Dogtra 175 NCP User manual

MAIN FEATURES

PRODUCT SAFETY AND HEALTH

STATEMENTS

COLLAR PACKAGE CONTENTS

DESCRIPTION OF TRANSMITTER PARTS

DESCRIPTION OF COLLAR / RECEIVER PARTS

BATTERY CHARGER

CHARGING THE BATTERIES

TESTING YOUR COLLAR

OPERATING INSTRUCTIONS

ACCESSORIES

WARRANTY AND REPAIR INFORMATION

CONTENTS

2 3

Easy-to-use, ergonomic transmitter.

Rheostat dial that allows for gradual increases

in stimulation intensity with no jumps

between levels.

The has a range of 400+

yards.

Waterproof collar/receiver and water-resistant

transmitter.

No external antenna on the collar receiver.

Rechargeable, user-replaceable Ni-MH

batteries.

One-charger system allows the transmitter and

receiver to be charged at the same time.

Over 999 different identity codes to prevent

conflicts with other e-collars.

MAIN FEATURES

PRODUCT SAFETY AND HEALTH STATEMENTS

Safety for your dog

Studies conducted by animal health professionals at

Dogtra Company’s training facilities showed no

adverse effects to the cardiovascular or nervous system

of dogs from e-collar stimulation. These studies

involved healthy dogs in a controlled environment.

Dogs should be in good health during any e-collar

training. Dogtra e-collars are not intended for use on

dogs weighing less than 12 pounds or under 6 months

of age.

Skin irritation can occur from prolonged wearing of

the stainless steel contact points on the training collar.

Most dogs will exhibit some type of irritation (pressure

necrosis) from prolonged contact of stainless steel

contact points. This is why it states in your owner’s

manual:

Attention:

Avoid having the dog wear the collar with the

contact points in the same place for more than two hours

at a time. Leaving the contact points on the same spot for

an extended period of time can cause skin irritation.

If the dog is to wear the e-collar for long periods,

occasionally reposition the collar so that the contact

points are moved to a different spot on the dog’s neck.

PRODUCT SAFETY AND HEALTH STATEMENTS

4 5

PRODUCT SAFETY AND HEALTH STATEMENTS PACKAGE INCLUDES

Transmitter

Receiver

Battery charger and splitter cable

Owner’s manual

COLLAR

PACKAGE CONTENTS

Proper e-collar use

Dogtra e-collars are intended for the sole purpose

of behavior modification of dogs. They are not

intended for human use or use on other animals.

Dogtra Company does not assume any liability for

improper use of the Dogtra e-collar.

Aggressive dogs

Dogtra does not recommend using the e-collar to

correct dogs that are aggressive towards other dogs

or people. In many such cases the dog will associate

the stimulation with the other dog or individual and

become even more aggressive. Dog aggression is

best treated by a dog training specialist.

Interference with other electronic devices

Dogtra’s industry-leading technology filtering

system ensures minimal interference with other

electronic devices (cellular phones, security systems,

etc.). Our digital microprocessor offers thousands of

unique codes to eliminate frequency match-up with

other Dogtra e-collars.

Inadvertent activation

If the constant button is held down for 12

seconds or more the unit will automatically shut

down. It will reactivate when the button is released.

TRANSMITTER

DESCRIPTION OF

TRANSMITTER PARTS

transmitter

Antenna

Indicator Light

“Nick” Button

“Pager” Button

“Constant” Button

Intensity

Selection Dial

Battery Charging

Receptacle

and Cover

Transmitter Antenna

A short 2 antenna is supplied with the

transmitter.

The antenna should be screwed into the top of

the transmitter to ensure that the signals are sent

properly to the collar receiver and that maximum

range is attained.

2Antenna

TRANSMITTER

Intensity Selection Dial

The intensity selection dial is located on the

top of the transmitter: (0) being the lowest level

and (100) being the highest.

Transmitter Battery Charging Receptacle

Located on the side of the transmitter, the

receptacle is covered by a rubber plug. Insert one

end of the battery charging cable into the

receptacle to charge the battery. (See Battery

Charging Procedure on page 21.)

After charging is completed, cover the

receptacle with its rubber plug to make sure dirt

or water does not get inside.

TRANSMITTER

BUTTON FUNCTION

Transmitter Indicator Light (LED window)

The transmitter indicator light is located near

the intensity selection dial. When a button on the

transmitter is pushed, the light comes on to

indicate that the transmitter is being activated.

The color of the light indicates the status of

battery life. The LED glows green when the

battery is fully charged and turns to amber when

battery life is getting low. When the LED emits a

blinking red light, the battery needs to be

recharged.

green = full charge, amber = medium charge

red = needs charge

The transmitter for has three

buttons (two on the face of the transmitter and

one on the side).

BUTTON FUNCTION

Constant

Pager

Nick

BUTTON FUNCTION

COLLAR / RECEIVER

“Nick” Button

When the “Nick” button is pushed the

receiver emits a single, rapid pulse of electrical

stimulation.

“Constant” Button

Pressing the “Constant” button gives

continuous stimulation as long as the button is

pushed, for up to twelve seconds. If the button is

not released after twelve seconds, the stimulation

will automatically turn off as a safety feature.

The collar will be ready to be reactivated once

the button has been released.

“Pager” Button

Pressing the “Pager” button on the side of the

transmitter causes the collar to vibrate. This is a

great way of communicating with your dog using

non-electrical stimulation.

DESCRIPTION OF

COLLAR / RECEIVER PARTS

Collar

Red Dot On/Off

Magnetic Switch

Contact Points

Indicator

Light

Battery

Charging

Receptacle

and Cover

Collar strap

COLLAR / RECEIVER

On/Off Magnetic Switch

To activate the , place the red

dot on the back of the transmitter to the red dot on

the collar receiver. Hold the two red dots together

for a moment until the LED indicator light comes

on.

To deactivate the repeat the

same procedure holding the two red dots together

momentarily. The LED light will stop blinking,

indicating that the unit is now shut off. To attain

maximum battery life, deactivate the unit when

not in use.

On/Off

Magnetic Switch

Receiver Indicator Light (LED window)

Located on the front of the collar, the

indicator light comes on and blinks once every 2

seconds after the collar is turned on. The color of

the LED indicates the battery life of the receiver.

(green = full charge, amber = medium charge,

red = needs charge)

When the “Constant” button on the

transmitter is pushed, the collar indicator light

will glow steadily as long as you hold the button

down, for up to twelve seconds. When the

“Nick” button is pushed, the light comes on for a

fraction of a second.

COLLAR / RECEIVER

Fitting the Collar on the Dog

The collar should be fitted so that the

stainless steel contact points press firmly against

the dog’s skin.

A loose fit can allow the collar to move

around on the dog’s neck. When this happens the

contact points may rub the skin and cause

irritation. If the collar is too loose, electrical

contact will be inconsistent and your corrections

will be inconsistent also.

Receiver Battery Charging Receptacle

On the inside of the collar, next to the collar

strap, is a battery charging receptacle with a

rubber cover plug.

Internal Antenna

The has a non-exposed

antenna that is located inside the collar receiver.
