Eclipse ECL-VIP200 User manual
i
2-Wire ECL-VIP200 User’s Manual
V1.0.0
i
Table of Contents
Table of Contents .....................................................................................................................i
1
Product Overview ....................................................................................................... 1
1.1
List of Models ................................................................................................................. 1
1.2
Structure ........................................................................................................................ 1
1.2.1
Dimension ........................................................................................................... 1
1.2.2
Front Panel ......................................................................................................... 2
1.2.3
Rear Panel ........................................................................................................... 3
1.3
System Networ ing ........................................................................................................ 3
1.3.1
One-to-One Scene .............................................................................................. 4
1.3.2
Group Call Scene ................................................................................................. 4
2
Install VTO .................................................................................................................. 5
2.1
Direct Installation ........................................................................................................... 5
2.1.1
Screw .................................................................................................................. 5
2.1.2
Dimension ........................................................................................................... 6
2.1.3
Installation Step .................................................................................................. 6
2.2
Embedded in Wall .......................................................................................................... 8
2.2.1
Screw .................................................................................................................. 8
2.2.2
Dimension ........................................................................................................... 8
2.2.3
Installation Step .................................................................................................. 9
2.3
Wiring ........................................................................................................................... 11
2.4
Electric Control Loc and Electromagnetic Loc .......................................................... 11
2.4.1
Electric Control Loc ......................................................................................... 11
2.4.2
Electromagnetic Loc ........................................................................................ 12
3
Installation Debugging ............................................................................................. 13
3.1
WEB Setup .................................................................................................................... 13
ii
3.2
General Config ............................................................................................................. 14
4
Web Config ............................................................................................................... 16
4.1
System Config ............................................................................................................... 16
4.1.1
Local Config ....................................................................................................... 16
4.1.2
LAN Config ........................................................................................................ 17
4.1.3
Indoor Manager ................................................................................................ 17
4.1.4
Networ Config ................................................................................................. 19
4.1.5
Video Set ........................................................................................................... 19
4.1.6
User Manage..................................................................................................... 20
4.2
Info Search ................................................................................................................... 21
4.2.1
Call History ........................................................................................................ 21
4.2.2
Alarm Record .................................................................................................... 22
4.3
Status Statistics ............................................................................................................ 22
4.3.1
VTH Status ........................................................................................................ 22
4.4
Logout .......................................................................................................................... 22
5
Basic Function Introduction ..................................................................................... 23
5.1
Call Function ................................................................................................................. 23
5.1.1
Call Manager Center ......................................................................................... 23
5.1.2
Call User ............................................................................................................ 24
5.1.3
Group Call ......................................................................................................... 24
5.2
Monitor ........................................................................................................................ 27
5.3
Unloc Function ........................................................................................................... 27
5.4
Compensation of Light ................................................................................................. 28
5.5
Vandal Proof................................................................................................................. 28
5.6
Restore Bac up ............................................................................................................ 28
6
FAQ ........................................................................................................................... 29
Appendix 1 Technical Specifications ....................................................................................... 30
Appendix 2 Technical Specifications ....................................................................................... 31
Appendix 2.1 Cable Specification ............................................................................................ 31
Appendix 2.2 Power Extension Line Specification ................................................................... 31
iii
Appendix 2.3 Embedded Box .................................................................................................. 31
Appendix 3 VTMS .................................................................................................................... 32
Appendix 4 VTMS Client .......................................................................................................... 34
Appendix 4.1 Config Networ Address .................................................................................... 34
Appendix 4.2 Create Organization .......................................................................................... 36
iv
Important afeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in
order to avoid damages and losses.
Note:
Do not expose the device to lampblack steam or dust. Otherwise it may cause fire or
electric shock.
Do not install the device at position exposed to sunlight or in high temperature.
Temperature rise in device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety
under load and earthquake. Otherwise it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise
temperature in device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise
it may cause fire or electric shock.
pecial Announcement
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective
owners.
If there is any uncertainty or controversy please refer to the final explanation of us.
Please visit ou
r website for more information.
1
1 Product Overview
1.1 List of Models
Model Chassis
Material
Color Unlock via
IC card
Button Type Lock Control Module
ECL-VIP200 Metal Silver N/A Mechanical
key
Built-in
1.2 tructure
1.2.1 Dimension
Before you install the device please make sure you know the dimension of device and
select appropriate installation method. See Figure 1- 1.
Figure 1- 1
2
1.2.2 Front Panel
Figure 1- 2
No. Port Name Note
1 MIC Audio input.
2 Camera It monitors corresponding door region.
3 Compensation
Light
Light compensation will automatically turn on
during monitoring calling or connecting status if
there is no enough light in environment.
4 Speaker Audio output.
5 User Nameplate Display username and other info.
6 Call Button Call center or VTH.
3
1.2.3 Rear Panel
Figure 1- 3
No. Component Name
Note
1 Camera Angle
Adjustment Adjust camera angle.
2 Vandal-proof
Switch
When VTO if forced to leave wall it will alarm and
report to MGT center.
3 User Port Connect to lock door sensor feedback and unlock
button.
4 Project Port Reserved for project staff use.
1.3 ystem Networking
This chapter mainly introduces usage of digital VTO please read the following content
and install the device according to your actual condition.
4
1.3.1 One-to-One cene
Visitor press Call button to call residence (as VTH) or Center. See Figure 1- 4.
Figure 1- 4
1.3.2 Group Call cene
When visitor press Call button on VTO multiple VTHs will ring at the same time. User can
call hang up and unlock on any of these VTHs.
Note:
VTH has 1 master VTH and up to 3 extension VTHs.
See Figure 1- 5.
Figure 1- 5
5
2 Install VTO
2.1 Direct Installation
2.1.1 crew
Before installing VTH please check screws on accessory bag according to the following
specifications and install by following this guide.
Component Name Illustration Quantity
M3×6 Hex slot pan head tail machine screws
--- galvanizing white 4
M3×8 Cross recessed countersunk head tail
machine screws --- galvanizing white 4
ST3×18 Cross recessed countersunk head
tail tapping screws --- galvanizing white 4
White expansion tube
￠
6×30mm 4
Chart 2- 1
Note:
M3x6 or M3x8 either is OK.
