Dirt Devil DD7002 User manual
STEAM MOP
1300W
220-240V~50-60HZ
ITEM: 871125247589
A.I.&E. Adriaan Mulderweg 9-11
5657 EM Eindhoven, The Netherlands
DD7002
330ml
2
YEAR
GUARANTEE
5,5M
30
sec
ready in
Points de collecte sur www quefairedemesdechets.fr
Cet appareil,
ses accessoires,
piles et cordons
se recyclent
À DÉPOSER
EN MAGASIN À DÉPOSER
EN DÉCHÈTERIE
OU
FRFR
INSTRUCTION MANUAL
AINSTRUCTION MANUAL
Steam-mop
Model number: DD7002 / VS521
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE USE
This model is for household use only. Commercial use of this unit
voids the manufacturer’s warranty.
READ ALL INSTRUCTIONS BEFORE USING YOUR STEAM MOP
When using an electrical appliance, basic precautions should be
observed, including the following:
• Unplug from outlet when not in use and before conducting
maintenance
WARNINGS
• TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY:
Always switch off and unplug the appliances from the socket after use
and before
cleaning the appliance or any maintenance task.
• WARNING: Danger of scalding.
• This appliance can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
• Cleaning
and user maintenance shall not be made by children without
supervision.
• Keep the appliance out of the reach of children when it is energized or
cooling down.
• The appliance shall not be left unattended while it is connected to
socket.
• The appliance shall not be used if it has been dropped, if there are
Scan QR-Code for
extended manual
visible signs of damage or if it is leaking.
• Liquid or steam must not be directed towards equipment containing
electrical components, such as the interior of ovens.
• If the power cord is damaged stop using the appliance immediately.
• To avoid a safety hazard, an authorized agency service engineer must
replace
the power cord.
• Keep hands, feet, loose clothing and hair away from rotating brushes.
• Use only the power plug supplied with the appliance.
• Static electricity: some carpets can cause a small buildup of static
electricity. Any static discharge is not hazardous to health.
• Do not use your appliance out of doors or on any wet surface or for
wet pick up.
• Do not pick up hard or sharp objects, matches, hot ashes, cigarette
ends or other similar items.
• Do not spray with or pick up ammable liquids, cleaning uids,
aerosols or their vapors.
• Do not run over the power cord when using your appliance or
remove
the plug by pulling on the power cord.
• Do not continue to use your appliance or charger if it appears
faulty.
• Agency service: To ensure the continued safe and efcient
operation of this appliance we recommend that any servicing
or repairs are
only carried out by an authorized Agency service
engineer.
• Do not use the appliance to clean animals or people.
• Do not use appliance in an enclosed space lled with vapor given
off by oil-base paint, paint thinner, some moth proong substances,
ammable dust, or other explosive or toxic vapors
• Do not use on leather, wax polished furniture or oors, synthetic
fabrics, valet or other delicate, steam-sensitive materials
• CAUTION: HOT SURFACE
• IPX4: Item is protected from splashing water, not matter the
direction.
Product View
1. Steam control 10. Water cup
2. Steam level indicator 11. Mop pad
3. Lower body 12. Carpet glider
4. Mop head 13. Wire hook
5. Wire hook 14. Metal tube
6. Power switch 15. Tube lock
7. Filter 16. Water inlet
8. Power cord 17. Handle
9. Water tank
Installation of the item
Your steam mop assembles quickly and easily. It is packaged with the
following items:
(1) Handle (2)Lower Body (3)Mop Head
(4)Water Tank (5) Mop pad
1. Attach lower body (2) to mop head (3) by snapping it into place
2. Install the handle (1) into the lower body until it lock into right place
3. Install the water tank (4) below the main body
4. Install the mop pad (5) on the mop head
5. Steam mop assembly is now complete
Operations
Special Features
Removable water tank
Water tank is located on the bottom of the main body. Distilled or
demineralize water is recommended instead of tap water
Filter
Water tank
Filter
Water cup
Note:
Turn off the steam mop when taking the water tank off
Fill the water tank with the water cup
Do not use chemicals in the water tank of your steam mop
Steam Control
Steam control indicator light will stop blinking when steam mop is
ready to use. Then press the steam level button to choose the level of
steam you desire.
Steam level indicator
Steam control Power switch
Note:
Press the power switch rst and then press the steam control. Please
note that when you rst press the steam level button, the steam is at
its maximum level. Please adjust your desired level by pressing the
button.
Microber Mop Pads
Reusable microber mop pads are
machine washable and safe for
virtually all hard oor surfaces. Your
steam mop may have come with two
different pads. The white microber
pad is best for everyday use on
delicate ooring like sealed
hardwoods and laminate. The gray
and white striped pad can be used
for scrubbing heavily soiled oors
and cleaning tougher messes.
Getting ready
The mop pad may have already come attached to the mop head.
1. Set mop head in mop pad, making sure quick-grip release tab is
located on the back.
2. Fill the water tank.
a. Press the buttons on both sides of the tank and pull it out.
b. Pull out the rubber plug on the back of the tank.
c. Fill water tank with water. For beat results, water should be at
room temperature.
d. Replace the water tank and gently slide it into place.
3. Quickly release the power cord and insert it into the 120volt power
socket.
4. The indicator will light up when the steam mop is ready to use press
the steam level button to select the steam level you want.
Note:
Upon rst use of the steam mop or rst use after relling the water
tank, the pump may make a “knocking” sound. This is normal and
should only last a few seconds.
Before you clean
Thoroughly sweep or vacuum oor prior to cleaning with the steam
mop.
Mop pad
Cleaning hard oors
Your steam mop is designed to clean hard ooring such as ceramic
tile, vinyl, laminate, marble, stone and sealed hard wood oors. Use
of your steam mop on waxed or some unwaxed oors may result in a
diminished glossiness. The steam mop is not for inconspicuous area
and check the care instructions from your ooring manufacturer.
1. Plug the unit in and wait 30 seconds for it to heat up. Choose the
level of steam to clean your oor: Low(delicate oors). Medium(regular
cleaning). High(durable oors or sticky messes). Begin cleaning by
slowly passing the unit over the oor surface.
Steam level indicator
Steam control Power switch
1
2High
Medium
Low
Note:
Press power switch before you press steam control. When you rst
press the steam level button, the steam is at its maximum level.
Please adjust desired level by pressing the button.
2. To turn off the steam mop, continue to press the steam level button
until the blue light is illuminated above the steam level button.
3. When the steam mop stops emitting steam, unplug the unit. Simply
remove the water tank, rell and continue steaming.
Note: Be sure to disinfect the oor, use a microber mat and wipe it
back and forth at least three times with continuous steam. For best
results, remove the liner and clean it after.
Carpet Gilder
This accessory is used to attach the steam mop to allow the steam
mop to slide over the carpet, thus cleaning the carpet.
Note: Please make sure that carpet gilder has been buckled on the
oor head. If it is not in the correct position, it will cause carpet gilder
to fall out during the use of the steam mop.
Note: Move the steam mop in a continuous motion until you are
nished. DO NOT leave the mop in a stationary position.
Maintenance & Care
1. Unplug power cord form outlet.
2. Carefully remove the mop pad from the mop head. The mop pad
and lower assembly may be hot.
3. Any water remaining in the water tank should be emptied prior to
machine storage.
4. Mop pad can be machine washed in warm water. Use only liquid
detergents. Do not use fabric softeners or bleach for best results, air
dry.
5. Wrap power cord around hook on back of the steam mop.
6. Wipe all surfaces of the steam mop with a soft cloth. Store upright in
a protected, dry area.
Troubleshooting
WARNING
To reduce the risk of electric shock, turn power switch off and
disconnect the plug form electrical outlet before performing
maintenance or troubleshooting checks.
Problem Possible Remedies
Reduced steam or
no steam
Water tank empty Fill tank
Steam level not se-
lected
Select steam level by pushing
steam level button
Note:
Other maintenance or service not included in the manual should be
performed by an authorized service representative.
Specications
Power : 1300W
Input voltage : 220 - 240 V AC 50-60 Hz
Power plug : Type C (CEE 7/17)
Capacity watertank : 330ml
Usetime full tank : 15min
Steam pressure: 0,6-0,8 bar
Heating time : 30sec
Cable length : 5m
Range : 5,5m
Removable tank : Yes
Hard water lter : Yes
Variable steam control : Yes
Shape foot : Rectangle
PACKAGING CONTENT
1x steam mop
1x carpet slider
1x microber pad
The Environment
The symbol on this appliance indicates that this appliance may not be
treated as household
waste. Instead it must be handed over to the
applicable collection point for the recycling of
electrical and electronic
equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed
information about treatment,
recovery and recycling of this appliance,
please contact your local city ofce, your household
and waste
disposal service or the shop where you purchased the appliance.
This manual suits for next models
1
Table of contents
Other Dirt Devil Steam Cleaner manuals
Dirt Devil
Dirt Devil AquaClean User manual
Dirt Devil
Dirt Devil AquaClean M319 Series User manual
Dirt Devil
Dirt Devil PD20000B User manual
Dirt Devil
Dirt Devil MBV2030 User manual
Dirt Devil
Dirt Devil SM10 User manual
Dirt Devil
Dirt Devil AQUAClean DD301-0 User manual
Dirt Devil
Dirt Devil AquaClean M317 User manual
Dirt Devil
Dirt Devil vapormate M388 User manual
Dirt Devil
Dirt Devil Vaporflex M3101 User manual
Dirt Devil
Dirt Devil aqua clean DD301 User manual
Dirt Devil
Dirt Devil AquaClean M318 User manual
Dirt Devil
Dirt Devil DD304STG User manual
Dirt Devil
Dirt Devil DAMPFMOP M333 User manual
Dirt Devil
Dirt Devil PD20000B User manual
Dirt Devil
Dirt Devil SM11 User manual
Dirt Devil
Dirt Devil AQUAclean DD302 User manual
Dirt Devil
Dirt Devil Vaporflex User manual
Dirt Devil
Dirt Devil Shark DAMPFMop User manual
Dirt Devil
Dirt Devil Vaporex M380 User manual
Dirt Devil
Dirt Devil 5 User manual
