CT100G Series Inverter Safety precautions
- 3 -
»Keep the signal cables of the inverter away from the power cables as far as
possible, or distribute the two categories of cables vertically-crossed if the
distance is not far enough, otherwise it may cause signal interference.
» Ensure that all the screws are tightened when wiring, otherwise damage to
the inverter may occur.
» The encoders and sensors should be applied with the shielded cables and
the shielded layer should be grounded reliably.
Operation
» Confirm that the wiring is completed and correct and then cover the plate
before power on.
» Do not open the plate after power on, otherwise electric shock may occur.
» Operate the inverter appropriately, otherwise damage to the inverter may
occur.
» Non-professionals are not allowed to test the signals when the inverter is
running. Otherwise, physical injury or damage to the devices may occur.
» Do not change the parameters of the inverter at random, otherwise damage
to the inverter may occur.
» Do not touch the fans and brake resistors, otherwise it may cause
mechanical injury or burn.
» Do not start up or stop the inverter by power on or off, otherwise damage to
the inverter may occur.
» Ensure that the circuit breakers or contactors at the output sides of the
inverter are not in output state before switching, otherwise damage to the
inverter may occur.
CT100G Series Inverter Safety precautions
- 4 -
Others
» This inverter is not suitable for the occasions when the specifications exceed
those specified in this manual. If you have special requirements, please
contact our technical department.
» The inverter is equipped with surge suppressors inside, which can protect it
from the lightning. It is necessary to mount external surge suppressors at the
power input side of the inverter in high lightning incidence areas.
» When the conductors between the inverter and the motor exceed 100m, it is
recommended to mount the output reactors to avoid overcurrent caused by
excessive distributed capacitance.
» Do not mount the compensation capacitors and the surge absorbers at the
output sides of the inverter. Otherwise, it may cause damage to the inverter
due to overheating.
» Mounting the input or output reactors, special filters and magnetic rings at
the input or output sides of the inverter can effectively reduce the noise and
thus avoid interference to other devices.
» Non-professionals are not allowed to perform withstand voltage tests on the
inverter, , otherwise damage to the inverter may occur.
» Deal with the devices as industrial effluent after scrapping. Burning is strictly
prohibited, otherwise an explosion may occur.
» The cooling effect of the inverter is reduced and the electrolytic capacitor
electrolyte is also volatile in high altitude areas, which will shorten the life of
the inverter. Check the altitude of the actual usage site is below 1000m. If
higher than 1000m, reduce 1% for every additional 100m.
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 5 -
CHAPTER 1 PRODUCT INFORMATION
1.1 Product model name rules
The letters and numbers of the type designation key indicate product
series, voltage, power, load etc.
Figure 1-1 Type designation key
1.2 Product specifications and technical parameters
1.2.1 Product specifications
Table 1-1 Product Specifications
Inverter mode Power
（KW）
Input
current
（A）
Output
current
（A）
Applicable
motor power
（KW）
Single phase 220V 50/60Hz
CT100G-2S-0.7G-B 0.75 8.2 4.5 0.75
CT100G-2S-1.5G-B 1.5 14.0 7.0 1.5
CT100G-2S-2.2G-B 2.2 23.0 9.6 2.2
CT100G-2S-4.0G-B 4.0 36.0 16.0 4.0
CT100G-2S-5.5G-B 5.5 46.0 20.0 5.5
CT100G-2S-7.5G-B 7.5 68.0 30.0 7.5
Three phase 380V 50/60Hz
CT100G-4T-0.7G-B 0.75 3.4 2.5 0.75
CT100G-4T-1.5G-B 1.5 5.0 3.7 1.5
CT100G-4T-2.2G-B 2.2 5.8 5.3 2.2
CT100G-4T-4.0G-B 4.0 12.0 9.5 4.0
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 6 -
CT100G-4T-5.5G-B 5.5 18.5 14 5.5
CT100G-4T-7.5G-B 7.5 22.5 18.5 7.5
CT100G-4T-11G-B 11 30.0 25.0 11
CT100G-4T-15G-B 15 39.0 32.0 15
CT100G-4T-18.5G-B 18.5 45.0 38.0 18.5
CT100G-4T-22G-B 22 54.0 45.0 22
CT100G-4T-30G-B 30 68.0 60.0 30
CT100G-4T-37G 37 84.0 75.0 37
CT100G-4T-45G 45 98.0 92.0 45
CT100G-4T-55G 55 123.0 115.0 55
CT100G-4T-75G 75 157.0 150.0 75
CT100G-4T-90G 90 188.0 180.0 90
CT100G-4T-110G 110 221.0 215.0 110
CT100G-4T-132G 132 267.0 260.0 132
CT100G-4T-160G 160 309.0 305.0 160
CT100G-4T-185G 185 344.0 340.0 185
CT100G-4T-200G 200 384.0 380.0 200
CT100G-4T-220G 220 429.0 425.0 220
CT100G-4T-250G 250 484.0 480.0 250
CT100G-4T-280G 280 539.0 530.0 280
CT100G-4T-315G 315 612.0 600.0 315
CT100G-4T-355G 355 665.0 650.0 355
CT100G-4T-450G 450 805 795.0 450
CT100G-4T-500G 500 890 860.0 500
CT100G-4T-560G 560 1045 1015 560
CT100G-4T-630G 630 1224 1200 630
Note: 1. The inverters with power less than or equal to CT100G-4T-160G are
equipped with braking units, but 37-160kw models are optional with or without
braking units. And braking resistors inside whose power and resistance are as
required as the table 2-2, otherwise has risk of damage. CT100G-4T-185G and
bigger power models can be equipped with external braking units bought by
customers themselves.
2. The above models are the standard general purpose inverters, excluding the
industrial special inverters. You can customize non-standard inverters of other
specifications.
1.2.2 Technical parameters
Table 1-2 Technical parameters
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 7 -
Input and
output
parameters
Input voltage Single-phase 220VAC±15%
Three-phase 380VAC±15%
Input frequency 50～60Hz±5%
Output voltage 0～Rated input voltage
Output frequency 0～500Hz, unit 0.01Hz
Overload
capacity
150% of rated current: 60s; 180% of rated
current: 10s; 200% of rated current: 1s
Running
control
parameters
Control mode V/F control, sensorless vector control (SVC)
Adjustable-speed
ratio 1:100 (V/F); 1:200 (SVC)
Speed control
accuracy ±0.5%
Speed wave ± 0.5%
Start torque 0.5Hz/150% (V/F)
0.25Hz/150% (SVC)
Based
functions
Starting
frequency 0.00～10.00Hz
ACC and DEC
time 0.1～65000.0s
Carrier frequency0.5KHz～16.0KHz
Frequency
setting
UP/DOW setting,analog setting, digital setting,
multi-step speed setting, PID setting,
MODBUS communication setting, to realize
switch of combination and channel setting.
Start mode Start frequency, DC braking and start
Stop mode DEC stop, free stop, DEC
+DC braking
Energy braking
capability Braking unit braking voltage:320～750V
DC braking
capability
DC braking frequency: 0～500Hz;
DC braking waiting time: 0～10s;
DC braking current: 0.0～100.0%;
DC braking time: 0.0～100.0s;
Auto voltage
adjustment
Keep a stable voltage automatically when the
grid voltage transients
Sudden
frequency down
Keep stable bus voltage while power net
low-voltage
Control
terminals
Digital input Standard 8-channel inputs, one of which can
be high-speed pulse input (HDI)
Analog input Standard 2-channel inputs, AI1: 0～10V or
0/4～20mA input optional, AI2:0V0～+10V
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 8 -
Digital output
Standard 2-channel multi-function collector
outputs, one of which can be high-speed pulse
output (HDO).
Relay output Standard 2-channel relay outputs
Communication
interface
RS485
Communication
RS485 communication interface for external
communication, support Modbus protocol
(RTU mode).
Fault protection
ACC overcurrent, DEC overcurrent, constant speed overcurrent,
ACC overvoltage, DEC overvoltage, constant speed overvoltage,
bus under voltage, motor overload, inverter overload, input
power failure, output phase loss, rectifier module overheating,
inverter module overheating, external fault, communication fault,
current detection fault, EEPROM operation fault, PID feedback
fault, factory setting time arrive etc.
Keypad display LED display Highlight LED digital tube displays the inverter
information
Others
Running
environment
Indoors, less than 1km above sea level,
without dust, corrosive gases or direct sunlight
Ambient
temperature
-10～+40℃, derate 1% for every additional 1℃
when the ambient temperature is between
40～50℃
Humidity 5～95% (no condensation)
Altitude 0～2000m, derate 1% for every additional
100m when the sea level is above 1000m
Vibration Less than 0.5g
Storage
temperature −40～+70℃
Control
terminals Digital input Standard 8-channel inputs, one of which can
be high-speed pulse input (HDI)
1.3 Product outline and installation size, weight
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 9 -
a) C0 models
b) C1,C2 models
c) C3~C6 models
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 10 -
d) C7,C8 models
e) C11,C12 models
Figure 1-2 Product appearance and installation dimensions diagram
Table 1-3 Structure, mounting dimension and weight
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 11 -
Inverter mode Appearance and dimensions（mm）Installing
hole(mm) weight cabinet
W H D W1 H1 H2
CT100G-2S-0.7G-B
126 186 155 115 175 --- 5 1.6 C0
CT100G-2S-1.5G-B
CT100G-2S-2.2G-B
CT100G-4T-0.7G-B
CT100G-4T-1.5G-B
CT100G-4T-2.2G-B
CT100G-4T-4.0G-B
CT100G-4T-5.5G-B
CT100G-4T-7.5G-B 140 230 172 128 218 --- 5.5 3.5 C1
CT100G-4T-11G-B 165 285 200 153 273 --- 5.5 5.2 C2
CT100G-4T-15G-B
CT100G-4T-18.5G-B
214 402 205 184 360 385 7 11.5 C3CT100G-4T-22G-B
CT100G-4T-30G-B
CT100G-4T-37G 250 442 230 220 405 425 7 19 C4
CT100G-4T-45G
CT100G-4T-55G
299 602 276 240 540 580 9 30 C5
CT100G-4T-75G
CT100G-4T-90G
CT100G-4T-110G
CT100G-4T-132G 329 660 332 250 601 640 9 56 C6
CT100G-4T-160G
CT100G-4T-185G
480 853 354 180 772 826 11 110 C7
CT100G-4T-200G
CT100G-4T-220G
CT100G-4T-250G
CT100G-4T-280G
CT100G-4T-315G
680 940 370 290 908 --- 13 165 C8CT100G-4T-355G
CT100G-4T-400G
CT100G-4T-450G 880 962 370 170 928 180 13 200 C11
CT100G-4T-500G
CT100G-4T-560G 950 962 380 314 923 --- 13 220 C12
CT100G-4T-630G
CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 12 -
1.4 Outline and size of keypad
Figure 1-3 Structure diagram of the keypad (unit: mm)
Figure 1-4 Structure diagram of the outer bracket (unit: mm)
Note: while use external keypad, the wire should not be more than 30m, otherwise there is
risk of keypad not work.
