DITEC CROSS7E User manual
IP2012
rev. 2008-12-18
CROSS7E / 8E / 14E - E1A
QUICK REFERENCE
1. ELECTRICAL CONNECTIONS FOR STANDARD INSTALLATION
Before installing the product, carefully read the instructions.
XEL5
XEL2 XEL2 RX
01
4x0,5 mm²
4x0,5 mm²
4x0,5 mm²
C
NO
NC
RG58 (max 10 m)
230~
2x1,5 mm²
GOL4-GOL4C
LAMP
TX
01
ANT E1A
L
N
N
CUWV
12
12 11
0
011 1568941
GOL4-GOL4C
3x1,5 mm²
Power supply
2
CROSS7E / 8E / 14E - E1A QUICK REFERENCE - IP2012
2. USAGE WITH STOP LIMIT SWITCH
OPENING
CYCLE
OPENING
CYCLE
CLOSING
CYCLE
CLOSING
CYCLE
C
C
A
A
DIP2=OFF
AOpening limit
switch setting
CClosing limit
switch setting
DIP2=ON
AOpening limit
switch setting
CClosing limit
switch setting
1°
1°
2°
2°
3CROSS7E / 8E / 14E - E1A QUICK REFERENCE - IP2012
4. RADIO ENABLING
3. E1A STANDARD SETTING
i
For different setting and further information consult the CROSS7E/8E and CROSS14E automation instruction manual,
the E1A control panel instruction manual and BIXLR22 radio instruction manual.
DITEC S.p.A.
Via Mons. Ban, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
5. AUTOMATIC CLOSING SETTING
-+
TC time setting
DISABLED!
MAX
1°
-+
TC time setting
ENABLED!
2°
MIN=0 s MAX
120 s
MIN=0 s MAX
120 s
1234
ON
OFF
DIP1 = ON
DIP2 = ON
OPENING RADIO MODE
LEFT OPENING
DIP2 = OFF
RIGHT OPENING
DIP1 = OFF
STEP BY STEP RADIO MODE
R1 TC TM
RF
1
5
4
2
12 011
JR4
LN NC UWV 12 11 0 1 568941
JR6
JR3
NIO
JR10
SO 6 4
3
SIG
PRG
JR3
NIO
GOL4-GOL4C
Wait for 10 s
SIG
Push PRG
Led SIG comes on
Push CH
SIG
Led SIG flashes 3 times
1° 2°
