Edimax BR-6215SRg User manual

Wireless LAN NAS Router

Wireless NAS / PS Router

Integrated 2 Ports NAS / Print Server

lP Sharing

The NAT/NAPT function lets you share the broadband connection to

all the Intranet users (up to 253 users). It also provides virtual server

and virtual DMZ functions to let your internal servers be accessed

from the Internet.

Wireless Access Point (4dBi antenna)

The Wireless access point function can let your IEEE 802.11g/b

wireless client devices access the Intranet and Internet through this

router and provide higher throughput and better coverage than normal

802.11g/b.

Supports Network Attached Storage (NAS) via USB ports

NAS supports following protocols: Windows File Sharing, FTP File

Sharing, HTTP File Sharing (WebDAV-http upload), APPLE File

Sharing.

Supports Peer-to-Peer Printing

Supports Peer-to-Peer printing. LAN clients can connect directly with

the print server to execute printing jobs (Peer-to-Peer printing)

Provides Completed Printing Methods

The print server provides LPR and IPP printing method. You can

choose the best printing method according to your environment.

Please check the printers compatibility list in our web site

Web Configuration

Configure the router through the friendly Web user interface with a

browser.

USB 2.0 X 2USB Ports

802.11g/bWireless Type

12V DC, 1.5APower

10/100 UTP X 1WAN Port

Ralink RT2661RF

10/100 UTP X 4LAN Ports

18dBm ±2dBmTransmit Power

2 MB NOR Flash / 32 MB SDRAMFlash / RAM

FCC Class B, CE MarkCertification

10~ 90% (Non-Condensing)Humidity

10 ~40°CTemperature

30(H) x 187(W) x 100(D) mmDimension

Realtek RTL8305SC (5 Port Switch)Switch

RDC 3210CPU

4dBi Antenna x 1Antenna

BR-6215SRg

Model NO.

Taiwan / Headquarters

Edimax Technology Co., LTD.

TEL:886-2-7739-6888

FAX:886-2-7739-6887

[email protected]

China

Beijing Edimax Science &

Technology Co., LTD.

TEL:8610-6213-9288

FAX:8610-6213-9231

[email protected]

Europe

Edimax Technology Europe B.V.

TEL:31-499-377344

FAX:31-499-372647

[email protected]

Latin America

TEL:1-786-845-8099

FAX:1-786-331-8490

[email protected]

Poland

Edimax Technology Europe

B.V. SP. Z O.O.

Tel: +48(22)-6060-255

Fax: +48(22)-6060-254

[email protected]

U.S.A.

Edimax Computer Company

TEL:1-408-496-1105

FAX:1-408-980-1530

[email protected]

U.K.

Edimax Technology (UK) Ltd.

TEL:44-870-7740226

FAX:44-870-7740227

info@edimax.co.uk

Features

•Supports NAT/NAPT IP Sharing

•Supports Anti-DoS Firewall and Virtual Server/DMZ

•IEEE 802.11g Access Point

•Supports 64/128 Bit Key Length WEP Encryption

•Supports WPA-PSK, WPA-Radius, WPA2 Security

•Provides two USB 2.0 port to connect to printer and USB storage.

•Windows File Sharing, FTP File Sharing, HTTP File Sharing

(WebDAV-http upload), APPLE File Sharing.

•User/Group based Permission Control and Folder Based

Permission Control.

•Obtains WAN IP by PPPoE/Static IP/PPTP/DHCP

•DHCP Server

•Web User Interface (Remote Configuration)

•System Status

•Security Log

•Firmware Upgrade

Wireless LAN NAS Router
