Electrolux RS06F41FG 727127 Instruction manual
Electrolux Benefit Cabinets
Digital freezers - 600 lt
The models detailed on this sheet are 600 liter fan assisted refrigeration cabinets that offer
excellent standards in terms of performance and efficiency. They come in various types of
materials (304 AISI, stainless steel or white painted steel) and are available with solid
doors, either full or half height. Model RS06FX1FR has a remote refrigeration unit.
727127
• External panels in 304 AISI,
stainless steel or white coated
galvanized steel. Galvanized steel
back panel and stainless steel
bottom panel as standard on all
models.
• Digital control panel allowing the
easy and precise setting and
control of the internal temperature.
• Completely automatic defrosting
and automatic evaporation of
defrost water (304 AISI models),
manual emptying of defrost water
(stainless steel models).
• Internal panels and door in 304
AISI or stainless steel .
• 150 mm height adjustable feet.
• High standards of hygiene and
ease of cleaning are guaranteed
by the rounded internal corners of
the cabinet and easily removable
runners and grids (without the use
of tools).
• The refrigeration unit can
operate in tropical climates (+43°C
ambient temperature).
• Excellent forced air cooling
system that ensures the utmost
uniformity of temperature in the
cabinet and guarantees a perfect
storage quality of the goods.
• High-density expanded
polyurethane insulating foam, 60
mm in thickness, with
cyclopenthane injection,
guarantees exceptional, long-term
insulation and notable energy
savings.
• The rational use of the internal
space of the refrigerator
guarantees a large storage area
suitable to contain 2/1 GN grids.
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.it/foodservice
HAEB0102009-07-04
PRINTER HACCP BASIC VERS-REF.DIGIT.CONTR 881457 881457
2/1 GN GREY "RILSAN" GRID 880720 880720
2 WHEELS FOR REFRIGERATORS/REFRIG.TABLES 880539 880539
ACCESSORIES
2/1 GN GREY "RILSAN" GRID 3 3
INCLUDED ACCESSORIES
Supply voltage 230 V, 1N, 50 230 V, 1, 50
Net weight - kg. 134 134
installed-electric 0.66 0.66
Power - kW
Refrigeration power - W 780 780
Refrigerant quantity - g. 300 300
Refrigerant type R404a R404a
N° defrost in 24 hrs. 4/30' 4/30'
N° and type of grids (included) 3, GN 2/1 3, GN 2/1
Door hinges Right Side Right Side
height 2000 2000
depth/with open doors 788, 1440 788, 1440
width 720 720
External dimensions - mm
Cooling unit Built-In Built-In
Gross capacity (D.I.N. 8952) - l. 600 600
internal AISI 430 304 AISI
external AISI 430 304 AISI
Type of stainless steel
Operating mode Ventilated Ventilated
Operating temperature - min/max °C -22/-15 -22/-15
TECHNICAL DATA
RS06F41FG
727127
RS06FX1F
726318
• Reversible self-closing door, in
positions less than 90°, with a
stop at 95° and a maximum
opening at 180°, equipped with a
magnetic door seal to guarantee
perfect closure. The pressed
stainless steel recessed door
handle without joints makes
opening the cabinet extremely
easy. All the doors are fitted as
standard with locks and keys and
a microswitch to switch off the fan
when the door is opened.
• Feet with stainless steel finish.
• A wide range of optional
accessories are available.
• Extremely quiet operation at 51
Db(A).
• CFC and HCFC free.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.it/foodservice
HAEB0102009-07-04
EI - Electrical connection 230 V, 1N, 50
LEGEND
RS06F41FG
727127
727127
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.it/foodservice
HAEB0102009-07-04
EI - Electrical connection 230 V, 1, 50
LEGEND
RS06FX1F
726318
726318
