Eaton FlexPDU User manual

FlexPDU User Manual

Contents

Ⅰ. Introduction.................................................................................................................................. 3

Ⅱ. Main functions............................................................................................................................. 3

Ⅲ. Monitoring method..................................................................................................................... 3

Ⅳ. Applications..................................................................................................................................3

Ⅴ. Product sketch.............................................................................................................................4

Ⅶ. Mounting method........................................................................................................................ 4

Ⅷ. Hardware introduction...............................................................................................................5

1. Front panel introduction..................................................................................................... 5

2．Initialization.......................................................................................................................... 5

3. Hardware settings.................................................................................................................7

4. Daisy-chain connection...................................................................................................... 8

Ⅸ. Software introduction................................................................................................................ 9

1. Web browser access............................................................................................................9

2. SNMP access....................................................................................................................... 15

3. Telnet access....................................................................................................................... 21

Ⅹ.Technical Specification............................................................................................................ 22

Ⅺ. Quality Warranty........................................................................................................................24

FlexPDU User Manual

Ⅰ. Introduction

The Hot-Swapple and AC/DC integration FlexPDU is EATON’s newest scientific achievement in the

power distribution filed in 2016. On the trend of future power distribution management technology

development, combining the technology requirement of the modern data center application environment,

adopting key technology with fully independent intellectual property, the product FlexPDU is designed in

combination of network communication, AC/DC integration, power distribution, network management and

hot-swappable technology.

Ⅱ. Main functions

1. Monitor input voltage

2. Monitor total load current

3. Monitor total power (kW)

4. Monitor energy consumption (kWh)

5. Monitor the micro-environment in the cabinet

Ⅲ. Monitoring method

Via software: FlexPDUs can be monitored and managed though centralized management software--- CLEVER

Manager

Ⅳ. Applications

Apply to single phase 100VAC~240VAC up to 63Amps, three phase 200VAC~400VAC up to 32Aamps and

100VDC~350VDC power source. The outlet type and quantity can be customized at request.

FlexPDU is widely applied to the data centers of industries like network communication, telecom, electric power,

finance, insurance, aerospace, transportation, information processing, education, medical, E-government etc.

FlexPDU User Manual

Ⅴ. Product sketch

Ⅵ. Instruction on the RS485 port and RJ45 terminal pin

Ⅶ. Mounting method

FlexPDU products can be vertical installation.

Color

Instructions

1.Orange & White

GND

2.Orange

GND

3.Green & White

RS485-A

4.Blue

RS485-A

5.Blue & White

RS485-B

6.Green

RS485-B

Brown & White

GND

8. Brown

GND

1. Screen: TFT screen;

2. RUN: Run indicator;

KWH: kWh indicator;

ALM: Alarm indicator;

3. NET: Ethernet port;

4. SER: Daisy-chain port;

5. LINK: Daisy-chain port;

6. MENU: Menu Key;

7. UP: Function set key;

8. DOWN: Position selection key;

9. RESET: Restart button;

10. T/H: Temperature/Humidity sensor port

FlexPDU User Manual

Ⅷ. Hardware introduction

1. Front panel introduction:

Panel

composition

Function

Description

RUN

Run indicator

States: flash frequency is 1 second

KWH

kWh indicator

States: flash frequency depends on the load

ALM

Alarm indicator

Sates: light on if there is a alarm happening

NET

Ethernet port

LAN/WAN Ethernet communication port

SER

Daisy-chain port

RS-485 daisy-chain communication port

LINK

Daisy-chain port

RS-485 daisy-chain communication port

Menu key

to view the LCM displayed information, light up the LCM

background, save the configuration as ENTER key.

Restore to factory settings: Hole the MENU key and press the

RESET button to restore

Mute alarming: Press and hold the MENU key for 4 seconds to

turn On/Off the alarm

Function set

key;

light up the LCM background, set the Master or Slave address

cord, the maximum threshold of voltage, current, temperature and

humidity from 0 to 9

DOWN

Position

selection key

light up the LCM background, to select the address cord,

maximum threshold of voltage , current, temperature and humidity

RESET

Restart button

Restart the device

Screen

View the states

display the power and environment date

T/H

Temperature

and humidity

sensor port

2．Initialization

When power on, the RUN indicator will flash and the FlexPDU works normally after initializing the LCD

indicator and TFT screen. Following is the LCD displaying content introductions from the Direct current power ,

single phase and three phase power:

2.1 Direct Current modular:

1st screen: Amps(0.1A), Volts(220VDC), Power(0.0kW), kWh(0.0kWh) (Figure 1)

2nd screen: the temperature and humidity date (figure 2)

3rd screen: the brad rate(4800/9600/19200/38400) (Figure 3)

4th screen: the device IP, address code(from 0 to 4) (Figure 4)

5th screen: the threshold of the current (32A)and voltage(276VDC) (Figure 5)

FlexPDU User Manual

6th screen: the threshold of the temperature(40℃) and humidity(90%) (Figure 6)

2.2 The single phase modular:

1st screen: Amps(0.0A), Volts(220VAC), Power(0.0kW), kWh(0.0kWh) (Figure 1)

2nd screen: the temperature and humidity date (figure 2)

3rd screen: the brad rate(4800/9600/19200/38400) (Figure 3)

4th screen: the device IP, address code(from 0 to 4) (Figure 4)

5th screen: the threshold of the current (32A)and voltage(276VAC) (Figure 5)

6th screen: the threshold of the temperature(40℃) and humidity(90%) (Figure 6)

2.3 The three phase modular:

1st screen: L1 Amps(0.1A), Volts(220VAC), Power(0.0kW), kWh(0.0kWh) (Figure 1)

2nd screen: L2 Amps(0.1A), Volts(220VAC), Power(0.0kW), kWh(0.0kWh) (Figure 2)

3rd screen: L3 Amps(0.1A), Volts(220VAC), Power(0.0kW), kWh(0.0kWh) (Figure 3)

4th screen: the temperature and humidity date (figure 4)

5th screen: the brad rate(4800/9600/19200/38400) (Figure 5)

（Figure 1）

（Figure 2）

（Figure 3）

Press MENU

TTON）键切换

（Figure 1）

（Figure 2）

（Figure 3）

216VDC

00.0A

00.0KW

000000.0KWh

Temp

00℃

Hum

00％

192.168.

1.165

Addr 0

Max

276V

32.0A

Press MENU

Max

276V

32.0A

L1 216VAC

00.0A

00.0KW

000000.0KWh

Temp

00℃

Hum

00％

192.168.

1.165

Addr 0

Press MENU

（Figure 4）

Press

Max

40℃

99％

Baud

9600

（Figure 4）

（Figure 5）

（Figure 6）

Press

Baud

9600

（Figure 5）

Max

40℃

99％

Press MENU

（Figure 6）

Press MENU

TTON）键切换

Press MENU

FlexPDU User Manual

6th screen: the device IP, address code(from 0 to 4) (Figure 6)

7th screen: L1 threshold of the current (32A)and voltage(276VAC) (Figure 7)

8th screen: L2 threshold of the current (32A)and voltage(276VAC) (Figure 8)

9th screen: L3 threshold of the current (32A)and voltage(276VAC) (Figure 9)

10th screen: the threshold of the temperature(40℃) and humidity(90%) (Figure 10)

3. Hardware settings

3.1 Address code settings: To locate the address code page(like Add -0) from the LCD screen, press DOWN

key to set the value which cycling from 4 to 0 for the master or slave address code and

press UP key to set the value which cycling from 0 to 4, the address code range from 0

to 4.

3.2. Current or Voltage threshold settings: To locate the threshold setting page(like L1 32.0A 276VAC);

Press DOWN key to select the value need to be set, the select position will flesh, then

press UP key to set the threshold value, the allowed maximum current is 32A and

maximum voltage is 276VAC

Note: All above settings must be saved by pressing the MENU key, and the settings will take effective after

the beep sound, otherwise, the device will without saving the settings.

3.3 Restore to factory settings: Press and hold the MENU key when power on or Hold the MENU key to

（Figure 1）

（Figure 2）

（Figure 3）

Press MENU

示

（Figure 5）

（Figure 4）

Press

L3 216VAC

00.0A

00.0KW

000000.0KWh

L2 216VAC

00.0A

00.0KW

000000.0KWh

L1 216VAC

00.0A

00.0KW

000000.0KWh

Temp

00℃

Hum

00％

192.168.

1.165

Addr 0

Max

276V

32.0A

Press MENU

显示

Press MENU

至下一屏显示

（Figure 7）

（Figure 6）

Max

276V

32.0A

Press MENU

（Figure 8）

Press

Max

276V

32.0A

Baud

9600

Press MENU

Max

40℃

99％

（Figure 9）

（Figure 10）

FlexPDU User Manual

press the RESET button till the screen display normally

3.4 Mute the alarming: Press and hold the MENU key for 5-6 seconds when there is a alarming to turn

off/on the alarm. When the alarm was turned on, an O in red will be displayed in the screen, When

the alarm was turned off, an F in red will be displayed in the screen.

4. Daisy-chain connection

Serial Daisy-chain mode:

（Figure 1）

4.1. Setting one FlexPDU as Master unit, and the rest as Slave unit. The maximum daisy-chain is 4pcs. Apply

to FlexPDU, refer to figure 1

Ethernet Daisy-chain mode:

（Figure 2）

4.2. Connect the each FlexPDU to the port from the HUB and connect the Net port from HUB to the internet. No

limitation for the FlexPDU quantity. Please see figure Figure 3.

4.3 Connecting the Master net port with computer net port,then access via IE.

FlexPDU User Manual

Ⅸ. Software introduction

User can access the FlexPDU through WEB interface, SNMP(V1/V2c/V3) or Telnet command console.

1. Web browser access

User can access, monitor and control the FlexPDU by web browser like Internet Explorer, google chrome

and etc) by input the correct IP address in the address bar. The pop-up login window is illustrated as figure 1

Figure1

User will see the home page(as figure 2) after entering the correct user name and password (eaton/eaton) in

the login dialog box

Figure 2

Company

Logo

FlexPDU User Manual

Main interface includes 3 parts: Company Logo, Menu and device states.

A. Device State:

A. Device state: Click the Device State(AC or DC), user can check the current, voltage, power factor,

Active power, Apparent power, energy consumption, Frequency, Temperature and Humidity senor of

the FlexPDU as figure 2

Input: From the drop-down list to view the power date of L1,L2 or L3（Single phase module

does not have drop-down list）

From the drop-down list view the power date or Master unit or Slave units. One

Master unit can support to you 4 Slave unit (Slave 1- Slave 4)

B. Threshold setting: to set threshold of total load current.See below.

User can set up the threshold of current, voltage, temperature and humidity from the threshold

settings page as figure 3.

Figure 3

Set up the threshold of current, voltage, temperature and humidity

The current of single phase range from 0-63A; three phase range from 0-32A and Direct current

range from 0-60A

The input voltage range from 170-276VAC

The temperate range from 0-40℃and humidity range from 0-99%

Table of contents

Other Eaton Power Distribution Unit manuals

Eaton

Eaton MBP6Ki User manual

Eaton

Eaton Remote Power Panel User manual

Eaton

Eaton Bussmann Series User manual

Eaton

Eaton PKZ Series Manual

Eaton

Eaton ePDU G3 User manual

Eaton

Eaton Powerslide RV Pedestal User manual

Eaton

Eaton PXS24 Series User manual

Eaton

Eaton Powerware 225 kVA Three-Phase Power Distribution... User manual

Eaton

Eaton xComfort CBEU-02/01 User manual

Eaton

Eaton EPBZ99 User manual

Eaton

Eaton ePDU G3 User manual

Eaton

Eaton Crouse-hinds series User manual

Eaton

Eaton ePDU User manual

Eaton

Eaton ePDU G3HD Guide

Eaton

Eaton AUX1NO+1NCDMM Manual

Eaton

Eaton Cutler-Hammer Magnum Digitrip 220+ User manual

Eaton

Eaton Pow-R-Line P2R Series User manual

Eaton

Eaton Power Xpert PXR 20 User manual

Eaton

Eaton Powerware 9390 User manual

Eaton

Eaton StructuredWiringSolutions ESWT41600 Manual

Eaton

Eaton 650 FR User manual

Eaton

Eaton ePDU G3 User manual

Eaton

Eaton Cutler-Hammer Digitrip RMS 510 Trip Unit User manual

Eaton

Eaton ePDU G3 Operating and maintenance manual

Popular Power Distribution Unit manuals by other brands

hager

hager SP 015 User instructions

Pakedge

Pakedge PowerPak 9 user guide

Pts

Pts 9042 Series installation guide

Shure

Shure WA405 user guide

CORNING

CORNING CCH 4U quick start guide

Panamax

Panamax M4LT-EX datasheet

PANCONNECT

PANCONNECT FLAT 3M Assembly instruction

Raytheon

Raytheon 138-118 manual

D&R ELECTRONICS

D&R ELECTRONICS PDU-6SS user manual

Botex

Botex PSA 322-6 DL quick start guide

GE QuiXtra 4000 Assembly and mounting instructions

RDL

RDL EZ Series Installation and operation manual

StarTech.com

StarTech.com RKPW161915 Spec sheet

Vertiv

Vertiv Knürr DI-Strip Rack PDU manual

ABB

ABB PSBS0065 Instruction handbook

Baumuller

Baumuller BFN 3-1-0007-001 Instruction handbook

GE GEK-45404F instructions

Huawei

Huawei PDU8000 Series user manual
