Edelbrock 68812 User manual

Catalog #68812, #68813

Page 1 of 2 Brochure #63-68812

Rev. 5/06 - DA/mc

TUBULAR EXHAUST SYSTEM

For 1981-1991 AMC Grand Wagoneer,

360 C.I.D. V8, Auto Transmission, 2 & 4 WD

Catalog #68812, #68813

INSTALLATION INSTRUCTIONS

Please study these instructions carefully before installing your new

Tubular Exhaust System

(TES). If you have any

questions, please contact our Technical Hotline at : 1-800-416-8628 from 7 am - 5pm, Monday-Friday, Pacific

Standard Time or e-mail us at [email protected]. Please fill out and mail your warranty card.

TUBULAR EXHAUST SYSTEM: These components are designed as a system to improve the exhaust efficiency of the AMC

V8 engine. A performance gain can be expected by the installation of the system. This system does not require welding

for installation and retains all O.E.M. emissions equipment.

Suggested Tools Needed for Installation: This vehicle has some metric fasteners.

❑ 3/8” ratchet socket set with extensions and universal 13mm and 15mm swivel sockets

❑Combination set of open-end wrenches

❑ Jackstands, screwdrivers, pliers, crescent wrench, etc.

❑Liquid penetrant, (GM #1052627) anti-seize compound (GM #5613695)

SPECIAL NOTICE: This Edelbrock Tubular Exhaust System has received an Executive Order number (E.O.#) from the

California Air Resources Board (C.A.R.B.) making it legal for street use in all 50 states. To assist you with emission

equipment certification, we have included a silver fan shroud decal to help testing personnel verify the this part is a legal

replacement on the vehicle for which it is cataloged. The adhesive-backed decal should be affixed next to the existing

emission and engine specifications decal. Do not cover any part of your original emission decal.

WARNING: The use of "Thermal Wrap" or any aftermarket coating process will void the warranty on your Edelbrock

Tubular Exhaust Systems. Those products can cause excessive heat and moisture buildup resulting in corrosion and

failure of the system.

NOTE: High temperature spark plug wires and boots are recommended to withstand heat from T.E.S.

IMPORTANT NOTE:

Proper installation is the responsibility of the installer. Improper installation will void warranty and may

result in poor performance and engine or vehicle damage.

Qty. Description

❑1Header left side #25-9435 (#68812)

❑1Header right side #25-9434 (#68812)

❑1Header left side #25-9043 (#68813)

❑1Header right side #25-9044 (#68813)

❑1Extension pipe right side #25-9540

❑1Extension pipe left side #25-9539

❑ 12 Header bolts; 3/8”-16 x 1”

❑ 1Flange

❑ 1U-Bolt; 2-1/4”

Qty. Description

❑ 2Port flange gaskets

❑ 11-Hole Gasket

❑ 1D-Nut gasket

❑ 8Bolts; 5/16”-18 x 1”

❑ 2Hex bolts; 3/8”-16 x 2”

❑ 2Hex bolts; 3/8”-16 x 3”

❑ 8Washers; 5/16”

❑ 8Lock washers; 5/16”

❑16 Lock washers; 3/8”

KIT CONTENTS

Catalog #68812 (Ceramic-Coated), #68813 (Ti-Tech Coated)

Catalog #68812, #68813

Page 2 of 2 Brochure #63-68812

Rev. 5/06 - DA/mc

DISASSEMBLY - LEFT SIDE

1. Disconnect negative cable from battery.

2. Use penetrating oil on all nuts and bolts to be

removed. This will prevent the possibility of broken

or stripped nuts and bolts.

3. Remove air cleaner system (note position of line and

hose connections).

4. Disconnect A.I.R. (air injection reactor) tube from

exhaust manifold.

5. Remove bolts and exhaust manifold.

DISASSEMBLY - RIGHT SIDE

1. Disconnect A.I.R. injection tube from exhaust

manifold.

2. Remove bolts and exhaust manifold.

3. Clean exhaust flange surfaces on cylinder heads at

this time.

DISASSEMBLY - CROSSOVER PIPE

1. Raise vehicle and support with jackstands.

2. Making sure the converter is cool, remove the

exhaust crossover pipe. If the pipe is frozen to the

converter, it can be heated with a Propane torch (or

equivalent) to help loosen the joint.

INSTALLATION INSTRUCTIONS

Edelbrock Corporation, 2700 California St., Torrance, CA 90503

Tech Line: 1-800-416-8628

E-Mail: [email protected]

ASSEMBLY- LEFT SIDE

1. Install T.E.S. flange gasket and one 3/8"- 16 x 1"

bolt, lock washer, and flat washer at rearmost bolt

hole (leave bolt loose enough to accept T.E.S.).

2. Install left side T.E.S. manifold from top side.

3. Install all bolts and washers on left side. Align all

parts and tighten left side bolts and nuts at this time.

ASSEMBLY- RIGHT SIDE

1. Install T.E.S. flange gasket and one 3/8"- 16 x 1"

bolt, lock washer and flat washer at rearmost bolt

hole (leave bolt loose enough to accept T.E.S.).

2. Install right side T.E.S. manifold from below.

3. Install remaining bolts and lock washers.

4. Align all parts and tighten all right side bolts at this

time.

5. Remove A.I.R. check valves from original manifolds

and re-install them on T.E.S. Re-connect all A.I.R.

injection hoses at this time.

CROSSOVER PIPE ASSEMBLY

1. Slip new Edelbrock T.E.S crossover (Y-pipe) over

catalytic converter.

2. Install crossover pipe assembly on vehicle using two

3/8"x 3" bolts on right side to hold pipe flare against

heat riser valve and valve against manifold flange,

with flat gasket between heat riser and manifold.

Use two 3/8" x 2" bolts and the donut gasket to

attach the left side pipe to the manifold.

3. Install U-clamps and tighten all nuts and bolts.

4. Lower vehicle to the ground.
