Dji MAVIC 3E User manual

DJI Mavic 3E

DJI Mavic 3T

Quick Start Guide

v1.0 2022.07

Aircraft

The DJITM MAVICTM 3E/3T features upward, downward, and horizontal omnidirectional Vision

Systems and Infrared Sensing System*, allowing for hovering and flying indoors as well as outdoors

and for automatic Return to Home while avoiding obstacles in all directions. With precise three-axis

gimbal to stabilize high-performance multi-camera load, the DJI Pilot 2 app can be used to observe

the real-time view from the cameras and take photos and videos. The built-in DJI AirSense detects

nearby aircraft in the surrounding airspace to ensure safety and beacon help to identify the aircraft

during flight. With a PSDK port so the aircraft can be equipped with designated accessories to adapt

to different application scenarios such as security, patrol inspection, and mapping.

1. Gimbal and Camera**

2. Horizontal Omnidirectional Vision System

3. Auxiliary Bottom Light

4. Downward Vision System

5. Infrared Sensing System

6. Front LEDs

7. Motors

8. Propellers

9. Aircraft Status Indicators

10. Landing Gears (Built-in antennas)

11. Upward Vision System

12. USB-C Port

13. microSD Card Slot

14. Battery Level LEDs

15. Intelligent Flight Battery

16. Power Button

17. Battery Buckles

18. Beacon

19. Extended Port (can be used to connect

accessories)

* The Vision and Infrared Sensing Systems are affected by surrounding conditions. Read the User

Manual for more information.

** The Mavic 3E and Mavic 3T are equipped with different cameras. Refer to the actual product

purchased.

Remote Controller

The DJI RC Pro Enterprise remote controller features O3 Enterprise, the latest version of DJI’s

signature OCUSYNCTM image transmission technology, and can transmit a live HD view from the

camera of an aircraft at a distance of up to 15 km*. The remote controller comes with a wide range of

aircraft and gimbal controls as well as customizable buttons. The built-in microphone allows recording

voice and 5.5-in high brightness 1000 cd/m2 screen boasts a resolution of 1920×1080 pixels. Users

can connect to the internet via Wi-Fi and the Android operating system comes with a variety of

functions such as Bluetooth and GNSS.

1. Control Sticks

2. Back/Function Button

3. RTH Button

4. Flight Pause Button

5. Flight Mode Switch

6. 5D Button

7. Power Button

8. Confirm Button/Customizable C3

Button

9. Touchscreen

10. M4 Screw Hole

11. microSD Card Slot

12. USB-C Port

13. Mini HDMI Port

14. Microphone

15. Gimbal Dial

16. Record Button

17. Antennas

18. Status LED

19. Battery Level LEDs

20. Focus/Shutter Button

21. Camera Settings Dial

22. Air Vent

23. Control Sticks Storage Slot

24. Customizable C1 Button

25. Speaker

26. Customizable C2 Button

27. Air Intake

* The remote controller is able to reach its maximum transmission distance (FCC) in a wide-open area

with no electromagnetic interference at an altitude of about 400 ft (120 m).

1. Watching the Tutorials

Scan the QR code or visit www.dji.com/mavic-3-enterprise to watch the tutorial videos.

2. Charging the Battery

Charge to activate the Intelligent Flight Battery and the internal battery of the Remote Controller

before using for the first time.

Check battery level: press once.

Power on/off: press, then press and hold.

3. Preparing the Aircraft

Unfold the front arms

Unfold the rear arms

Remove the gimbal protector from the camera

Press the propellers

down and rotate until

they click in place

Match the propellers to motors

Unfolded

Unfold the front arms before the rear ones. All arms and propellers must be unfolded before

takeoff.

4. Preparing the Remote Controller

Remove the control sticks

from the storage slots

Attach the control sticks and

twist to secure

Unfold the antennas

The optimal transmission range is where the antennas are facing toward the aircraft and the angle

between the antennas and the back of the remote controller is 180° or 270°.

DO NOT operate other wireless devices at the same frequency as the remote

controller, to avoid signal interference.

A warning prompt appears in DJI Pilot 2 if the transmission signal is weak. Adjust the

antennas to make sure that the aircraft is within the optimal transmission range.

5. Getting Ready for Takeoff

Power on the remote

controller

Power on the aircraft

Launch DJI Pilot 2

Use a DJI account to activate the aircraft and the remote controller. Activation requires

an internet connection. Before activating the aircraft in DJI Pilot 2, power on the remote

controller and follow the prompts to activate.

6. Flight

Manual Takeoff/Landing

Start/stop motors:

perform Combination

Stick Command and hold

for two seconds.

Takeoff: slowly push the left control stick (mode 2) up to take

off.

Landing: slowly push the left control stick (mode 2) down

until the aircraft lands. Hold for three seconds to stop the

motors.

Control Stick Mode

The default control stick mode is mode 2. The left control stick controls the altitude and heading of

the aircraft while the right control stick controls the forward, backward, and sideward movements.

Always set an appropriate RTH mode and altitude when remote controller signal is

lost before takeoff.

Press the Flight Pause button for emergency braking during flight.

Specifications

Aircraft (Model: M3E/M3T)

Takeoff Weight (with

propellers)

915 g (Mavic 3E), 920 g (Mavic 3T)

Max Takeoff Weight

1050 g

Max Ascent Speed

8 m/s (Sport mode)

6 m/s (Normal mode)

1 m/s (Cine Mode)

Max Descent Speed

6 m/s (Sport mode)

6 m/s (Normal mode)

1 m/s (Cine Mode)

Max Horizontal Speed

(near sea level, no wind)

21 m/s (Sport mode), 19 m/s (Sport mode, EU)

15 m/s (Normal mode)

5 m/s (Cine Mode)

Max Service Ceiling Above

Sea Level

6,000 m

Max Flight Time (without

wind)

45 min (Mavic 3E), 44 min (Mavic 3T)

Max Hover Time (without

wind)

39 min (Mavic 3E), 38 min (Mavic 3T)

Max Wind Speed Resistance

12 m/s

Operating Temperature

-10° to 40° C (14° to 104° F)

GNSS

GPS + Galileo + BeiDou

Operating Frequency

2.400-2.4835 GHz, 5.725-5.850 GHz*

Transmitter Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)

5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)

Interface

USB-C, microSD card slot, PSDK port

Gimbal

Angular vibration range

±0.007°

Controllable Rotating Range

Tilt: -90° to +35°

Mavic 3E Wide Camera

Sensor

4/3" CMOS; Effective pixels: 20M

Lens

FOV: 84°

Format Equivalent: 24 mm

Aperture: f/2.8-f/11

Focus 1 m to ∞

Mavic 3E/3T Tele Camera

Sensor

1/2" CMOS; Effective pixels: 12M

Lens

FOV: 15°

Format Equivalent: 162 mm

Aperture: f/4.4

Focus 3 m to ∞

Mavic 3T Wide Camera

Sensor

1/2" CMOS; Effective pixels: 48M

Lens

FOV: 84°

Format Equivalent: 24 mm

Aperture: f/2.8

Focus 1 m to ∞

Mavic 3T Thermal Camera

Thermal Imager

Uncooled VOx Microbolometer

Lens

DFOV: 61°

Focal Length: 9.1 mm (equivalent: 40 mm)

Aperture: f/1.0

Focus: 5 m to ∞

Infrared Temperature

Measurement Accuracy

±2° C or ±2% (using the larger value)

Intelligent Flight Battery

Capacity

5000 mAh

Standard Voltage

15.4 V

Max Charging Voltage

17.6 V

Battery Type

LiPo 4S

Energy

77 Wh

Weight

335.5 g

Charging Temperature

5° to 40° C (41° to 104° F)

Battery Charger

Input

100-240 V AC, 50-60 Hz, 2.5 A

Output

Max. 100W (Total)

When both the ports are used, the maximum output power of each

interface is 82 W, and the charger will dynamically allocate the

output power of the two ports according to the load power.

Remote Controller (Model: RC510B)

Weight

Approx. 680 g

Battery

Li-ion (5000 mAh @ 7.2 V)

Storage Capacity

ROM 64GB + expandable storage via microSD card

Operating Time

3 hours

Operating Temperature

-10° to 40° C (14° to 104° F)

Charging Temperature

5° to 40° C (41° to 104° F)

GNSS

GPS + Galileo + GLONASS

O3 Enterprise

Operating Frequency

2.400-2.4835 GHz, 5.725-5.850 GHz*

Max Transmission Distance

(Unobstructed, free of

interference)

15 km (FCC), 8 km (CE/SRRC/MIC)

Max Transmission Distance

Strong Interference (urban landscape, limited line of sight, many

(with interference)

competing signals):

1.5-3 km (FCC/CE/SRRC/MIC)

Medium Interference (suburban landscape, open line of sight, some

competing signals):

3-9 km (FCC), 3-6 km (CE/SRRC/MIC)

Weak Interference (open landscape, abundant line of sight, few

competing signals):

9-15 km (FCC), 6-8 km (CE/SRRC/MIC)

Transmitter Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)

5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)

Wi-Fi

Protocol

802.11 a/b/g/n/ac/ax

Support 2×2 MIMO Wi-Fi

Operating Frequency

2.400-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz*

Transmitter Power (EIRP)

2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)

5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)

5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)

Bluetooth

Protocol

Bluetooth 5.1

Operating Frequency

2.400-2.4835 GHz

Transmitter Power (EIRP)

<10 dBm

* 5.8 and 5.1GHz frequencies are prohibited in some countries. In some countries, the 5.1GHz frequency

is only allowed for use indoor.

For more information, read the User Manual: www.dji.com/mavic-3-enterprice

※This content is subject to change without prior notice.
