Dometic RMDX 21 User manual

RMDX21, RMDX25

Absorber refrigerator

Operating manual

REFRIGERATION

REFRIGERATORS

RMDX21-25--O-AU.book Seite 1 Freitag, 3. Februar 2017 5:10 17

RMDX21-25--O-AU.book Seite 2 Freitag, 3. Februar 2017 5:10 17

RMDX21, RMDX25

Please read this instruction manual carefully before first use, and store it in

a safe place. If you pass on the product to another person, hand over this

instruction manual along with it.

Table of contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

7 Using the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

8 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

RMDX21-25--O-AU.book Seite 3 Freitag, 3. Februar 2017 5:10 17

Explanation of symbols RMDX21, RMDX25

1 Explanation of symbols

2 Safety instructions

The manufacturer accepts no liability for damage in the following cases:

•Damage to the product resulting from mechanical influences and excess voltage

•Alterations to the product without express permission from the manufacturer

•Use for purposes other than those described in the operating manual

2.1 General safety

!WARNING!

•Never open the absorber unit. It is under high pressure and can cause

injury if it is opened.

•Do not operate the refrigerator if it is visibly damaged.

•If the power cable for this refrigerator is damaged, it must be replaced

by the manufacturer, customer service or a similarly qualified person in

order to prevent safety hazards.

•This refrigerator may only be repaired by qualified personnel.

Inadequate repairs may cause serious hazards.

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

RMDX21-25--O-AU.book Seite 4 Freitag, 3. Februar 2017 5:10 17

RMDX21, RMDX25 Safety instructions

•This refrigerator can be used by children aged 8 years or over, as well

as by persons with diminished physical, sensory or mental capacities

or a lack of experience and knowledge, providing they are supervised

or have been instructed how to use the refrigerator safely and are

aware of the resulting risks.

•Cleaning and user maintenance must not be carried out by

unsupervised children.

•Children must be supervised to ensure that they do not play with the

refrigerator.

•Do not store any explosive substances, such as spray cans with

propellants, in the refrigerator.

!CAUTION!

•Danger of crushing! Do not put your fingers into the hinge.

•Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

•Do not open the refrigerant circuit under any circumstances.

•The refrigerant in the refrigerator circuit is highly flammable.

In the event of any damage to the refrigerator circuit (smell of

ammonia):

– Switch off the refrigerator if applicable.

– Avoid naked flames and sparks.

– Air the room well.

•Check that the voltage specification on the type plate is the same as

that of the power supply.

•The refrigerator is not suitable for storing substances which are caustic

or contain solvents.

•Keep the drainage outlet clean at all times.

•Do not use a high-pressure cleaner near the ventilation grille when

cleaning the vehicle.

•Never pull the plug out of the socket by the connection cable.

•The refrigerator lighting may only be replaced by customer service.

•The refrigerator may not be exposed to rain.

RMDX21-25--O-AU.book Seite 5 Freitag, 3. Februar 2017 5:10 17

Safety instructions RMDX21, RMDX25

2.2 Safe operation

!CAUTION!

•Close and lock the refrigerator door before beginning a journey.

•The refrigerator unit at the back of the refrigerator becomes hot during

operation. Protect yourself from coming into contact with hot parts

when removing ventilation grilles.

•Only store heavy objects such as bottles or cans in the refrigerator

door, in the vegetable drawer or on the bottom shelf.

ANOTICE!

•Do not use electrical devices inside the refrigerator unless they are

recommended by the manufacturer for that purpose.

•Danger of overheating!

Always ensure sufficient ventilation so that the heat generated during

operation can dissipate. Make sure that the refrigerator is sufficiently

far away from walls and other objects so that the air can circulate.

•Ensure that the ventilation openings are not covered.

•Do not fill the inner container with ice or fluid.

•Protect the refrigerator and the cable against heat and moisture.

•Make sure that foodstuffs do not touch the walls of the cooling area.

2.3 Safety when operating with DC power

ANOTICE!

•Only select operation with DC power supply (battery mode) if the

vehicle engine is running and providing sufficient voltage to the light

system, or if you are using a battery monitor.

2.4 Safety when operating with AC power

ANOTICE!

•Check that the voltage specification on the type plate is the same as

that of the power supply.

•Only use the cable supplied to connect the refrigerator to the

AC mains.

•Never pull the plug out of the socket by the connection cable.

RMDX21-25--O-AU.book Seite 6 Freitag, 3. Februar 2017 5:10 17

RMDX21, RMDX25 Scope of delivery

2.5 Safety when operating with gas

!WARNING!

•Only operate the refrigerator at the pressure shown on the type

plate. Only use pressure controllers with a fixed setting which comply

with national regulations.

•Never store liquid gas cylinders in unventilated areas or below

ground level (funnel shaped holes in the ground).

•Keep liquid gas cylinders away from direct sunlight. The temperature

may not exceed 50 °C.

•Never operate the refrigerator with gas

– at petrol stations

– while driving

– while transporting the caravan or mobile home with a transport

vehicle or tow truck

•Never use a naked flame to check the refrigerator for leaks.

•If you smell gas:

– Close the gas supply cock and the valve on the cylinder.

– Open all windows and leave the room.

– Do not press an electric switch.

– Put out any naked flames.

– Have the gas system checked by a specialist.

ANOTICE!

•Only use universal LPG gas.

3Scopeofdelivery

•Refrigerator

•Ice-cube tray

•Operating manual

•Installation manual

4Accessories

Accessories available from your local Dometic agent.

RMDX21-25--O-AU.book Seite 7 Freitag, 3. Februar 2017 5:10 17

Intended use RMDX21, RMDX25

5 Intended use

The refrigerator is designed for installation in caravans or motorhomes. It is only suit-

able for cooling, freezing and storing foodstuffs. The refrigerator is not intended for

the proper storage of medicine.

The refrigerator is designed to be operated on a DC power supply and an AC socket

and can be powered by liquid universal LPG gas. The refrigerator may not be run on

natural gas or city gas.

6 Technical description

6.1 Description

The refrigerator is an absorption refrigerator. The refrigerator is designed to operate

with different types of power and can be run on an AC power supply, a DC power

supply or with liquefied universal LPG gas. For DC operation, the vehicle battery can

be used. The thermostatic control ensures that the refrigerator temperature is kept

constant and as little power as possible is consumed.

The refrigerator is equipped with an automatic safety device which automatically

terminates the gas supply to the burner approximately 30 seconds after the flame

goes out and remains out.

The RMDX21 refrigerator has manual power mode selection.

The RMDX25 refrigerator has an automatic operating mode which selects the most

economical power mode connected.

CAUTION! Health hazard!

Please check if the cooling capacity of the refrigerator is suitable for

storing the food you wish to cool.

NOTE

To safely operate 12 V consumer units in the caravan, it must be ensured

that the towing vehicle provides sufficient voltage. On some vehicles,

the battery management system may automatically switch off the con-

sumer unit to protect the battery. Ask your vehicle manufacturer for

more information.

RMDX21-25--O-AU.book Seite 8 Freitag, 3. Februar 2017 5:10 17

RMDX21, RMDX25 Technical description

6.2 Components

No. in

fig. 1Description

1 Ice compartment

2 Top tray with flap

3 Bottom tray with bottle holder

4 Vegetable compartment

5 Type plate

6 Thawed water drainage channel

7 Secondary evaporator for refrigerator

8 Control elements

RMDX21-25--O-AU.book Seite 9 Freitag, 3. Februar 2017 5:10 17

Technical description RMDX21, RMDX25

Inside the refrigerator, you can see the type plate of the refrigerator. There you can

see the model name, product number and serial number. You will need this

information whenever you contact the customer service or order spare parts:

No. in

fig. 2Description

1 Model number

2 Product number

3 Serial number

4 Electrical connection value

5 Gas pressure

6 Test mark/certification

BRUTTOINHALT

TOTAL CAP.

VOLUME BRUT

VERDAMPFERFACH

FREEZER COMP.

VOLUME COMPT BT

MADE IN GERMANY

MLCPROD. NO.MOD. NO.

TYPE

C 40/110

100 l

106 l

~ 230 – 240V / 135 W UNIVERSAL LPG

INJECTOR: 43

CE 0063 BL3214

ABSORBER NH

= 135 g

5375

CrO

= 8,1 g

G30, G31 p = 30/37 mbar

p max = 35 bar

INLET: 2,75 (2,5 – 3,5) kPa TPP: 2,75 kPa

NGC: 0,82 MJ/h

12 V / 130 W

9 l

0 l

96 l

102 l

RM 850x 0092107xxxx 33500xxx

CLIMATE CLASS SKU

SER. NO.

00107597289

APPROVAL NO. SAA111752EA

ACN 086 366 305 Z660

NUTZINHALT

USEFUL CAP.

VOLUME NET

RMDX21-25--O-AU.book Seite 10 Freitag, 3. Februar 2017 5:10 17

This manual suits for next models

Table of contents

Other Dometic Refrigerator manuals

Dometic

Dometic RMD 8501 User manual

Dometic

Dometic RM8 Series User manual

Dometic

Dometic NDR 1402 User manual

Dometic

Dometic miniCool EA3255 User manual

Dometic

Dometic EA 3280 User manual

Dometic

Dometic REFRIGERATION 10-Series User manual

Dometic

Dometic HiPro3000 User manual

Dometic

Dometic MC Series User manual

Dometic

Dometic miniCool DS301H User manual

Dometic

Dometic DM2672 User manual

Dometic

Dometic CRX Series User manual

Dometic

Dometic RM 8400 User manual

Dometic

Dometic Silhouette S1521 User manual

Dometic

Dometic RM2662 User manual

Dometic

Dometic RM2351 User manual

Dometic

Dometic RM2551 User guide

Dometic

Dometic AMERICANA RM2652 User manual

Dometic

Dometic RGE 2100 User manual

Dometic

Dometic RH418NTE User manual

Dometic

Dometic A30P1 User manual

Dometic

Dometic MF6W User manual

Dometic

Dometic NDR1062 User manual

Dometic

Dometic Type C40/110 User manual

Dometic

Dometic RH423LDA Operating instructions

Popular Refrigerator manuals by other brands

Bonnet Neve

Bonnet Neve SKYVIEW PLUS User instructions

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Instruction book

Sharp

Sharp SJ-BA31IEXW2-EU user manual

CORBERO

CORBERO CC2300MCW Instruction booklet

KitchenAid

KitchenAid 2205264 Use and care guide

Stengel

Stengel KU 1101 A++ user manual

NEFF

NEFF KI181 Series user manual

Hoshizaki

Hoshizaki Reach-In instruction manual

Amana

Amana ASD2524VES00 User instructions

BOMANN

BOMANN KGC 213 instruction manual

Danby

Danby DAR044A1SLDD Owner's use and care guide

Samsung

Samsung RF323TE user manual

Beko

Beko CSA31022 Instructions for use

IKEA

IKEA FROSTIG C 185 E manual

Electrolux

Electrolux ER 6821 D Instruction book

True

True TS-28 Specifications

Frigidaire

Frigidaire FSC23R5DW9 installation guide

Beko

Beko LSP4579W Instructions for use
