6.1.5 Slide the filter support between the filter support mounting and the filter support rest until it
comes to a stop. Push the filter support rest up and tighten the fastening screws. The setting
is correct when the filter support independently remains in the mounting.
6.1.6 Check whether the factory grinding time settings for single shots S 2.0 and double shots D
4.0 appear in the display. If the display corresponds to the factory settings, continue as
described in point 6; if this is not the case, the time must be set (see point 6.2.3.).
6.1.7 Setting the grinding time (portion quantity). Simultaneously press both buttons for approx. 3
sec.. MENU appears in the display. Scroll to menu option STI using the single button. Use the
rotary knob, item 6, to set 2.0 sec. Scroll to menu option DTI using the single button. Use the
rotary knob, item 9, to set 4.0 sec. To store these values, press both buttons simultaneously
until SAVE appears in the display.
6.1.8 Adjust the grinding fineness by pulling the sliding detent (4) out to the front and turning the lid /
grinding fineness adjustment to the 2 ½ mark. Note that "0" is the finest setting and "10" is the
most coarse setting. A total of 19 settings are available.
6.1.9 Push your espresso machine's filter support into the filter support mounting, item 8, until the
grinding process is switched on. Only remove the filter support once the grinding process has
been completed. This process has to be repeated approximately twice until the grinder casing
is filled with ground material.
6.1.10 Now make a test portion of espresso using your machine. If the result is unsatisfactory, repeat
adjustment steps 6 to 8 again by varying the grinding time and grinding fineness. Carry out
this process until the best coffee results have been reached.
6.2 Display / Menu
6.2.1 Calling up the menu: To call the menu up, simultaneously press both buttons for approx. 3
sec. MENU appears in the display. Scroll forwards using the single button. Scroll backwards
using the double button.
6.2.2 Grinding time setting: The grinding time range for single cups may be set between 0.1 and
10 sec. Scroll to menu option STI (time for single cups) using the single button. Use the rotary
knob, item 6, to set the time. Scroll to menu option DTI (time for double cups) using the single
button. Use the rotary knob, item 13, to set the time.
6.2.3 Store grinding time or go to 6.2.4. To store these values, press both buttons simultaneously
until SAVE appears in the display.
6.2.4 Quantity indicator: Scroll to menu option S using the single button. The display shows e.g. S
000020 – You have ground 20 single cup portions. Scroll to menu option D using the single
button. The display shows e.g. D 00018 – You have ground 18 double cup portions.
6.2.5 Continuous quantity indicator: Scroll to menu option SC using the single button. The
display shows e.g. SC 000127 – You have ground 127 single cup portions. If you wish to set
the grinding time, proceed from point 6.2.3. If you would like to exit the menu, press both
buttons simultaneously until SAVE appears in the display.
6.2.6 Reset function: If you wish to reset the quantity indicator, switch the grinder off at the mains
switch. Press both buttons simultaneously and switch the mains switch on again. The quantity
indicator is now set to 0.
6.2.7 Interruption of grinding: If the grinding process is interrupted before the set grinding time
has expired, the light-emitting diode in the active pre-selection button flashes. The grinding
process can be re-started by pushing the filter support back into the mounting. The missing
quantity is ground into the filter support. If this is not desired, the pre-selection button can be
activated and the entire set grinding quantity or grinding time is available once again.
