Drive Clever-Lite LS Installation instructions manual

of defects in materials and workmanship for the

lifetime of the original consumer purchaser.

This device was built to exacting standards

and carefully inspected prior to shipment. This

Lifetime Limited Warranty is an expression of our

confidence in the materials and workmanship of

our products and our assurance to the consumer

of years of dependable service.

In the event of a defect covered by this warranty,

we will, at our option, repair or replace the device.

This warranty does not cover device failure due to

owner misuse or negligence, or normal wear and

tear. The warranty does not extend to non-durable

components, such as rubber accessories, casters,

and grips, which are subject to normal wear and

need periodic replacement.

If you have a question about your Drive device or

this warranty, please contact an authorized Drive

dealer.

Port Washington, NY 11050

MADE IN CHINA

© 2002 Medical Depot, Inc. All rights reserved.

Drive is a trademark of Medical Depot, Inc.

Port Washington N.Y. 11050 USA Made in China

LIFETIME LIMITED

WARRANTY

Instructions & Warranty

www.drivemedical.com

Clever-Lite LS

Item #10233 Shown

Do

not

attempt

to

adjust

or

operate

walker

without

carefully reading all instructions in this manual.

Wide

Comfortable

Seat

OrthodicHand Grips

Trigger release

allows easy

folding

Backrest

Sealed Wheel

Bearing for

Smooth Operation

Item #10233

Push Lock Style

Assembly Instructions:

Safety Precautions:

First remove all contents from carton: backrest,

handle with tube, Walker frame and basket.

Open Frame and slide padded backrest into frame

brackets making sure snap bottons protrude

through holes.

Unscrew tightening knob from handle and insert

handle tube into frame at desired height lining up

holes appropriately. Slide bolts through holes from

the inside and screw on tightening knob until secure.

1

2

3

Please make sure the Walker is fully opened, seat is

down and the folding bar under seat is locked in the

down position.

Be sure that both knobs are fully tightened and are

at equal heights. Test Rollator for stability before

applying full weight to hand grips.

Test the push down locks before operating the Walker.

When wheels are locked (by sitting or having weight

applied by pushing down on handles), rear wheels

should prevent wheels from turning. If the wheels

turn while locks are locked, please take unit back to

dealer for adjustment. When weight is released, the

wheels should turn freely.

Weight will lock push locks by sitting. Do not use seat

when unit is on an incline or uneven ground.

Replace tires when signiﬁcantly worn or damaged.

Do not have anyone push you while you are seated on

the Walker. This is a walking aid only and is not to be

used as a transportation device.

Push Down

Lock Operation:

Always engage and disengage wheel locks on both sides

simultaneously.

To Slow Down or Come to a Temporary Stop —

Push down slowly by applying weight on the handles

until unit slows down or comes to a temporary stop.

To Temporarily Lock Wheels in Position —

Once seated, rear wheels will automatically lock until

weight is removed.

To Release Wheel Locks —

Remove weight until wheels start moving freely.
