EazzyDV P2P HD720P BULB User manual
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 2 / 25 www.eazzydv.com
Key-points For Setup in Router
When in WiFi mode, bulb camera will be connected with router. To have better performance
and being successfully connected with router, there are some key points must be aware :
1. Router’s DHCP service must be enabled. Bulb camera depends on it to get IPaddress.
2. Router’s SSID, must no space in between, that means format like “my ssid”is not
acceptable, only acceptable “myssid”
3. Router’s wireless channel, we would suggest using no. “13”
4. Router’s security method, we would suggest using “WPA2-PSK”
5. Router’s encryption method, we would suggest using “AES”
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 3 / 25 www.eazzydv.com
Table of Content
1. Summary
1.1Overview ……………………………………………………………………………P3
1.2Key Functions ………………………………………………………………………...P3
1.3Specifications…………………………………………………………….....................P4
1.4Package content…………………………………………………………………..…...P5
1.5Attention…………………………………………………………………...………….P5
2. Product layout..……………………………………………………………......................P6
3. How to install ………..……………………………………………………......................P7
4. Client Software Installation ………………………………………………………......P8
5. Operation mode ………...……………………………………………………………….P10
6. Online watch ..………………………………………………………………...................P13
7. Download recorded video ………………..……………………………………………..P13
8. Set Alarms …………………..………...…………………………………………………P15
9. Hearing Sound ……… …….……………………………………………………………P17
10. Video Recording Methods …………………………….………………………………P18
11. Advanced Setting for Professional …………………………………………………….P18
12.Advanced Setting for Professional –update patch …………………………………….P19
13.Accessory…………………………………………………………………………………P20
14.Trouble Shooting ………………………………………………………………………...P22
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 4 / 25 www.eazzydv.com
1. Summary
1.1 Overview
It is a WiFi enabled IP Network CCTV Security Digital Video Recorder (DVR) camera, not a real
lamp. This is an innovative design and being patented. The idea is very simple to use and can be
used worldwide, just insert a Micro-SD card and screw-in like a bulb, turn on power, it will be auto
recording. Using this device, there is no drilling holes and no cabling, just using existing bulb holder.
It is no need technical background, you know how to replace a normal bulb, then you know how to
install it.
Besides, you can use your mobile phones or computers remotely access it via internet, watching and
hearing what is happening at there. It can be broadly used in any environments and setup by your
own like home, office, factory, shopping mall, restaurant and so on.
1.2 Key Functions
Function
Description
Provide true HD 720P resolution 1280x720 pixels.
Provide two operation modes, AP mode that is point to point access.
WiFi mode that is joining existing network and to be accessed outside
via internet.
Using H.264 compression, delivers high quality video and a superb
compression ratio.
Onvif compatible that means video can be saved to ONVIF supported
NVR machines for backup large volume video files
Using Peer-to-Peer technology, no need setting on routers and no need
DDNS and no need IP address setting, just plug and play.
Local storage using Micro-SD card, accepting 2GB-32GB, 32GB card
can store 12 days video files, recommend using CLASS 10 card.
When there is motion detected, it will trigger alarms by email alert or
push warning message to mobile phone.
When there is motion detected, email alert can send 3 pictures to your
dedicated email account
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 5 / 25 www.eazzydv.com
Able to hear sound from bulb camera on mobile phones, PCs and MAC
and so on.
Built-in IR-cut, no color casting
Provide clear image at night (in black and white)
1.3 Specifications
System
Embedded Linux OS
Using industrial grade TI solution CPU, TIDM365
Image Sensor
1/4" CMOS progressive sensor,1.0M pixels
Video
H.264 Compression Format
Resolution : 720P (1280*720) / VGA (640*480) / QVGA(320*240)
Frame Rate : 0 –25 FPS
Data Rate : 32Kbps –2.0M Kbps
Light intensity, contrast ratio, saturation level are adjustable
Network
Using Peer to Peer (P2P) technology, no need configuration and no
DDNS
Support two modes, AP mode and WiFi mode :
AP mode –For local usage, no need internet remote access and no
need to connect to wifi router
WiFi mode –Connect to wifi router and to be accessed via internet
Wi-Fi compliant with wireless standards IEEE 802.11b/g/n
Support both WEP & WPAWPA2 encryption for wireless
Wireless transmission distance in open area around 100 meters
Watch
On line viewing and control via iPhones、iPad、Android Smart
Phones、Wins PC、Notepads、Notebooks、MAC
Free client software for mobile phones and computers
One software can display max. 64 bulbs
Simple installation, just download and launch it. No configuration
and no setup at all.
Storage
Local storage, support Micro-SD card, 2GB-32GB (class10 card
recommended)
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 6 / 25 www.eazzydv.com
32GB card can store 12days video by using VGA(640*480) format
Support looping and motion detection recording
Recorded files can be remotely downloaded to computer or mobile
phone for viewing
Support client side recording, on PC or mobile phones
Alarm
Motion detection triggering email alert
Motion detection triggering mobile phone push alert
Night Vision
Using 2pcs of 3rd generation LED ARRAY, more longer life 3-5yrs
and more brighter
Night vision distance about 20 meters
LEN
3.6mm, 90 degree viewing angle, 3.0M pixels
Min. Illumination
0.1 Lux (IR Off), 0 Lux (IR ON)
IR-CUT
Built in IR-CUT, no color cast in day, clearer images at night
Audio
ADPCM Format
Built-in microphone
Through Client software able to hear sound
Motion Detection
Motion detection distance 5 meters
Adapters
E27/E26/B22 optional
Voltage
Worldwide usage, AC 100-240V
Power Consumpt.
< 5W
Operation Temp.
-20~50℃
Weight
Gross: 300g
Packaging size
85*85*175mm (L*W*H)
1.4 Package Content
1 x Bulb WiFi IP Network DVR Camera (not include memory card)
1 x CD (user manuals inside)
1 x Micro-SD card reader (plug to computer for viewing videos if needed)
1 x Reset Pin (manually reset the camera)
1 x Reset Remote Control (reset the camera bc-881m only or control light for bc-883 only)
1.5 Attention
1. Before replacing the camera, please ensure the power is OFF and the circuit
voltage is within the operation range (100 –250V AC)
2. Please hold the plastic enclosure of the camera during installation or removal
to ensure safety
3. If camera running for more than 2hrs with IR light On, the plastic case will be little bit warm that
is normal, and the metal part will be warm too. But when IR light off, it will cool down quickly.
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 7 / 25 www.eazzydv.com
2. Product Layout
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 8 / 25 www.eazzydv.com
Buttons
Button
Function
Micro-SD card slot
For inserting Micro-SD card,
accepting 2GB-32GB, recommend
CLASS 10 card
Reset
Using reset pin, press and hold for 10
seconds, device will be reset to factory
default mode(AP mode)
Or Press reset button on remote
control once and hearing 10 beeps,
device will be reset to factory default
mode (AP mode)
3. How to install
1. Insert a Micro SD card (2GB-32GB, format it for first time usage) into the camera card-slot
1.1. Before screw-in the camera, ensure the socket power is off and the voltage is
within the operation range (AC 100 –250V)
2. Screw-in the camera into a bulb holder like a bulb
3. Turn on power
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 9 / 25 www.eazzydv.com
4. Client Software Installation
4.1Andriod Smart Phones Scan to install
Or download at http://www.bulbcam.net/download/bulbcam.apk
Software name : BulbCam
4.2 iPhone /iPad Scan to install
Or search “BulbCam”in APP Store and install it
__________________________________________________________________________________________
Eazzy Digital Video Technology Limited 10 / 25 www.eazzydv.com
Software name : BulbCam
4.3 Win PC
Download it from http://www.bulbcam.net/download/bulbcam.zip
Unzip the file
Click “bulb cam.exe”to install it
Software name : BulbCam
4.4 MAC
Software name : BulbCam
Download it from http://www.bulbcam.net/download/bulbcam.dmg
Install it
