Dolmar AR-3733 User manual
AR-3733
EN Battery Powered Pruning
Shears INSTRUCTION MANUAL 8
FR Sécateur à batterie MANUEL D’INSTRUCTIONS 16
DE Akku-Astschere BETRIEBSANLEITUNG 25
IT Cesoie per potare a batteria ISTRUZIONI PER L’USO 35
NL Accusnoeischaar GEBRUIKSAANWIJZING 45
ES Tijera de podar Inalámbrica MANUAL DE
INSTRUCCIONES 54
PT Tesoura de Jardim a Bateria MANUAL DE INSTRUÇÕES 63
DA Akku grensaks BRUGSANVISNING 72
EL Κλαδευτικό ψαλίδι μπαταρίας ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ 80
TR Akülü Budama Makası KULLANMA KILAVUZU 90
1
4
2
10
3
7
9
11
8
56
Fig.1
1
2
3
4
3
Fig.2
1
2
Fig.3
2
1
2
3
Fig.4
1
Fig.5
1
Fig.6
1
Fig.7
1
2
3
Fig.8
1
2
3
Fig.9
1
2
Fig.10
1
Fig.11
3
Fig.12
1
Fig.13
2
1
4
1
3
5
Fig.14
Fig.15
Fig.16
Fig.17
4
Fig.18
1
Fig.19
21
4
1
3
5
Fig.20
Fig.21
Fig.22
1
Fig.23
Fig.24
5
Fig.25
Fig.26
1
23
Fig.27
Fig.28
1
2
Fig.29
1
2
Fig.30
1
Fig.31
1
Fig.32
6
Fig.33
2
1
Fig.34
1
2
Fig.35
Fig.36
7
8ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: AR-3733
Max. cutting capacity 33 mm
Overall length (shears part) 305 mm
Rated voltage D.C.36 V
Battery cartridge AP-1815, BL1815N, BL1820, BL1820B AP-183, BL1830, BL1840, BL1840B,
BL1850, BL1850B, BL1860B
Net weight (with shears, switch box,
connection cord, two battery cartridges and
back pack)
3.3 kg 3.8 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsandbatterycartridgemaydifferfromcountrytocountry.
• Weight,withbatterycartridge,accordingtoEPTA-Procedure01/2003
Symbols
Thefollowingshowthesymbolsusedfortheequip-
ment.Besurethatyouunderstandtheirmeaningbefore
use.
Read instruction manual.
Do not expose to moisture.
Danger;beawareofthrownobjects.
Keep bystanders away.
Cd
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentor
battery pack together with household waste
material!
InobservanceoftheEuropeanDirectives,
onWasteElectricandElectronic
EquipmentandBatteriesandAccumulators
andWasteBatteriesandAccumulators
and their implementation in accordance
withnationallaws,electricequipmentand
batteries and battery pack(s) that have
reachedtheendoftheirlifemustbecol-
lected separately and returned to an envi-
ronmentallycompatiblerecyclingfacility.
Intended use
Thetoolisintendedforpruningtwigsorbranches.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ing to EN50636:
Sound pressure level (LpA) : 70 dB(A) or less
Uncertainty(K):3.2dB(A)
Thenoiselevelunderworkingmayexceed80dB(A).
WARNING: Wear ear protection.
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
mined according to EN50636:
Vibration emission (ah):2.5m/s2or less
Uncertainty(K):1.5m/s2
NOTE:Thedeclaredvibrationemissionvaluehas
been measured in accordance with the standard test
methodandmaybeusedforcomparingonetoolwith
another.
NOTE:Thedeclaredvibrationemissionvalue
mayalsobeusedinapreliminaryassessmentof
exposure.
WARNING:Thevibrationemissionduringactual
useofthepowertoolcandifferfromthedeclared
emission value depending on the ways in which the
tool is used.
WARNING:Besuretoidentifysafetymeasures
to protect the operator that are based on an estima-
tionofexposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
thetimeswhenthetoolisswitchedoffandwhenitis
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
MakitadeclaresthatthefollowingMachine(s):
DesignationofMachine:BatteryPoweredPruning
Shears
ModelNo./Type:AR-3733
ConformstothefollowingEuropeanDirectives:
2006/42/EC
Theyaremanufacturedinaccordancewiththefollowing
standard or standardized documents: EN ISO 12100
Thetechnicalleinaccordancewith2006/42/ECis
availablefrom:
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
29.1.2015
9ENGLISH
Yasushi Fukaya
Director
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
Pruning shears safety warnings
WARNING: Read all safety warnings and
all instructions. Failuretofollowthewarningsand
instructionsmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. Use personal protective equipment. Always
wear eye protection.Protectiveequipmentsuch
asdustmask,non-skidsafetyshoes,hardhat,or
hearingprotectionusedforappropriateconditions
willreducepersonalinjuries.
2. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
3. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing, and gloves
away from moving parts.Looseclothes,jewel-
lery or long hair can be caught in moving parts.
4. This tool is for pruning branches. Do not use it
foranyjobexceptthatforwhichitisintended.
5. Never allow children, persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge or people
unfamiliar with these instructions to use the
tool. Local regulations may restrict the age of
the operator.
6. Never operate the tool while people, especially
children, or pets are nearby.
7. Do not overreach and keep balance at all
times.Alwaysbesureoffootingonslopesandto
walk, never run.
8. Do not touch moving hazardous parts before
the tool is disconnected from the mains and/or
the battery pack is removed from the tool.
9. Always wear substantial footwear and long
trousers while operating the tool.
10. Disconnect the supply and/or remove the
battery pack from the tool:
• wheneverthetoolisleftbytheuser,
• beforeclearingablockage,
• beforechecking,cleaningorworkingonthe
tool,
• afterstrikingaforeignobjecttoinspectthe
toolfordamage,
• ifthetoolstartstovibrateabnormally,for
immediately check.
11. Never operate the tool with defective guards
or shields, or without safety devices, or if the
cord is damaged or worn.
12. Avoid using the tool in bad weather conditions
especially when there is a risk of lightning.
13. Don’t use the tool or perform battery charging
operations in the rain.
14. Don’t leave the tool in rain or wet locations.
15. Be careful not to catch foreign matter between
the blades.Ifthebladesarejammedwithforeign
matter,immediatelyswitchoffthetoolanddiscon-
nectthebatteryfromthetool.Thenremovethe
foreignmatterfromtheblades.
16. Never hold the branch you are pruning with
your free hand.Keepyourfreehandawayfrom
the cutting area. Never touch the blades, they are
verysharpandyoumaycutyourself.
17. Don’t force the tool to make it cut. You could
slipandinjureyourselforcutsomethingelse
unintentionally.
18. Avoid cutting electrical wires that may be
hidden.
19. Always check the blades carefully before
operation.
20. Handle the blades with extreme care to prevent
cuts or injury from the blades.
21. Disconnect the battery from the tool after each
use and before attempting to perform inspec-
tion or maintenance.
22. When not in use, always keep the tool in its
holster.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs.Useofanyotherbattery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Follow instruction for lubricating and chang-
ing accessories.
3. Keep handles dry, clean and free from oil and
grease.
10 ENGLISH
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. Follow your local regulations relating to dis-
posal of battery.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita/Dolmar
batteries.Useofnon-genuineMakita/Dolmarbatter-
ies, or batteries that have been altered, may result in
thebatteryburstingcausingres,personalinjuryand
damage.ItwillalsovoidtheMakita/Dolmarwarranty
fortheMakita/Dolmartoolandcharger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).
N Mark
TheNMarkisatrademarkorregisteredtrademarkof
NFCFormula,Inc.inUSAandothercountriesinthe
world.
PARTS DESCRIPTION
►Fig.1
1Harness 2Back pack 3Switch box 4Pilot lamp (red)
5Pilot lamp (green) 6I/Oswitch 7Holster 8Cord holder
9Connection cord 10 Shears 11 Switch trigger - -
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
Removing or installing battery
cartridge
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridgermlymaycausethemtoslipoffyourhands
and result in damage to the tool and battery cartridge
andapersonalinjury.
Table of contents
Languages:
Other Dolmar Power Tools manuals
