EdgeStar BR1500BL User manual
Undercounter Kegerator
Owner’s Manual
V2.5-06092021www.edgestar.com
BR1500BL / BR1500SS
BR1500SSOD
2
Important Safety Information
Electrical Safety
Improper handling can cause serious damage to the EdgeStar kegerator and / or injury to the user. This
kegerator is designed for domestic use only. Do not use the unit for industrial or commercial use.
Any other use may invalidate the warranty. Please review the ratings label located on the rear panel of
the unit for electrical and other technical data related to this unit. The unit must be used in a properly
grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of re, electric
shock, or injury.
• Do not exceed the power outlet ratings.
• It is recommended the kegerator be connected on its own circuit.
• The unit must be installed in accordance with state and local electrical codes.
• A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the National
Electrical Code and local codes and ordinances is required.
• Use outlets that cannot be turned o by a switch or pull chain.
• Always turn the unit o and unplug it from the outlet when cleaning.
• Unplug the unit if it is not going to be used for an extended period of time.
• Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
• Be sure the kegerator is properly grounded.
• Avoid installation in high humidity environments such as bathrooms and non-acclimatized
basements. Excess moisture may create condensation on the door and impact the performance of
the kegerator.
• Never plug or unplug the unit with wet hands.
• Do not bypass, cut, or remove the grounding plug.
• Do not use extension cords or power strips with this unit. You may need to contact your electrician
if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not modify the
power cord’s length or share the outlet with other appliances.
• Do not start or stop the unit by switching the circuit’s power on and o.
• If the power cord is damaged, it must be replaced by the manufacturer or a qualied technician.
• Never repair the unit while it is plugged in.
• Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and
contact customer service.
• Do not remove any part of the casing unless instructed to do so by an authorized technician.
• You should never attempt to repair the unit yourself. Contact customer service for service options if
the unit needs service.
DANGER: Flammable Refrigerant Used! When handling, moving, and using the kegerator,
make sure to avoid either damaging the refrigerant tubing or increasing the risk of a leak.
!
3
Important Safety Information
General Safety
• To prevent injuries, use at least two people to move and install the kegerator.
• Install the kegerator in a well-ventilated area where the ambient temperature is above 50° F and
below 95° F.
• The temperature range for this kegerator is optimized for storage. Perishable food items may
require a dierent storage environment.
• Do not place hot or warm items into the kegerator before they cool down to room temperature.
• This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or moisture.
• This unit is not intended to be used by children.
• Children should be supervised to ensure that they do not play with this product.
• Never allow children to crawl inside the kegerator. If you are disposing of the unit, remove the door.
• Do not use this appliance near ammable gas or combustibles such as gasoline, benzene, or
thinner.
• Do not store explosive substances such as aerosol cans with ammable propellant in this
appliance.
• Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
• Only use in an upright position on a at, level surface and provide proper ventilation.
• Do not pinch or kink the power supply line between the unit and cabinet.
• Do not leave any cleaning solutions in the unit.
• Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
• Do not place any other appliances on top of the unit.
• Do not turn the unit upside down, on its side, or at an angle o level.
• If your model of kegerator is equipped with a lock, keep the keys away from children.
• Do not move the unit without emptying the contents and securing the door in a closed position.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities unless they are given supervision or instruction by a person
responsible for their safety.
• This appliance is meant for use in the household or similar settings.
• Keep all ventilation openings clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process.
• Do not damage the refrigerant circuit.
• Do not use other appliances inside the kegerator unless recommended by the manufacturer.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a
similarly
!
DISPOSAL: This appliance may not be treated as regular household waste, it should be
taken to the appropriate waste collection
!
4
Table of Contents
Important Safety Information ..........................................................................................2
First-Time Operating Instructions ...................................................................................5
Introduction.....................................................................................................................5
Parts Identication.......................................................................................................... 6
Installation ......................................................................................................................8
Unpacking the Kegerator.........................................................................................8
Types of Installation.................................................................................................8
Countertop Opening for Dispense Kit......................................................................9
Clearance Requirements.........................................................................................10
Seal Space Between Cabinet and Countertop........................................................ 11
Electrical Requirements ..........................................................................................12
Recommended Grounding Method ......................................................................... 12
Leveling the Kegerator ............................................................................................12
Installing the Door Handle....................................................................................... 13
Installing the Guard Rail.......................................................................................... 13
Installing the Drip Tray.............................................................................................13
Installing the Casters...............................................................................................14
Reversing the Door Swing.......................................................................................14
Keg Loading ............................................................................................................16
Operation........................................................................................................................17
Installation Checklist before Operation....................................................................17
Using the Temperature Control Panel ..................................................................... 17
Normal Sounds........................................................................................................18
Temperature Alarm .................................................................................................. 18
Door Ajar Alarm ....................................................................................................... 18
Defrosting................................................................................................................ 19
Preparing the Kegerator for Storage ....................................................................... 19
Cleaning and Maintenance.............................................................................................19
Troubleshooting.............................................................................................................. 20
Specications .................................................................................................................22
EdgeStar Limited Warranty ............................................................................................23
5
First-Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep
track of all included parts and pieces before discarding the packaging materials. It is advised that you
keep the original box and packaging materials in case you ever need to move or ship the appliance in
the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components time to
settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar kegerator. We hope that this purchase will be the beginning of
a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support
and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and maintenance of
your kegerator. Following this manual will ensure that your product will work at its peak performance
and eciency.
Please save the original product packaging in case you need to safely transport your kegerator.
For Your Records:
Please write down the model number and serial number below for future reference. Both numbers are
located on the ratings label on the back of your unit and are needed to obtain warranty service. You may
also want to staple your receipt to this manual as it is the proof of your purchase, and is also needed
for service under your warranty.
Model Number: ________________________________
Serial Number: ________________________________
Date of Purchase: ______________________________
For a more ecient experience, please do the following before contacting customer service:
• If you received a damaged product, immediately contact the retailer or dealer who sold the product.
• Read and follow this instruction manual carefully to help you install, use, and maintain your kegerator.
• Read the troubleshooting section of this manual. It will help you diagnose and solve common issues.
• Visit us on the web at www.edgestar.com to register your product, download product guides, and
access additional troubleshooting resources and up-to-date information.
• For warranty service, customer service representatives are available at service@edgestar.com.
6
Parts Identication
Front View:
Rear View:
Note: Gather the model and serial number from the product label and write them down
before installing the kegerator.
Cabinet
Product Label
Power Cord
Control Panel
Dispense Tower Opening
Leveling Leg
Internal Fan with Fan Pipe
Door Lock
Front Vent
7
Internal Fan:
This is an air-cooled unit equipped with an internal fan that maintains a consistent internal
temperature.
Accessories:
(1) Drip Tray (1) Guard Rail (4) Guard Rail
Installation Pegs
(1) Door Handle
(Not included with BR1500BL)
(4) Casters
(Includes 16 screws for
installation)
(4) Dispense Tower
Screws
8
Installation
The kegerator should be installed in accordance with local electrical code requirements. The kegerator
should also be placed in a location that is strong enough to support its total weight, keeping in mind that
it will weigh substantially more when fully loaded than when empty. Before you plug the kegerator
into a power supply, be sure to let it stand upright for at least 24 hours to allow the compressor’s
oils to settle.
Unpacking the Kegerator
Warning: Use two or more people to move and install the kegerator. Failure to do so
can result in back or other injury. Carefully remove the packaging materials. Remove any
shipping tape and glue from your kegerator before use. Do not use sharp instruments,
rubbing alcohol, ammable uids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your kegerator.
!
Warning: Do not remove any safety, warning, or product information labels from your
kegerator.
!
Warning: DO NOT install the kegerator behind a closed cabinet door.
This kegerator has been designed for freestanding or built-in installation. In each case, there must be
adequate ventilation and access for service.
Freestanding Installation:
A freestanding installation will allow you to install the kegerator in almost any place you desire. You
must follow the stated instructions for electrical requirements and leveling the kegerator.
Built-in Installation:
A built-in installation will allow you to install the kegerator under a counter as long as the required
clearance space around the kegerator is provided. It is necessary to allow adequate ventilation space
around the unit, including at the back of the unit.
This installation requires several more steps and considerations than a free standing installation.
Types of Installation
!
Note: Please refer to the dispense kit installation guide to complete the full assembly of the
kegerator.
9
Countertop Opening for Dispense Kit
Notes:
• Choose a location that has ambient temperatures above 50° F and below 95° F. Operation
outside these temperatures may result in lowered eciency or cause other adverse eects.
• This unit MUST be installed in an area protected from the elements, e.g. wind, rain, water
spray or drips.
• The kegerator should not be located next to ovens, grills, or other heat sources.
• Do not kink or pinch the power supply cord between the kegerator and the wall or cabinet.
Once the location of the kegerator installation is determined the rst step is to create an opening in the
counter for the dispense kit lines to pass through.
1. Mark o a spot on the countertop where the opening will be created.
2. Align that spot so it will be directly above the opening of the kegerator that will be placed under the
counter.
3. Drill or cut (depending on the material of your countertop) an opening into your counter the same
size as the opening of the top of the kegerator.
4. Conrm that the opening is not larger than the size of the dispense tower for optimal performance.
10
Note: The kegerator should be installed on a rm and level surface that will be able to
support the entire weight of a fully loaded unit. It is important for the kegerator to be level
in order to work properly. If needed, you can adjust the height of the kegerator by rotating
the feet. See the “Leveling the Kegerator” section.
Note: A standard electrical supply (115V AC only, 60 Hz), properly grounded in accordance
with National Electrical Code and local codes and ordinances, is required.
Clearance Requirements
Make sure the top cover, guard rail, drip tray, and installation pegs are NOT installed on the top of the
cabinet. These items will create an obstacle for the cabinet to be installed under counter. Move the
kegerator so the opening on the top of the cabinet is aligned with the opening in the counter.
When installing the kegerator under a counter, follow the recommended spacing dimensions shown
below:
To ensure proper service access and ventilation, allow at least 1-2” of clearance at the back, 1/2” at
the top, and 1/4” at the sides. If the door side is against a wall, allow at least 2 3/8” of clearance. The
installation should allow the unit to be pulled forward for servicing, if necessary.
90
Door Swing
2“
16 3/16
"
2 /”
1-2”
1/4
” 1/4”
1/4”
1 - 2”
Top View: Side View:
This manual suits for next models
2
Table of contents
Other EdgeStar Kegerator manuals
Popular Kegerator manuals by other brands
Nostalgia Electrics
Nostalgia Electrics KEG9000DTSS instruction manual
Nostalgia Electrics
Nostalgia Electrics KRS2100 SERIES instruction manual
NPC
NPC ReverseTap instruction manual
AMD DIrect
AMD DIrect SSRFR-24DK user manual
PolyKeg
PolyKeg PRO Filling instructions
PolyKeg
PolyKeg PRO one-way keg Insruction manual
KegLand
KegLand Fermzilla instruction manual
Nostalgia Electrics
Nostalgia Electrics Kegorator KRS-2150 instruction manual
Nostalgia Electrics
Nostalgia Electrics KEGORATOR KRS-2000 SERIES instruction manual
NPC
NPC ReverseTap RD-B1 installation guide
KegLand
KegLand Benchy Carbon KL18210 instruction manual
KegLand
KegLand Benchy - Glycol instruction manual
