E-matic EWT136WT User manual
User Guide
10” Quad-Core Tablet with Windows™ 10
EWT136WT
Since the tablet software updates regularly, the user manual
may not cover all aspects of new features.
• The new battery will be in its best condition after
being fully charged and discharged 2-3 times.
• While using earphones, if the volume is excessively
high it may cause hearing damage. Please adjust the
volume of the player to a safe and moderate level
during use.
• Do not disconnect the tablet suddenly when format-
ting or uploading and downloading, which can lead
to program errors.
• Do not dismantle the tablet by yourself, and do not
use alcohol, thinner or benzene to clean its surface.
• Do not use the tablet while driving or walking.
• The tablet is not moisture and water resistant. Please
do not use it in a damp environment.
• Do not drop or hit the tablet against a hard surface,
or the screen may be damaged or cracked.
• Do not upgrade the firmware by yourself. The tablet
should be upgraded with the right firmware and right
methods offered by us. If upgrade is needed, please
contact us.
Important Notices
Section 1: Tablet Overview
Tablet Overview
Touch Screen Basics
Actions Center
Take a Screenshot
Section 2: Initial Setup
Turn on or Wake
Charging
Battery Status
Getting Started
Section 3: Personalize Your Tablet
Personalize Your Start Screen
Create Tiles
Customize Your Tiles
Background & Color
Personalize Your Lock Screen
Notications
Personalize Your Desktop
Section 4: Networks
Turn On/Off Wi-Fi
Forget a Wi-Fi Network
Connect/Disconnect to a VPN
Section 5: Connect to Devices
Pair with a Bluetooth Devices
Printing
Connect to TV, Monitor, or Projector
Section 6: Keyboard Settings
On-screen Keyboard
Other On-Screen Keyboard Options
Access On-screen Keyboard Settings
On-screen Keyboard Tips
Docking Keyboard
Connecting the Keyboard
Keyboard Functions
Section 7: Apps
Finding Apps
Switch Between Apps
Dual Screen Apps
4
4
5
6
7
8
8
8
9
10
10
10
11
11
11
12
12
12
13
13
14
14
15
15
15
16
16
17
17
17
18
18
19
20
21
21
21
22
Close Apps
App Commands
Uninstall Apps
App Help & Settings
Explore Apps
Alarm
Camera
Included Apps
Section 8: User Accounts
Microsoft Account or Local Account
Manage Your Accounts
Unlock & Sign-in
Sign-In Options
Change Your Password
Lock or Sign Out
Section 9: Ease of Access
Section 10: PC Settings
Section 11: Tips & Tricks
Extending Battery Life
Refresh/Reset
Troubleshooting
TechnicalSpecications
Customer Support
Limitations of Liability Statement
22
22
23
23
24
24
24
25
30
30
30
31
31
32
32
33
33
34
34
35
36
37
38
38
4
1. TABLET OVERVIEW
Camera
Camera
Speaker
Speaker
Speaker
Hold for 2 seconds to
turn on/off.
Press to sleep/wake up. Volume Up/Down
Microphone
Microphone
3.5mm Audio
3.5mm Audio
USB
USB
5v Charging
5v Charging
Micro USB
Micro USB
HDMI
HDMI
Micro SD
Micro SD
Hold for 2 seconds
to turn on/off.
Press to sleep/wake.
Volume
Up/Down
5
Touch Screen Basics
Swipe in from the right edge to reveal Action Center.
You can also return to the Start screen from here.
Swipe in from the left edge to switch to the last
used App.
Drag from the top edge of the screen down to the
bottom to close the current app.
Pinchorstretchyourngerstozoominandout.
Slideyourngersacrossthescreentoseemore.
6
Action Center
The action center allows you to view and manage the
accumulatednoticationsandgivesyouquickaccess
to commonly customized settings.
Touch: Swipe from right edge of the screen
andtapthenoticationyouwanttoview,or
thesettingyouwanttocongure.
Keyboard: Windows Key + A
To open the Action Center
Lock the devices current orientation.
Turn Bluetooth® on or off
Switch from desktop to tablet mode.
Connect to a WiFi network.
7
Access all device settings .
Connect to wireless display or audio devices.
Activate to save battery.
Tap to connect to a connection via VPN
service.
Activatetodisablenoticationsafteracer-
tain hour.
Tap to activate airplane mode.
Enable or disable location settings.
Adjust the displays brightness
Take a Screenshot
To take a screenshot of your screen:
1. Hold Windows button down while pressing the
Volume Down key.
2. Screen will dim.
3. The image will be saved to the screenshots folder in
your photos.
Note: Sometimes the Screenshot option doesn’t appear,
dependingonwhatappyouarein.Justtaptherstbutton
underneath Share, and the Screenshot option will appear.
8
2. INITIAL SETUP
Turn on / Wake
To turn on your tablet, press and hold the power key
for 2 seconds.
Once the screen loads, connect to your Wi-Fi network.
To wake, press the power button and the lock screen
should appear. Swipe up to unlock and sign in.
Charging
Fully charge your tablet for 6 hours
beforetherstuse.
Use the included wall
charger.
The battery indicator will
show that your device is
charging.
9
Battery Status
Battery
Status
There are a few places you can check on your battery
status:
The lower left corner of the lock screen.
The lower right corner of the Desktop taskbar.
Battery Status
Note:: Plug your tablet into the charger when you see a
low battery warning.
