DOD MEATBOX User manual
1 2
3 4
5
6
8
7
1. OCTAVE - adjusts the amount of low octave being added to the signal.
2. OUTPUT - adjusts the overall output level of the eect.
3. SUB - adjusts the amount of synthesized sub harmonic eect is added to the signal.
4. LOW - adjusts the low frequency content of the overall eect.
WARNING: Start with the OUTPUT and LOW controls at minimum and gradually increase
their level to avoid possible speaker damage.
5. INPUT - connect your instrument here.
6. FOOTSWITCH - turns the eect on and o.
7. LED - turns on when the eect is enabled.
8. OUTPUT - connect to the next pedal input or to the input of your amplier. This output
allows you to route a dry unprocessed signal (Ring) and processed signal (Tip)
to an amplier and other eects simultaneously via TRS ‘Y’ cable.
Tip = Octave+Sub
Ring = Dry
Sleeve = Ground
USING MEATBOX:
Most bassists will favor placing the Meatbox at the beginning of
their chain of eects, so start with that placement. Guitarists may
nd it better to add after distortion eects or near the end of the
eect chain.
A typical eects signal chain will consist of Distortion eects rst
then Modulation eects (Chorus, Flanger, Phaser, Tremolo, etc...)
next and then nally Time based eects (Delay and Reverb).
This being said you may wish to experiment with dierent eect
placements.
SPECIFICATIONS:
Input 1/4”TS Unbalanced - 470 kΩ
Output 1/4”TRS Unbalanced - 100 Ω
Current Draw 20 mA
Bypass True Bypass
Power 9VDC alkaline battery (not included)
HARMAN PS0913DC power adapter (optional)
Warranty 1 Year
DOD
10653 River Front Parkway
South Jordan, UT 84095
USA
801-566-8800 Rev A - 6/15
