basic Settings

To change different oven Basic Settings.

Basic Settings

Set Time of Day To set current time on the clock

Time Indication When on, the time of day is displayed when the

oven is switched off

When off, the display switches itself off com-

pletely

Display Contrast Adjusts the display

Display Brightness Adjusts the display

Set Language

Buzzer Volume

Key Tones Switches key tones on or off

Alarm/Error Tones Switches alarm tones on or off

Smell Filter Smell Filter Activating or deactivating

Calibration Adapts oven to the kitchen environment, e. g.

after moving house

Service Indicates the version of the software, the con-

figuration and the period of operation

Factory Settings Resets all basic settings to the original factory

settings

Cleaning Menu

Pyrolytic cleaning and other functions.

Cleaning menu

Pyrolytic To clean the oven using pyrolytic cleaning

Cleaning Assistant Reminds you of various points that should be

noted prior to pyrolytic cleaning. Can be switch-

ed on or off.

Cleaning Reminder Recognises when pyrolytic cleaning is required

and alerts the user to this fact. Can be switched

on or off.

Additional Functions

You can use the Additional Functions key to set the available Additional Functions.

Additional functions menu

Minute Minder

Key Lock

Duration / End Time

Meatprobe

10 The electronic oven controls

Table of contents

Other Electrolux Oven manuals

Electrolux

Electrolux EOC6697 Operation manual

Electrolux

Electrolux EBGL70 User manual

Electrolux

Electrolux EOB68000 User manual

Electrolux

Electrolux EOD6335 User manual

Electrolux

Electrolux E30EW85EPS - Icon 30" Professional Series Electric Double... User manual

Electrolux

Electrolux EOD5330 User manual

Electrolux

Electrolux OKE6P71X User manual

Electrolux

Electrolux EOR3420 User manual

Electrolux

Electrolux EOB5851AO User manual

Electrolux

Electrolux CKP720V User manual

Electrolux

Electrolux EON 3710 User manual

Electrolux

Electrolux EOD67043X User manual

Electrolux

Electrolux EOT1513X User manual

Electrolux

Electrolux EOD6P77WX User manual

Electrolux

Electrolux EI30EW45KW3 User manual

Electrolux

Electrolux EW30DF65GB - 30" Dual Fuel Range User manual

Electrolux

Electrolux EOD33003 User manual

Electrolux

Electrolux EH7K1-2WE User manual

Electrolux

Electrolux E30EW85EPS1 User manual

Electrolux

Electrolux EOB8851AA User manual

Electrolux

Electrolux Air-O-Steam 267005 User manual

Electrolux

Electrolux KOCDP60X User manual

Electrolux

Electrolux EDB705SV User manual

Electrolux

Electrolux EOB5440AO User manual

Popular Oven manuals by other brands

Bosch

Bosch HVA531NS0 instruction manual

NEFF

NEFF B44S32 5GB Series instruction manual

Combi

Combi BLODGETT BC142GDS Specifications

AEG

AEG COMPETENCE 311704300 Installation and operating instructions

Falcon

Falcon DOMINATOR PLUS G3106 Series Servicing instructions

Rational

Rational SCC WE 61G installation manual

Smeg

Smeg DOSPA38X User manuals

Miele

Miele HR 1954-2 operating instructions

KHIND

KHIND OT50 instruction manual

Henny Penny

Henny Penny Smoker Box installation manual

Lang

Lang ECOD-AP Installation and operation instructions

AEG

AEG BEK455310M user manual

Frigidaire

Frigidaire FNGE90JGR user manual

Hotpoint

Hotpoint FE9 S831 JSH IX user manual

GE Advantium SCB2000 owner's manual

AEG

AEG DE401301DM user manual

DeLonghi

DeLonghi XA660 Directions for use

AEG

AEG BEB331010M user manual
