Dukane ImagePro 8774 Technical document

56

Mini D-Sub 15 Pin Connector

Pin Assignments of D-Sub COMPUTER Input Connector

Signal Level

Video signal : 0.7Vp-p (Analog)

Sync signal : TTL level

11 1512 1413

6

54321

10798

7. Appendix

Pin No. RGB Signal (Analog) YCbCr Signal

1Red Cr

2Green or Sync on Green Y

3Blue Cb

4Ground

5Ground

6Red Ground Cr Ground

7Green Ground Y Ground

8Blue Ground Cb Ground

9No Connection

10 Sync Signal Ground

11 SCART Sync

12 Bi-directional DATA (SDA)

13

Horizontal Sync or Composite Sync

14 Vertical Sync

15 Data Clock
